1. Important This electronic user’s guide is intended for anyone who uses the Philips monitor. Take time to read this user manual before you use your monitor. It contains important information and notes regarding operating your monitor. The Philips guarantee applies provided the...
• IMPORTANT: Always activate a moving screen saver program when you leave your monitor unattended. Always activate a periodic screen refresh application if your monitor will display unchanging static content. Uninterrupted display of still or static images over an extended period may cause “burn in”, also known as “after-imaging”...
1.3 Disposal of product and packing material Waste Electrical and Electronic Equipment- WEEE This marking on the product or on its packaging illustrates that, under European Directive 2002/96/ EC governing used electrical and electronic appliances, this product may not be disposed of with normal household waste.
2. Setting up the monitor 2.1 Installation 191V2 Package contents LCD Monitor Monitor LCD / Monitor LCD / LCD-Monitor / Moniteur LCD / LCD Monitor / LCD监视器 / LCD-монитором 191V Guide de démarrage rapide / Guía rápida / Kurzanleitung / H zl başlangiç...
Page 7
Return to previous OSD level. Description of the On Screen Display What is On-Screen Display (OSD)? On-Screen Display (OSD) is a feature in all Philips LCD monitors. It allows an end user to adjust screen performance or select functions of the monitors directly through an on-screen instruction window.
Physical Function Tilt (191V2) 2.3 Remove Base Stand and Base Remove the Base Stand 191V2 Place the monitor face on a safe surface, pull the base stand away from the monitor. Remove the Base Condition: • For VESA standard mounting applications 1.
3. Product information 3.1 SmartContrast What is it? Unique technology that dynamically analyzes displayed content and automatically optimizes a LCD monitor's contrast ratio for maximum visual clarity and viewing enjoyment, stepping up backlighting for clearer, crisper and brighter images or dimming backlighting for clear display of images on dark backgrounds.
3.2 Philips SmartControl Lite The new SmartControl Lite software by Phillips allows you to control your monitor via an easy to use on-screen graphic interface. Complicated adjustments are a thing of the past as this user friendly software guides you through...
Page 11
Start with Standard pane: Adjust menu: • Adjust Menu allow you to adjust Brightness, Contrast, Focus, Position and Resolution. • You can follow the instruction and do the adjustment. • Cancel prompts user if you want to cancel installation.
Page 12
Color menu: • Color Menu allow you to adjust RGB, Black Level, White Point, Color Calibration, and SmartImage Lite (Please refer to SmartImage Lite section). • You can follow the instruction and do the adjustment. • Refer to below table for sub-menu item base on your input.
Page 13
First color Calibration Screen: • Previous button is disabled until the second color screen. • Next goes to the succeeding target (6-targets). • Final next goes File>Presets pane. • Cancel closes the UI and returns to the plug in page. SmartImage Lite Allows user to change setting for better display setting based on content.
Page 14
Options>Input - Will only be active when selecting Input from the drop-down Options menu. On a non-supported display capable of DDC/CI, only the Help and Options tabs are available. All other SmartControl Lite tabs are not available. • Display the Source instruction pane and current input source setting.
Page 15
Help>Version - Will only be active when selecting Version from the drop- down Help menu. On a non-supported display capable of DDC/CI, only the Help and Options tabs are available. Context Sensitive menu The Context Sensitive menu is Enabled by default. If Enable Context Menu has been checked in the Options>Preferences pane, then the menu will be visible.
Page 16
Task Tray Menu Enabled The task tray menu can be displayed by right- clicking on the SmartControl Lite icon from the task tray. Left Click will launch the application. The task tray has five entries: • Help - Access to User Manual file: Open User Manual file using the default browser window.
Page 17
TFT LCD panels used in flat panel monitors are sometimes unavoidable. No manufacturer can guarantee that all panels will be free from pixel defects, but Philips guarantees that any monitor with an unacceptable number of defects will be repaired or replaced under warranty.
Page 18
In order to qualify for repair or replacement due to pixel defects during the warranty period, a TFT LCD panel in a Philips flat panel monitor must have pixel or sub pixel defects exceeding the tolerances listed in the following tables.
Separate Sync, Sync on Green 4:3 Wide/ , Power On/Off , Menu (OK), Brightness/ , AUTO/back, English, French, German, Italian, Russian, Spanish, Simplified Chinese, Portuguese VESA mount ( 100 x 100mm), Kensington lock DDC/CI, sRGB, Windows 7/Vista/XP, Mac OSX, Linux -5/+20 (191V2)
Page 20
Power On mode (EnergyStar 5.0 test method) Energy Consumption (EnergyStar 5.0 test method) Normal Operation (typical) Sleep Heat Dissipation* Normal Operation Sleep Power LED indicator Power Supply Dimension Product with stand (WxHxD) Product without stand (WxHxD) Box dimension (WxHxD) Weight Product with stand Product without stand Product with packaging Operating Condition Temperature range (operation)
Page 21
Color Finish Note This data is subject to change without notice. Go to www.philips.com/support to download the latest version of leaflet. Silver. (www.epeat.net) 100% recyclable CE Mark, FCC Class B, SEMKO, TCO5.0, TÜV/ GS, TÜV Ergo, UL/cUL, Energy star 5.0, TCO5.0...
4.1 Resolution & Preset Modes Maximum Resolution For 191V2 1366 x 768 at 60 Hz (analog input) 1366 x 768 at 60 Hz (digital input) Recommended Resolution For 191V2 1366 x 768 at 60 Hz (digital input) H. freq (kHz) Resolution 31.469...
Lead has been eliminated and compliance with European community’s stringent RoHs directive mandating restrictions on hazardous substances in electrical and electronic equipment have been adhered to in order to make Philips monitors safe to use throughout its life cycle. TCO Displays 5.0 Information Congratulations,...
Page 24
Benefits of EPEAT Reduce use of primary materials Reduce use of toxic materials Avoid the disposal of hazardous waste EPEAT’S requirement that all registered products meet ENERGY STAR’s energy efficiency specifications, means that these products will consume less energy throughout their life. CE Declaration of Conformity This product is in conformity with the following standards...
Page 25
Federal Communications Commission (FCC) Notice (U.S. Only) This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
Page 26
Commission Federale de la Communication (FCC Declaration) Cet équipement a été testé et déclaré conforme auxlimites des appareils numériques de class B,aux termes de l'article 15 Des règles de la FCC. Ces limites sont conçues de façon à fourir une protection raisonnable contre les interférences nuisibles dans le cadre d'une installation résidentielle.
Page 27
Polish Center for Testing and Certification Notice The equipment should draw power from a socket with an attached protection circuit (a three- prong socket). All equipment that works together (computer, monitor, printer, and so on) should have the same power supply source. The phasing conductor of the room's electrical installation should have a reserve short-circuit protection device in the form of a fuse with a...
Page 28
Ergonomie Hinweis (nur Deutschland) Der von uns gelieferte Farbmonitor entspricht den in der "Verordnung über den Schutz vor Schäden durch Röntgenstrahlen" festgelegten Vorschriften. Auf der Rückwand des Gerätes befindet sich ein Aufkleber, der auf die Unbedenklichkeit der Inbetriebnahme hinweist, da die Vorschriften über die Bauart von Störstrahlern nach Anlage III ¤ 5 Abs.
Philips helpdesk directly to benefit from your Philips F1rst Choice Warranty. This three-year service warranty entitles you to a swap model on-site if your monitor turns out to be faulty or defective. Philips aims at a swap within 48 hours of your call being received. What is covered? The Philips F1rst Choice Warranty applies within...
Page 30
• Note that products that are not originally designed, manufactured, approved and/or authorized for usage within the Philips F1rst Choice countries, do not apply to the Philips F1rst Choice Warranty. In these cases the Philips global warranty terms are valid. Just a click away...
Page 31
F1rst Choice Contact Information Country Code Austria Belgium Denmark Finland +358 Luxembourg +352 The Netherlands Norway Poland Portugal +351 Spain Sweden Switzerland United Kingdom Telephone number Tariff €0.07 0810 000206 €0.06 078 250851 3525 8761 Local call tariff €0.08 840 320 041 26 84 30 00 Local call tariff €0.10...
Page 32
Information Centers In case your Philips product is not working correctly or is defective, please contact your Philips dealer or directly the Philips Service and Consumer Information Centers...
Page 33
Consumer Information Centers Argentina / Australia / Brasil / Canada / New Zealand / Belarus / Bulgaria / Croatia / Czech Republic / Estonia / United Arab Emirates / Hong Kong / Hungary / India / Indonesia / Israel / Latvia / Lithuania / Malaysia / Middle East + North Africa / New Zealand / Pakistan / Romania / Russia / Serbia &...
Page 34
123290 Moscow Russia Tel. +7(495)797 3434 Profservice: 14A -3, 2Karacharovskaya str, 109202, Moscow , Russia Tel. +7(095)170-5401 TURKEY Türk Philips Ticaret A.S. Yukari Dudullu Org.San.Bolgesi 2.Cadde No:22 34776-Umraniye/Istanbul Tel: (0800)-261 33 02 UKRAINE Comel Shevchenko street 32 UA - 49030 Dnepropetrovsk Tel: +380 562320045 www.csp-comel.com LLC Topaz Company...
Page 35
Fax: 021-7510982 E-mail: gepta@cbn.net.id Service hours: Mon.~Fri. 8:30am~4:30pm; Sat. 8:30am~2:00pm Additional service points: 1. Philips Building Jl. Buncit Raya Kav 99. Jakarta Selatan. Phone: 021-7940040, ext 1722/1724, 98249295, 70980942 2. Jl. Tanah Abang 1 no 12S. Jakarta Pusat. Phone: 021-3455150, 34835453 3.
Page 36
Singapore Company: Philips Electronics Singapore Pte Ltd (Philips Consumer Care Center) Address: 620A Lorong 1 Toa Payoh, TP4 Building Level 1, Singapore 319762 Tel: (65) 6882 3999 Fax: (65) 62508037 E-mail: consumer.care.sg@philips.com Service hours: Mon.~Fri. 9:00am~6:00pm; Sat. 9:00am~1:00pm Taiwan Company: FETEC.CO Address: 3F, No.6, Lane 205, Sec.
Page 37
Should you encounter any difficulties while installing or using this product, please contact Philips directly to benefit from your Philips F1rst Choice Warranty. This three-year service warranty entitles you to a swap model on-site within 48 hours of your call being received within the first year of purchase.
Page 38
Philips Consumer Electronics. reception problems caused by signal conditions or cable or antenna systems outside the unit.
Page 39
Please contact Philips at: (800) 479-6696 Three years free parts and three years free labor will be provided at Philips Canada depot or any one of its authorized service centers. (In Canada, this warranty is given in lieu of all other warranties.
Page 40
In the event you require service whilst in another country a dealer address can be given to you by the Philips Consumer Help Desk in that country, the telephone and fax number of which can be found in the relevant part of this booklet.
7 Troubleshooting & FAQs 7.1 Troubleshooting This page deals with problems that can be corrected by a user. If the problem still persists after you have tried these solutions, contact Philips customer service representative. Common Problems No Picture (Power LED not lit) • Make sure the power cord is plugged into...
Page 42
• Check if audio cable is connected to PC and monitor correctly. • Ensure audio is not muted. Press OSD “Menu”, select “Audio” then “Mute”. Check it on “Off ” position. • Press “Volume” in OSD main control to adjust the volume. For further assistance, refer to the Consumer Information Centers list and contact Philips customer service representative.
Remove SmartControl Lite and re-install it once more. Q5. I forgot my PIN for Theft Deterrence Function. How can I do? Ans.: Philips Service center has a right to ask for legitimate identification and authorization, in order to establish ownership of the monitor.
2 and 3 to verify that your PC is set at 1366 x 768@60Hz (18.5"). • Shut down your computer, disconnect your old monitor and reconnect your Philips LCD monitor. • Turn on your monitor and then turn on your PC.
Page 45
(degrees Kelvin). Lower Kevin temperatures such as 2004K are red; higher temperatures such as 9300K are blue. Neutral temperature is white, at 6504K. Q9: Can the Philips LCD Monitor be mounted on the wall? Ans.: Yes. Philips LCD monitors have this optional feature.
Page 46
gives superior results over TN panel. Q13: What is Image Sticking, or Image Burn-in, or After Image, or Ghost Image in LCD panels? Ans.: Uninterrupted display of still or static images over an extended period may cause "burn in", also known as "after-imaging" or "ghost imaging", on your screen.
