OWNER'S MANUAL
4 0 " L A W N A E R A T O R
MODEL:
S A 2 - 4 0 B H - G
• Assembly
• Installation
• Operation
• Repair Parts
Visit us on the web!
www.brinly.com
English Manual
Call Customer Service, Toll-Free: 877-728-8224
Important: This manual contains information for the safety
of persons and property. Read it carefully before
assembly and operation of the equipment!
1
1019097-D

Advertisement

loading
Need help?

Need help?

Do you have a question about the SA2-40BH-G and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Brinly SA2-40BH-G

Summary of Contents for Brinly SA2-40BH-G

  • Page 1 • Operation • Repair Parts Call Customer Service, Toll-Free: 877-728-8224 Important: This manual contains information for the safety Visit us on the web! of persons and property. Read it carefully before www.brinly.com assembly and operation of the equipment! 1019097-D English Manual...

  • Page 2: Table Of Contents

    INTRODUCTION AND SAFETY CONGRATULATIONS on your new Brinly-Hardy Aerator! This accessory has been designed, engineered and manufactured to give you the best possible dependability and performance. Should you experience any problem you cannot easily remedy, please do not hesitate to contact our knowledgeable customer service department toll-free at 1-877-728-8224.

  • Page 3: Safety

    SAFETY GENERAL NOTES (OPERATION) Caution should be taken when towing and/or using any attachment. This attachment combined with the weight distribution, turning radius, and speed of towing vehicle can result in severe injury or death to operator, damage to towing vehicle, and/or attachment if not used properly. Follow all towing safety precautions noted in the towing vehicle owner’s manual, including the following precautions: - Use this attachment for intended purpose only.
  • Page 4 Total towed weight must not exceed department, Toll Free: 877-728-8224 limits specified in towing vehicle operator’s manual. or customerservice@brinly.com - Excessive towed load can cause loss of traction and loss of control on slopes. Reduce towed weight when operating on slopes.

  • Page 5: Component View And Reference List

    COMPONENT VIEW AND REFERENCE LIST Ref # Part # Description Hardware Bag: 1019107 1018977-16 End Panel 2M1012P Bolt; Hex Head, 5/16 x 3/4 1018988 Tine Shaft 2M1016P Bolt; Hex Head, 5/16 x 1 1019410 Drawbar with Label B-4786 Nut; Nylock, 5/16 1019407 Tray with Labels 45M1111P...
  • Page 6 HARDWARE IDENTIFIER DO NOT RETURN PRODUCT IF YOU ARE MISSING PARTS. Illustrations on this page Please Call: 1 (877) 728-8224 are to scale for faster identification of hardware during assembly. Nut: Nylock 5/16” (x10) ... . . B-4786 Washer: Flat 5/16”...

  • Page 7: Assembly

    Additional info and videos are available on our website: brinly.com This QR code links directly to the Spike Aerator product page. Step 1-A Align the Drawbar (3) with the Tray (4) as illustrated.
  • Page 8 ASSEMBLY Step 1-B 1. Align the Clevis (20) to the Drawbar (3). - Attach the clevis from beneath with two 5/16" x 1" Hex Head Bolts (11). - Secure with two 5/16" Nylock Nuts (12). NOTE: Leave nuts loose on this step, allowing the End Panels (1) to be adjusted later. Step 2 Align an End Panel (1) with the Aerator Tray (4).
  • Page 9 ASSEMBLY Step 3 Slide a Cotter Pin (19) Place a 5/8" Flat through the end of Washer (15) on the Tine the Tine Shaft (2). Using Shaft (2) and push the Add a Square Bearing (17) and a pliers, bend the ends shaft through one End 5/8"...
  • Page 10 ASSEMBLY CAUTION: GlOves Are reqUIred. Tines have extremely sharp points. Use caution when working around them. Step 4-B 2. Push a Square 1. WEARING GLOVES: Bearing (17) into the Slide the 10 Tines (5) End Panel (1). and 20 Bearings (6) onto the Place a 5/8”...
  • Page 11 ASSEMBLY CAUTION: GlOves Are reqUIred. Tines have extremely sharp points. Use caution when working around them. Step 4-C Add as many 5/8" Flat Washers (15) to the opposite end of the shaft as necessary to eliminate extra space. Fasten the remaining Cotter Pin (19) on the end of the Tine Shaft (2).

  • Page 12: Operation

    Aerator Tray: the aerator across concrete or asphalt driveways and walkways. Weight CAUTION: Excessive towed load can Model SA2-40BH-G 25 lbs (empty) cause loss of control on slopes. Stopping distance increases with speed and the Maximum Tray Weight 110 lbs weight of the towed load.
  • Page 13 OPERATION TINES ADDING WEIGHT - Bagged weight material can fall through Tray Openings and be torn open or damaged by the CAUTION: AVOID INjURY! Openings in Tray allow access to Tines for cleaning Tines. Use solid weight or close Tray Openings with and service.

  • Page 14: Maintenance

    - For rust appearing on painted surfaces, sand wear of abrasive soil. Striking objects can cause Tines lightly and paint affected area with enamel. to curl or break. Contact Brinly-Hardy customer service - Periodically remove debris that department to purchase replacement Tines.

  • Page 15: Storage And Service

    If you have installation questions, are missing parts or need replacement parts, don’t go back to the store! Please find your product serial number and model number, then contact our Customer Service department: In North America and Canada call Toll-Free: 877-728-8224 Chat online: www.brinly.com Email: customerservice@brinly.com 1019097-D English Manual...

  • Page 16: Warranty

    MANUFACTURER’S LIMITEd WARRANTY AERATORS The limited warranty set forth below is given by Brinly-Hardy Company with respect to new merchandise purchased and used in the United States (its possessions and territories) and Canada. Brinly-Hardy Company warrants the products listed below against to use this product.
