VAL VLC-12V10-1 Operation Manual

Operation Manual
To use this LED controller with optimum performance and safety, please read this manual thoroughly before starting operation.
Keep this manual for the whole product lifetime.
The following warning symbols are used in this manual. Be sure to fully understand the contents.
WARNING
CAUTION
１．Safety regulations
Do not open the chassis to avoid electric shock.
High-voltage parts are inside.
Use only VAL LED lighting unit.
If you use with other lighting unit, over current may cause a fire or heat.
USE the extension or remote cables 3m maximum to prevent power drop by voltage reduction or malfunction by noise.
Do not look at the LED directly. If you see the LED long time, your eyes may be damaged.
Cleaning : Use wet cloth twisted well.
Dispose the product conforming to the law in the region where the product is used.
２．General Description
VLC-12V10-1 is a controller for VAL LED lighting unit (10W max. *).
It can be used with input voltage range with DC12V/1A. Remote control is also available.
３．Confirming package contents
Item
Main unit
Output connector
This instruction manual
４．Operation
(1) Connections
Connect cable to terminal block by figure.
CAUTION
(2) Manual control
Light intensity is adjustable manually where the control volume on the front panel.
Turn the volume anticlockwise, it becomes darker. Turn the volume clockwise, it becomes brighter.
５．External Signal Connector
Caution
Pin assignment of Terminal block
No. Identification
1 DC 12V IN
2 DC 0V IN
3
LED ON DC 0V IN /
OFF DC12-24V IN
4
LED ON/OFF DC0V IN
A warning denotes a hazard that can cause severe injury or death.
A caution denotes a hazard that can cause injury or damage of equipment.
Q'ty
1
1
1
Please be careful about polar character.
Use output signal cable size AWG min.24 – max.20.
Use flat head screwdriver. (Recommended width size 0.4x2.0mm)
Do not use screwdriver with excessive force.
Use output signal cable of 3m or shorter.
Do not apply too high current and voltage.
Do not use external connector except SELV circuit with reinforced insulation or a circuit with double insulation.
No. Identification
5
MANU/EXT.DC12-24V IN
6
MANU/EXT.DC0V IN
7 EXT.DC 0-5V IN
8 EXT.DC 0V IN
Controller for LED Illumination
VLC-12V10-1
WARNING
CAUTION
No. Identification
9 LED+OUT
10 LED-OUT
