User Manual
LC-RL-4-W
Wall Mount 4 CH RELAY Controller-Heavy Duty

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LC-RL-4-W and is the answer not in the manual?

Questions and answers

Related Manuals for Sonetonix LC-RL-4-W

Summary of Contents for Sonetonix LC-RL-4-W

  • Page 1 User Manual LC-RL-4-W Wall Mount 4 CH RELAY Controller-Heavy Duty...
  • Page 2 LC-RL-4-W User Manua Preface Read this user manual carefully before using this product. Pictures shown in this manual is for reference only, different model and specifications are subject to real product. This manual is only for operation instruction only, not for any maintenance usage. The functions described in this version are updated till January 2016.
  • Page 3 LC-RL-4-W User Manua SAFETY PRECAUTIONS To insure the best from the product, please read all instructions carefully before using the device. Save this manual for further reference.  Unpack the equipment carefully and save the original box and packing material for possible future shipment ...

  • Page 4: Table Of Contents

    LC-RL-4-W User Manua Content 1. PRODUCT OVERVIEW.................................. 1 1.1 Key Features....................................1 1.2 Override Input.................................... 2 1.3 Front panel....................................2 1.4 Loads......................................2 1.5 S-NET......................................2 2. TECHNICAL SPECIFICATIONS..............................3 2.1 Florescent/LED Dimmer Electrical Specifications........................ 3 2.2 Power Requirements................................3 2.3 Connections....................................3 2.4 Controls and Indications................................3 2.5 Mechanical specifications................................

  • Page 5: Product Overview

    Watchdog LED on front panel blinking @1 sec Indicates normal working condition of the Device Status indication LEDS for each channel S-NET Communication, using S-NET protocol enables the relay Controller to be connected with other Sonetonix Lighting/ Dimming modules for a complete Automation Solution Wall mountable Sonetonix...

  • Page 6: Override Input

    Pin 2 and connect to Load Live. 1.5 S-NET The LC-RL-4-W communicates with all Sonetonix products or third party units via S-NET. A pair of S-NET terminal blocks, allow for easy daisy-chaining of several DIN rail Series automation control modules.

  • Page 7: Technical Specifications

    LC-RL-4-W User Manua 2. Technical Specifications 2.1 Florescent/LED Dimmer Electrical Specifications Parameter Value Unit Operating Voltage(@50hz) 220-240 Max Power per channel 2200 Max Load current per channel Module Total current S-NET Power Usage 3.72 Operating Temperature 0 – 45 °C Table1.

  • Page 8: Mechanical Specifications

    LC-RL-4-W User Manua 2.5 Mechanical specifications 2.5.1 Enclosure Wall Mount d ark Gray metal sheet enclosure 2.5.2 Environmental Operating Temperature: 0° to 45°C 2.5.3 Dimensions and weight Parameter Value Unit Height 4.20 Inches Width 6.20 Inches Depth 1.57 Inches Weight...

  • Page 9: Application And Wiring Diagram

    LC-RL-4-W User Manua 3. Application and wiring diagram Sonetonix...

  • Page 10: Manual Control

    4. Manual Control 4.1 Programming the S-NET ID For any communication to take place with the LC-RL-4-W, it needs to be programmed with a unique S-NET ID (1 to 230). The S-NET ID can be set manually using the following procedure...

  • Page 11: S-Net Communication

    LC-RL-4-W User Manua 5. S-NET Communication can be connected in S-NET with other Automation modules using LC-RL-4-W RS485 serial interface. The signal connection is shown in Fig 1. Wiring diagram 5.1 Communication parameters Parameter Description Signal Level RS-485 compliant Synchronisation method...

  • Page 12: Examples

    LC-RL-4-W User Manua 5.3 Examples Command Description Get Device Info for ID 2 $02 $F2 Set New Device ID to ID 3 as 8 $FE $03 $F3 $08 $FD Force Set Device ID of a new ID to 01 $FE $F4 $01 $00 $FD...

  • Page 13: After-Sales Service

    LC-RL-4-W User Manua 7. After-sales Service If there appear some problems when running the device, please check and deal with the problems reference to this user manual. 1) Product Limited Warranty: We warrant that our products will be free from defects in materials and workmanship for three years, which starts from the first day the product leaves warehouse (check the SN mark on the product).
