Phantom Viewpoint VI0508 Installation Manual

Retractable screen solutions for right and left hinged doors openings up to 36” (914 mm) wide and 80 9/16” (2,047 mm) high
Hide thumbs

Advertisement

Table of Contents

Installation Manual for
For Right and Left Hinged Doors
Durable. Reliable. Attractive.
For door openings up to 36" (914 mm) wide
and 80 9/16" (2,047 mm) high
Quick
and
Easy
Size
to
Install
and

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Viewpoint VI0508 and is the answer not in the manual?

Questions and answers

Related Manuals for Phantom Viewpoint VI0508

Summary of Contents for Phantom Viewpoint VI0508

  • Page 1 Installation Manual for For Right and Left Hinged Doors Durable. Reliable. Attractive. For door openings up to 36” (914 mm) wide and 80 9/16” (2,047 mm) high Quick Easy Size Install...
  • Page 2 Congratulations and thank you for purchasing The Viewpoint Screen is designed and manufactured by Seiki Screen Systems, the world’s largest manufacturer of retractable screens. Phantom Screens, North America’s leading brand of retractable solutions, is proud to bring you these innovative products. Thanks to rigorous design and product testing, the Viewpoint Screen will provide years of dependable operation.

  • Page 3: Table Of Contents

    Attaching the Fixing Strip and Installing the Clips ... Service and Maintenance Hints ... For installation on a double hinged door (French Doors), you will need: two Viewpoint Screens and one Double Door Kit. Please refer to the Installation Manual within the “Double Door Kit”...

  • Page 4: Getting To Know The Viewpoint Screen

    Viewpoint Screen can still be installed by attaching a filler strip under the door frame to reduce the height of the door opening. Refer to page 6 for details. NOTE: The Viewpoint Screen can only be shortened by 4”...

  • Page 5: Parts And Tools

    NOTE: A chop saw can be used in place of a hacksaw provided that a bi-metal blade has been properly installed Parts and Tools Screen Housing Catch Frame Assembly (not required for a double door application) Sliding Bar Corner Cover Bottom Cap Carpenter Philips Electric drill...

  • Page 6: Measuring The Door Opening

    (or filler strip), and the top of the door sill at a point 1 3/4" (45 mm) from the front surface of the frame. Record this dimension in the box below labeled “H”.

  • Page 7: Cutting The Horizontal

    Cutting the Cutting the Horizontal Parts Calculate the correct cut off Lengths. Subtract inside door Maximum Opening frame width “W” Width 36” (914 mm) Cut from each part the cut off length provided by the calculation performed above. Top Rail...

  • Page 8: Installing The Bottom Rail And Preparing The Screen Housing Assembly

    Bottom Rail onto the door sill, placing the front edge of the Bottom Rail even with the face or front edge of the door frame on both sides of the opening. Preparing the Screen Housing Assembly 1. Before installing the Screen...

  • Page 9: Installing The Mounting Bracket

    Rail on the hinge side of the door. 3. Push the Mounting Bracket upwards, ensuring that the top of the Corner Cover is tight against the upper portion of the door frame. 4. Using a level, ensure that the Mounting Bracket is positioned plumb.

  • Page 10: Installing The Top Rail And Catch Frame

    Top Rail. Position it against the door frame on the opposite side of the Screen Housing Assembly. 2. Lift the Catch Frame upward into the Top Rail as far as it will go, and secure to the door frame using the provided wood screws. Catch Frame...

  • Page 11: Adjusting The Latch

    Latch. Push the entire mesh over to the Sliding Bar so that only the Tension Wires are visible in the opening of the door. Loosen the screw of the top most Tension Wire Adjuster. Slide it up or down until snug, without any sag in the Tension Wire.

  • Page 12: Attaching The Fixing Strip

    Fixing Strip Attaching the Installing the Clips Attach the Fixing Strip Insert one edge of the Fixing Strip into the Mounting Bracket on an angle, beginning at the top, and working toward the bottom. Again from the top, press the other edge of the Fixing Strip into the Mounting Bracket, working it into position all the way to the bottom so that it is now fully inserted into the Mounting Bracket.

  • Page 13: Service And Maintenance Hints

    The Viewpoint Screen is designed and engineered to be maintenance free. The following are some helpful hints to ensure the smooth operation of the Viewpoint Screen for years to come. • All moving components used in the Viewpoint Screen are manufactured from a mixture of nylon and other materials.
  • Page 14 Hotline Help The Viewpoint Screen was designed for easy sizing and installation. This Installation Manual provides a step by step guide through the entire process. If there are any questions during the installation of the Viewpoint Screen, please call toll free: 1-877-446-7180...
  • Page 15 Viewpoint Screen Limited Lifetime/Non-transferable Manufacturer’s Warranty The Viewpoint Screen is warranted by Seiki Screen Systems to be free of manufacturer’s defects in materials or workmanship, for as long as the original purchaser owns and or resides at that residence and that the product remains at its original point of installation.
  • Page 16 Designed & Manufactured by Seiki Screen Systems ™ Marketed and Distributed by Phantom Screens ® Seiki Screen Systems Call 1-877-446-7180 Or email: info@seikiscreensystems.com www.seikiscreensystems.com © 2008 Phantom Mfg. (Int’l) Ltd. & Seiki Screen Systems VI0508 Phantom Mfg. (Int’l) Ltd. Call 1-888-PHANTOM Or email: phantom@phantomscreens.com www.phantomscreens.com...
