Phantom Sure View SU0508L Installation Manual

Retractable screen solutions for left hinged doors openings up to 36” (914 mm) wide and 81 1/4” (2,064 mm) high
Hide thumbs

Advertisement

Table of Contents

Installation Manual for
For Left Hinged Doors
Durable. Reliable. Attractive.
For door openings up to 36" (914 mm) wide
and 81 1/4" (2,064 mm) high
Quick
and
Easy
Size
to
Install
and

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Sure View SU0508L and is the answer not in the manual?

Questions and answers

Related Manuals for Phantom Sure View SU0508L

Summary of Contents for Phantom Sure View SU0508L

  • Page 1 Installation Manual for For Left Hinged Doors Durable. Reliable. Attractive. For door openings up to 36” (914 mm) wide and 81 1/4” (2,064 mm) high Quick Easy Size Install...
  • Page 2 Congratulations and thank you for purchasing The Sure View retractable screen is designed and manufactured by Seiki Screen Systems, the world’s largest manufacturer of retractable screens. Phantom Screens, North America’s leading brand of retractable solutions, is proud to bring you these innovative products. Thanks to rigorous design and product testing, the Sure View Screen will provide years of dependable operation.

  • Page 3: Table Of Contents

    Service and Maintenance Hints ... For installations on double doors (French doors) you will need: one left Sure View Screen, one right Sure View Screen, and one Double Door Kit. Please refer to Installation Manual within the “Double Door Kit” prior to installation.

  • Page 4: Getting To Know The Sure View Screen

    Sure View Screen can still be installed by attaching a filler strip under the door frame to reduce the height of the door opening. Refer to page 6 for details. Is there enough Mounting Surface for the...

  • Page 5: Parts And Tools

    Before beginning, make sure that all these parts are included in the Sure View Screen package. Screen Housing Assembly Bottom Rail Type “A” (used on at door sills) Required Tools Hacksaw * Measuring tape 32tpi Carpenter Philips square screwdriver Level...

  • Page 6: Measuring The Door Opening

    (the furthest point away from the door). Measure from the top of the door frame to the door sill at a point 1 5/8” (42 mm) back from the outside edge of the door frame.

  • Page 7: Sizing The Sure View Screen

    Sure View Screen Sizing the If the door opening is smaller than 36” (914 mm) wide and 81 1/4” (2,064 mm) high, the Sure View Screen must be cut. Determine Length to be Cut from Top and Bottom Rails To determine the length to be cut from the Top and Bottom Rails,...

  • Page 8: Cutting The Top/Bottom Rail And Catch Frame

    Bottom Rail for installation. The Sure View Screen package comes with two Bottom Rails to accommodate both flat and angled door sills. Please refer to (B) to determine the correct Bottom Rail. 1. Using the same “Length to be cut” dimension...

  • Page 9: Cutting The Screen Housing Assembly

    Cutting the It is easy to cut right through the Screen Housing Assembly of the Sure View Screen using a chop saw or hacksaw. NOTE: All cutting will be done on the upper end of the Screen Housing Assembly. The Mounting Bracket on the Screen Housing Assembly is clearly labeled with CUT and NO CUT zones.

  • Page 10: Installing The Screen Housing Assembly

    If the mounting surface is greater than 1 5/8” (42 mm), the Mounting Bracket can be positioned anywhere on this surface. We recommend positioning the Mounting Bracket flush with the edge of the door frame (the furthest point away from the door.) 1.
  • Page 11 Installing the Attaching the Screen Housing Assembly 1. Place the front left corner of the Screen Housing Assembly in the outside edge of the Mounting Bracket. (C) 2. Pivot the Screen Housing along this point until the back of the Assembly snaps into the “L”...

  • Page 12: Installing The Top Rail

    (A) 3. Align the Top Rail so that the edge of the Top Rail End Cap closest to the door is in a straight line to the “L” shaped edge of the Mounting Bracket. This line should be at a 90º angle to the mounting surface on which the Mounting Bracket was attached.

  • Page 13: Installing The Catch Frame

    (D) 2. Using a level, adjust the Catch Frame along the mounting surface of the door frame to ensure that it is positioned plumb. It is important that the bottom of the Catch Frame fits tight to the door sill. (E) 3.

  • Page 14: Installing The Bottom Rail

    NOTE: If using the Angled Bottom Rail, ensure that it is oriented so that the top of the Bottom Rail is flat and level when placed on the door sill. 3. Position the other end so that the center of the Catch Frame aligns with the center of the Bottom Rail.

  • Page 15: Adjusting The Catch

    1. Loosen the screw on the Catch. 2. Move the Catch up and down to determine the position where the Latch makes a secure contact with the Catch. Tighten the screw on the Catch to secure it in place. (D) 3.

  • Page 16: Final Adjustments

    Adjustments Final Mesh Lock Adjuster Dial Lock Spring Tension Adjuster Dial Increase Spring Tension Adjusting the Mesh The Sure View Screen can be adjusted to reduce the amount of mesh discharged from the Screen Housing. This keeps the mesh tight to maintain the effectiveness of the Sure View Screen in keeping out unwanted insects.

  • Page 17: Service And Maintenance Hints

    The Sure View Screen is designed and engineered to be maintenance free. Please review these helpful hints to ensure the smooth operation of the Sure View Screen for years to come: • All moving components used in the Sure View Screen are manufactured from a mixture of nylon and other materials.
  • Page 18 Hotline Help The Sure View Screen was designed for easy sizing and installation. This Installation Manual provides a step by step guide through the entire process. If there are any questions during the installation of the Sure View Screen, please call toll free: 1-888-PHANTOM (1-888-742-6866)
  • Page 19 Sure View Screen Limited Lifetime/Non-transferable Manufacturer’s Warranty The Sure View Screen is warranted by Seiki Screen Systems to be free of manufacturer’s defects in materials or workmanship, for as long as the original purchaser owns and or resides at that residence and that the product remains at its original point of installation. Seiki Screen Systems will repair or replace at its discretion any component, within the terms and conditions of this warranty, which is deemed as being defective from the manufacturing process upon proof of purchase.
  • Page 20 Designed & Manufactured by Seiki Screen Systems ™ Marketed and Distributed by Phantom Screens ® Seiki Screen Systems Call 1-877-446-7180 Or email: info@seikiscreensystems.com www.seikiscreensystems.com © 2008 Phantom Mfg. (Int’l) Ltd. & Seiki Screen Systems SU0508L Phantom Mfg. (Int’l) Ltd. Call 1-888-PHANTOM Or email: phantom@phantomscreens.com www.phantomscreens.com...
