Sharkrf Ip Connector Server - SharkRF openSPOT User Manual

DMR transceiver

SharkRF IP Connector Server

connector
You can use this connector to accept connections from another openSPOT
device. This connector only supports 1 active connection, so if you want to link
more than 1 device, you can use our open source
Protocol Server. The protocol's documentation can be found on GitHub, so you
can also develop your own application for the openSPOT4.
The easiest way is to use the
Make sure that the UDP port used by this connector (by default it's 65100) is
correctly set up on your router (it's open on the firewall and is forwarded to the
openSPOT4's IP address).
All modem modes are supported by this connector, with automatic cross mode
conversion between the following modes:
DMR, C4FM (DN mode) and NXDN®, and also D-STAR® with the
openSPOT4 Pro
C4FM (VW mode) and P25
104
SharkRF IP Connector
Quick setup to set up this connector.
