Whirlpool IKEA DWF 406 Quick Reference Manual

GB DWF 406
On button
Off button
Rinse aid level indicator
Add rinse aid.
Salt level indicator
Add regeneration salt; only add
regeneration salt immediately before
starting a wash programme.
Programme Symbol
and Temperature
Crockery to be washed later.
Pre-wash
Lightly soiled crockery with no dried-on food.
Rapid 50° C
2)
Normally or heavily soiled crockery with dried-on food.
Bio Eco 50° C
Normally soiled crockery.
Universal 65° C
3)
Normally or heavily soiled crockery.
Normal 65° C
Heavily soiled pans and saucepans.
Intensive 70° C
1) Values may vary in relation to usage, e.g.: different loads, water
temperatures - above or below 15° C - as well as water hardness and power supply voltage etc.
2) Programme recommended when using detergents of type B (enzyme-based detergents).
Reference programme for energy label.
3) Programme recommended when using detergents of type A (non enzyme-based detergents).
Quick Reference Guide
Further indications are given in the pages to follow and in the user instructions.
Programme selection button
Start button
Indicator lamp lit while the dishwasher is operating.
Flashes when a fault occurs.
Switches off at the end of the programme.
Programme selection and
recommended load type
Half Load button
This function can be used with any programme.
The indicator lamp switches on: the wash cycle
is activated for the upper or lower rack only.
Place the detergent in the:
small large
compartment compartment
(Litres)
- - 5.0
- X 12.5 (10.5)
X X 16.0 (14.5)
- X 14.0 (12.0)
X X 20.0 (18.0)
X X 22.5 (19.0)
(We reserve the right to make technical modifications)
Option
1)
Consumption
Normal Load / (Half Load)
Water Energy Time
(kWh) (Min.)
(4.2) 0.02 (0.02) 9 (9)
0.90 (0.85) 65 (63)
1.22 (1.10) 91 (88)
1.50 (1.40) 73 (71)
1.63 (1.55) 98 (90)
1.75 (1.64) 93 (90)
5019 100 92209
