RESERATOR 1 V2
English Version
Visit our website (www.zalman.co.kr) and watch the RESERATOR 1 V2
installation video for an installation overview.
※ Please read this manual thoroughly before installation.
※ The specifications of this product and its components may change without prior notice to improve the performance thereof.
www.zalman.co.kr
www.zalmanusa.com
Advertisement
Related Manuals for ZALMAN RESERATOR 1 V2
Summary of Contents for ZALMAN RESERATOR 1 V2
- Page 1 All manuals and user guides at all-guides.com RESERATOR 1 V2 English Version Visit our website (www.zalman.co.kr) and watch the RESERATOR 1 V2 installation video for an installation overview. ※ Please read this manual thoroughly before installation. ※ The specifications of this product and its components may change without prior notice to improve the performance thereof.
- Page 2 7. Check for leaks on water block before the installation. Operational Notes 1. Use a power strip with a power switch, and connect both PC and Reserator 1 V2 to the power strip to allow simultaneous power ON/OFF switching. 2. Always turn on the water pump first before using the system.
-
Page 3: Table Of Contents
. The Reserator 1 V2 is a fanless water cooling system that unites the functions of a reservoir, radiator, and water pump into one system for easy operation. It is anodized and comes with a custom coolant to prevent corrosion. - Page 4 All manuals and user guides at all-guides.com RESERATOR 1 V2 1. 1 Reserator (Reservoir + Radiator + Water Pump) “Reserator” is a compound word derived from ‘Reservoir’ and ‘Radiator’ - it acts as a reservoir while radiating heat. This product works well with natural convection and integrates a water pump inside for convenience.
-
Page 5: Specifications
All manuals and user guides at all-guides.com RESERATOR 1 V2 2. Specifications 2. 1 Reserator (Reservoir+Radiator+Water pump) 1) Dissipation Area : 1.274㎡ 2) Weight : 6.5 kg 3) Dimensions : 150(L) x 150(W) x 592(H) mm 4) Material : Anodized Pure Aluminum 5) Max Coolant Capacity : 2.5ℓ... -
Page 6: Installation Overview
All manuals and user guides at all-guides.com RESERATOR 1 V2 3. Installation Overview Reserator CPU Water Block (ZM-WB4 Gold) Northbridge Water Block (ZM-NWB1, Optional) VGA Water Block (ZM-GWB3) I/O Bracket Quick Coupling Flow Indicator The specifications of any product may change without prior notice to improve performance. -
Page 7: Standard Components & Optional Components
All manuals and user guides at all-guides.com RESERATOR 1 V2 4. Components 4. 5 Coolant (ZM-G200) 1EA 4. 1 Reserator 1 Unit 4. 6 PVC Tube 4m 4. 2 CPU Water Block(ZM-WB4 Gold) 1SET 4. 7 I/O Bracket 1EA Please refer to the separately provided manual for the ZM-WB4 Gold. - Page 8 All manuals and user guides at all-guides.com RESERATOR 1 V2 Optional Components Northbridge Water Block (ZM-NWB1) ● ● This anodized, pure aluminum block is built for high performance cooling, and is designed for Motherboard compatibility with a wide variety of northbridge chipsets.
-
Page 9: Installation Guide
All manuals and user guides at all-guides.com RESERATOR 1 V2 5. Installation Guide 5. 1 Check for Leaks Before installing the product on a PC, check each Water Block and the Reserator for leaks. 5. 2 Determine the Placement of the Reserator The Reserator’s placement should be... - Page 10 All manuals and user guides at all-guides.com RESERATOR 1 V2 PVC Tube 5. 6 Connect the CPU Water Block and the VGA Water Block CPU Water Block 1) As shown in the diagram, connect the two water blocks with a PVC tube.
- Page 11 All manuals and user guides at all-guides.com RESERATOR 1 V2 5. 9 Connect the Flow Indicator with the Reserator’s Base OUT 1) Connect one end of the PVC Tube to the Flow Indicator. 2) Insert a Tube Clamp to the other end of the tube, connect a Quick Coupling Insert, then fasten with the Tube Clamp.
- Page 12 All manuals and user guides at all-guides.com RESERATOR 1 V2 5. 11 Confirm Proper Installation 1) Check that the product is placed properly (i.e. conforms to section 5.2). 2) Confirm that the coolant circulation path is correct as shown below.
- Page 13 All manuals and user guides at all-guides.com RESERATOR 1 V2 5. 13 Leakage Inspection and Test Run 1) Turn off the PC’s power completely before starting leakage inspection. 2) Turn on the water pump. If the coolant does not circulate properly, turn the pump on and off repeatedly to eliminate air bubbles.
-
Page 14: Pump Replacement And External Water Pump Installation
All manuals and user guides at all-guides.com RESERATOR 1 V2 6. Pump Replacement and External Water Pump Installation If the integrated water pump is broken or you need a water pump with higher capacity, you can replace the water pump or install an external water pump as shown below. - Page 15 All manuals and user guides at all-guides.com RESERATOR 1 V2 5) Take out the Power Cable Sealing Bolt A Water Pump Pull the Water Pump power cable out through the Cable Hole. Power Cable 6) Remove the Cable Fitting Take the Cable Fitting out of the hole as...
- Page 16 2) Check that the chosen water pump’s holes are compatible with the provided PVC tubes (12 x 8 mm). 3) Zalman Tech is not responsible for performance degradation or malfunction of a system that results from using an external water pump.
-
Page 17: Zalman Noise Prevention System
RESERATOR 1 V2 7. Zalman Noise Prevention System Stable performance and noiseless liquid cooling system can both be achieved with the use of Zalman’s Noiseless Power Supply, Hard Disk Cooler and Noiseless Case Fan, Northbridge Water Block. Noiseless Power Supply... - Page 18 All manuals and user guides at all-guides.com...
