RESERATOR 2
English Version
Visit our website (www.zalman.co.kr) and watch the Reserator 2 installation
video for an installation overview.
※ Please read this manual thoroughly before installation.
※ The specifications of this product and its components may change without prior notice to improve the performance thereof.
www.zalman.co.kr
www.zalmanusa.com
Advertisement
Related Manuals for ZALMAN RESERATOR 2
Summary of Contents for ZALMAN RESERATOR 2
- Page 1 All manuals and user guides at all-guides.com RESERATOR 2 English Version Visit our website (www.zalman.co.kr) and watch the Reserator 2 installation video for an installation overview. ※ Please read this manual thoroughly before installation. ※ The specifications of this product and its components may change without prior notice to improve the performance thereof.
- Page 2 7. Check for leaks on Water Blocks before installation. Operational Notes 1. Reserator 2 simultaneously operates with the PC. The power must first be supplied to the AC power cable before turning on the PC because it uses an AC pump.
-
Page 3: Table Of Contents
The Reserator 2 is a noiseless and fanless water cooling system that incorporates a and Flow Indicator in the front section, a high efficiency heatsink in the middle section, and a water tank and water pump in the back section which allows easy installation and use. - Page 4 All manuals and user guides at all-guides.com RESERATOR 2 1. 1 Reserator (Reservoir + Radiator + Water Pump) “Reserator” is a compound word derived from ‘Reservoir’ and ‘Radiator’- it acts as a reservoir while radiating heat. This product works well with natural convection and integrates a Water Pump inside for convenience.
-
Page 5: Specifications
All manuals and user guides at all-guides.com RESERATOR 2 2. Specifications 2. 1 Reserator (Reservoir + Radiator+Water pump) 1) Dissipation Area : 1.5㎡ 2) Weight : 7 kg 3) Dimensions : 76(L) x 436(W) x 369(H) mm 4) Material : Anodized Pure Aluminum 5) Max Coolant Capacity : 1.25ℓ... -
Page 6: Installation Overview
All manuals and user guides at all-guides.com RESERATOR 2 3. Installation Overview DC Cable Power Supply 4-Pin Connecter Water Block Water Block I/O Bracket Quick Coupling AC Cable The specifications of any product may change without prior notice to improve performance. -
Page 7: Standard Components And Optional Components
All manuals and user guides at all-guides.com RESERATOR 2 4. Components 4. 6 Coolant (ZM-G300) 1EA 4. 1 Reserator 2 - 1 UNIT 4. 7 PVC Tube 4m 4. 2 CPU Water Block (ZM-WB4 Gold) 1SET 4. 8 I/O Bracket 1EA Please refer to the separately provided manual for the ZM-WB4 Gold. - Page 8 All manuals and user guides at all-guides.com RESERATOR 2 Optional Components Northbridge Water Block (ZM-NWB1) ● ● This anodized, pure aluminum block is built for high performance cooling, and is designed for Motherboard compatibility with a wide variety of northbridge chipsets.
-
Page 9: Installation Guide
All manuals and user guides at all-guides.com RESERATOR 2 5. Installation Guide 5. 1 Determine the Placement of the Reserator The Reserator’s placement should be determined ( ( O O ) ) ( ( O O ) ) in relation to the position of the PC. - Page 10 All manuals and user guides at all-guides.com RESERATOR 2 5. 4 Reserator’s Coolant Circulation 1) The purpose of connecting the Jump Cable of the power supply’s main connector (20P/24P) is to receive direct current (12V) needed for the test and leakage inspection.
- Page 11 All manuals and user guides at all-guides.com RESERATOR 2 5. 5 Install the CPU Water Block (ZM-WB4 Gold) 1) Refer to the manual included with the ZM-WB4 Gold for installation instructions. 2) If physical interference occurs while installing the Water Block, then stop the installation.
- Page 12 All manuals and user guides at all-guides.com RESERATOR 2 4) Plug the Quick Coupling Insert into the Base OUT located on the lower part of the Reserator Base OUT, Quick Coupling Body 5. 10 Connect DC Power Cable 1) Fit the DC Cable’s Cord Bushing into the groove of the I/O Bracket, and fasten the I/O Bracket with the use of Bolts.
- Page 13 All manuals and user guides at all-guides.com RESERATOR 2 5. 12 Installing the VGA RAM Water Block 1) To install the VGA RAM Water Block, connect as shown in the diagram below. 2) Remember to install Tube Clamps on the PVC Tubes during installation.
- Page 14 All manuals and user guides at all-guides.com RESERATOR 2 5) Check for leakage at each connector. Leakage can lead to short-circuit and damage of the motherboard and other components. 6) If leakage occurs, immediately stop the pump, clean the leakage area with tissue paper, and reassemble the leakage area.
-
Page 15: External Water Pump Installation
2) Check that the chosen Water Pump°Øs holes are compatible with the provided PVC tubes (12 x 8 mm). 3) Zalman Tech is not responsible for performance degradation or malfunction of a system that results from using an external Water Pump. -
Page 16: Exploded View
All manuals and user guides at all-guides.com RESERATOR 2 7. Exploded View Reservoir Cover Light/Reset Button Front Panel Heat Sink Front Body Water Pump Flow Indicator Quick Coupler Body Reservoir Base Support The specifications of any product may change without prior notice to improve performance. -
Page 17: Zalman Noise Prevention System
RESERATOR 2 8. Zalman Noise Prevention System Stable performance and noiseless liquid cooling system can both be achieved with the use of Zalman’s Noiseless Power Supply, Hard Disk Cooler and Noiseless Case Fan, Northbridge Water Block. Noiseless Power Supply Heatpipe HDD Cooler... - Page 18 All manuals and user guides at all-guides.com...
