ARROWELD ARW-TVP Instruction Manual

Thank you for buying a ARROWELD test stand. We hope you are pleased with your high quality test stand with its big
functional range. If you have any queries, wishes or helpful suggestions, do not hesitate to call our service number.
1.

Included in delivery

- ARW-TVP
- Various hooks
2.

Warning

Intended use
The instrument you have acquired serves to determine the measuring value of the material to be measured. It is intended to be
used as a "non-automatic" instrument, i.e. the material to be measured is manually and carefully attached at the instrument. The
measuring value can be read off after a stable measuring value has been obtained.
Be careful about the limit load of test stand and force gauge. Do not go over the maximum force.
3.

Technical Specifications

Capacity: up to 500 Newton
Unit net weight: 10,5 kg
Minimum height above base plate: 115 mm
AS, 03.12.2010
Instruction Manual
ARW-TVP
BA_GB_TVP.doc
ARROWELD ITALIA Spa
Via M. Pasubio, 137
36010 Zanè (VI)-(Italia)
Tel +39 0445 492313
Fax +39 0445 491365
E-mail:info@strumentieservizi.com
Page 1 of 2
