PACKAGE CONTENTS
D
G
I
F
PART DESCRIPTION
A Side-cover knob
B Side cover
C Guide bar
D Saw chain
E Oil-tank cap
F Oil tank
G Chain sheath
H Threaded sleeve
I Threaded connection
WARNING
• Remove the tool from the package and examine it carefully. Do not discard the carton or any
packaging material until all parts have been examined.
• If any part of the tool is missing or damaged, do not attach the battery to use the tool until
the part has been repaired or replaced. Failure to heed this warning could result in serious
injury.
C
A
B
I
K
Q
E
O
J
N
L
M
PART DESCRIPTION
J Extension segment
K Front handle
L Lock-off button
M Trigger switch
N Rear handle
O Chain-tensioning knob
P Power-head segment
Q Rear segment
