ITEM #2220273/2220274
80 V LITHIUM-ION CORDLESS POLE SAW
MODEL #KPS 1081-06
Español p. 26
ATTACH YOUR RECEIPT HERE
Serial Number
Purchase Date
Questions, problems, missing parts? Before returning to your retailer, call our customer
service department at 1-888-3KOBALT (1-888-356-2258), 8 a.m. - 8 p.m., EST,
Monday - Sunday.
RR20009
1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Kobalt KPS 1081-06
Summary of Contents for Kobalt KPS 1081-06
- Page 1 ITEM #2220273/2220274 80 V LITHIUM-ION CORDLESS POLE SAW MODEL #KPS 1081-06 Español p. 26 ATTACH YOUR RECEIPT HERE Serial Number Purchase Date Questions, problems, missing parts? Before returning to your retailer, call our customer service department at 1-888-3KOBALT (1-888-356-2258), 8 a.m. - 8 p.m., EST, Monday - Sunday.
-
Page 2: Table Of Contents
TABLE OF CONTENTS Product Specifications ......................3 Package Contents ........................ 4 Symbols ..........................6 Safety Information ......................... 8 Preparation .......................... 11 Assembly Instructions ......................12 Operating Instructions ......................14 Care and Maintenance ....................... 16 Troubleshooting ........................24 Warranty ..........................24 Replacement Parts List ....................... -
Page 3: Product Specifications
PRODUCT SPECIFICATIONS SPECIFICATIONS Type Cordless, Battery-powered Battery 80 V Lithium-ion Bar length 10 in. (254 mm) Chain pitch 1/4 in. (6.3 mm) Chain type 25AP058X Guide bar type 100SDAA041 Weight (without battery) 9.8 lbs. (4.45 kg) The recommended ambient temperature range: Item Temperature Appliance storage temperature range... -
Page 4: Package Contents
PACKAGE CONTENTS... - Page 5 PACKAGE CONTENTS PART DESCRIPTION QUANTITY PART DESCRIPTION QUANTITY Lower Tube Chain Tension Screw Bar Cover Handle Pole Extension pole Saw Chain Power head pole Wrench Battery Release Button Strap Rear Handle Scabbard Lock-off Lever Trigger Switch Collar Upper Tube Oil Cap Bar Cover Knob...
-
Page 6: Symbols
SYMBOLS Some of the following symbols may be used on this product. Please study them and learn their meaning. Proper interpretation of these symbols will allow you to operate the product better and safer. SYMBOL DESIGNATION EXPLANATION Volts Voltage Amperes Current Hertz Frequency (cycles per second) - Page 7 SYMBOLS The following signal words and meanings are intended to explain the levels of risk associated with this product. SYMBOL SIGNAL MEANING Indicates an imminently hazardous situation, which, if not avoided, will DANGER result in death or serious injury. Indicates a potentially hazardous situation, which, if not avoided, could WARNING result in death or serious injury.
-
Page 8: Safety Information
A guard or other part that is damaged should be properly repaired or replaced by an authorized service center unless indicated elsewhere in this manual. • Use only Kobalt 80-volt batteries (KB 280-06, KB 2580-06, KB 380-06). - Page 9 SAFETY INFORMATION • Use only Kobalt charger (KRC 80-06, KRC 30-06). POLE SAW SAFETY WARNINGS • Keep all parts of the body away from the saw chain. Do not remove cut material or hold material to be cut when blades are moving. Make sure the switch is off when clearing jammed material.
- Page 10 SAFETY INFORMATION • Have servicing performed by a qualified repair person using only identical replacement parts. This will ensure that the safety of the product is maintained. • Do not modify or attempt to repair the appliance or the battery pack (as applicable) except as indicated in the instructions for use and care.
-
Page 11: Preparation
PREPARATION Before beginning assembly of product, make sure all parts are present. Compare parts with package contents list. If any part is missing or damaged, do not attempt to assemble the product. Helpful Tools: Wrench for tightening the chain and connecting the poles. UNPACKING •... -
Page 12: Assembly Instructions
ASSEMBLY INSTRUCTIONS 1. Connecting the poles a. Insert the extension pole (C) into the handle pole (B) and slide together. b. Lower the collar (I) on the extension pole (C) to the threaded base on the handle pole (B) and rotate clockwise to secure. - Page 13 ASSEMBLY INSTRUCTIONS 3a. To install the battery: a. Align the battery (not included) with the battery compartment. b. Insert battery into the battery compartment until battery release button (E) locks into place. You should hear a “click” once it is installed. 3b.
-
Page 14: Operating Instructions
OPERATING INSTRUCTIONS To turn on and off • Slide the lock-off lever (G). Squeeze the trigger switch (H) to start. • Release the trigger switch (H) to stop. Note: The lock-off lever must be engaged before the trigger is active. Once the trigger is engaged, release the lock-off lever. - Page 15 OPERATING INSTRUCTIONS • Release the trigger as soon as the cut is completed. Failure to follow proper cutting procedures will result in the bar and chain binding and becoming pinched or trapped in the limb. If this should happen: • Stop the motor and remove the battery from the pole saw.
-
Page 16: Care And Maintenance
OPERATING INSTRUCTIONS • Keep the tree between you and the chain while limbing. Cut from the side of the tree opposite of the branch you are cutting. • Do not cut from a ladder; this is extremely dangerous. Leave this operation for professionals. •... - Page 17 CARE AND MAINTENANCE Chain & Bar Assembly During use, the chain will stretch and become dull. Debris and saw dust can also collect underneath the bar cover. Use the following steps to maintain your pole saw and chain. • Release chain tension by turning the chain tension screw (M), located behind the bar and chain, counterclockwise with the wrench (Q).
- Page 18 CARE AND MAINTENANCE • To replace the bar and chain, loop the chain over the sprocket and place the bar against the bar stud slot. Bar Stud Slot Sprocket • Ensure that the chain tensioning pin is located in the tensioning hole on the chain bar.
- Page 19 CARE AND MAINTENANCE • Using the wrench (Q) on the chain tension screw (M), turn clockwise. • Turn clockwise until there is enough play that the chain can be pulled away from the bar, but not so much that the runners can be pulled out of the bar. •...
- Page 20 CARE AND MAINTENANCE Chain tension • Stop the motor and remove the battery before setting the chain tension. Turn the bar cover knob counterclockwise to loosen the bar cover but do not remove the bar cover. Flats Turn the chain tensioning screw clockwise to tension chain.
- Page 21 CARE AND MAINTENANCE Chain Oiler WARNING To avoid possible serious injury, stop the motor and remove the battery from the pole saw before replacing the bar, chain or performing any maintenance operation. • Use Premium Bar and Chain Lubricant. It is designed for Bar Lube Reservoir chains and chain oilers and is formulated to perform over a wide temperature range with no dilution required.
- Page 22 CARE AND MAINTENANCE Chain maintenance For smooth and fast cutting, the chain needs to be maintained properly. The following conditions indicate that the chain requires sharpening: • Wood chips are small and powdery. Raker (Depth Gauge) Clearance • Chain must be forced through the wood during cutting. •...
- Page 23 CARE AND MAINTENANCE • Using light but firm pressure, stroke towards the front corner of the tooth. Lift file away from the steel on each return stroke. • Put a few firm strokes on every tooth. File all left hand cutters in one direction.
-
Page 24: Troubleshooting
This Kobalt 80 V Lithium-ion pole saw is warranted to the original purchaser from the original purchase date for five (5) years subject to the warranty coverage described herein. This Kobalt 80 V Lithium-ion pole saw is warranted for the original user to be free from defects in material and workmanship. -
Page 25: Replacement Parts List
REPLACEMENT PARTS LIST For replacement parts, call our customer service department at 1-888-3KOBALT (1-888-356-2258), 8 a.m. - 8 p.m., EST, Monday - Sunday. PART DESCRIPTION PART # Oil Tank Cap C1102459-00 Bar Cover 341031726D Wrench 333101726 Printed in China...
