HEAVY DUTY

MULCHER

BE-TMSXXXX

OPERATIONS & PARTS MANUAL

FOR MODELS:

• BE-TMS1400

• BE-TMS1550

• BE-TMS1850

• BE-TMS2050

• BE-TMS2300

• BE-TMS2600

PURCHASE DATE

MODEL NO.

SERIAL NUMBER

DEALER

Table of Contents

Need help?

Do you have a question about the BE-TMS Series and is the answer not in the manual?

Questions and answers

Summary of Contents for AGRI EASE BE-TMS Series

Page 1 HEAVY DUTY MULCHER BE-TMSXXXX OPERATIONS & PARTS MANUAL FOR MODELS: • BE-TMS1400 • BE-TMS1550 • BE-TMS1850 • BE-TMS2050 • BE-TMS2300 • BE-TMS2600 PURCHASE DATE MODEL NO. SERIAL NUMBER DEALER...
Page 2: Table Of Contents
TABLE OF CONTENTS INTRODUCTION TECHNICAL DATA SAFETY INSTALLATION USAGE INSTRUCTIONS MAINTENANCE TROUBLESHOOTING EXPLODED VIEW & PARTS LIST...
Page 3: Introduction
MULCHER DESCRIPTION BE-TMSxxxx 1.5. Mulcher description INTRODUCTION With reference to Fig. 1, the Mulcher is a machine designed and built exclusively for mulching directly on site (Orchards, vineyards and kiwi plantations) by crushing vegetation; it mulches prunings, grass, straw, tobacco, Mulcher description artichokes, beets, cotton and pruning residues.
Page 4 INTENDED USE INTENDED USE BE-TMSxxxx Allowed uses The Mulcher has been designed and built to mulch prunings, grass, straw, tobacco, artichokes, beets, cotton and pruning residues of orchards, vineyards and kiwi plantations. When the Mulcher works it guarantees the 1.6. Intended use required level of safety even in the presence of an insignificant malfunction of its components or hazardous 1.6.1.
Page 5: Technical Data
Dimensions Work Power Mass Model N. hammers TECHNICAL DATA (W x L x H) requested (cm) (HP) (kg) (cm) TMS 1400 60 - 70 165x120x115 POWER DIMENSIONS TMS 1550 60 - 80 180x120x115 MODEL WORK (CM) N. HAMMERS MASS (KG) REQUESTED (HP) (WXLXH CM) TMS 1850...
Page 6 EC marking of the Mulcher Directive 2006/42/EC specifies the minimum conditions with which a machine can be placed on the EU market. All machines can only be marketed and put into service if the health and safety of persons, domestic animals or property are not affected.
Page 7 GENERAL SAFETY AND ACCIDENT PREVENTION STANDARDS Level of danger The safety of the operator and exposed persons is the main concern of the designer and the manufacturer of the machine. When designing a new machine, one tries to plan for all possible danger situations and risks connected to using the machine, adopting the steps necessary to make the equipment as safe as possible.
Page 8 Braber declines all responsibility for damage caused by not complying with the safety and injury prevention regulations described below. Braber also declines any responsibility for damage caused by improper use of the machine and/or as a result of modifications made without authorization by the manufacturer. Danger plates and warning The Mulcher is equipped with pictograms (labels) warning about residual risks present on the machine that it was not possible to eliminate.
Page 9 DANGER PLATES & WARNINGS CONT. BE-TMSxxxx BE-TMSXXXX USER MANUAL...
Page 10 Figure 4 shows an indication of the precise points on the machine where labels are usually applied by the manufacturer. Figure 4 shows an indication of the precise points on the machine where labels are usually applied by the manufacturer. Model No.
Page 11 and disposal of lubricants and products used for machine cleaning and maintenance, observing the recommendations of the manufacturer of those products. • If replacing worn parts or during demolition, one must follow anti-pollution laws foreseen in the country where the Mulcher is used. •...
Page 12 • It is forbidden to abandon the Mulcher and leave it unattended. The machine and the work area should always be monitored. • It is forbidden to transport persons or items on board the Mulcher while driving with the tractor. •...
Page 13 Safe maintenance In order to guarantee safe maintenance of the Mulcher it is necessary to respect the following provisions: • It is prohibited to remove or tamper with the safety devices. • Periodically check safety device integrity and operation. • Periodically check screws and bolts tightness. •...
Page 14: Installation
WARNING The machine must be lifted with maximum care and by using lifting devices suitable for the weight and size of the same. WARNING Due to the danger of this operation, it must be performed by expert and responsible personnel. For the lifting device to be used it is mandatory to comply with the safety regulations prescribed by the laws in force in the country where the machine is used.
Page 15 WARNING Clean and clear the installation area from any obstruction before starting to work. The area must be speciﬁcally closed o and personnel not assigned to the works must be made to Application to the tractor move away. The available means must be veriﬁed to be intact and suitable. The operator must also tighten all the bolts and ﬁttings properly, using suitable tools.
Page 16 Fig. 7 Cardan shaft Braber does not include the cardan shaft in supply. It is therefore necessary to purchase it paying careful attention to its length and section. Work inclination of the cardan shaft must be as small as possible (max 10 from the horizontal line): this favors its durability and that of the Mulcher.
Page 17 CARDAN SHAFT BE-TMSxxxx 10÷15 1/3 L.max Cm 4 L.min. 1/3L Fig. 8 The Mulcher is fitted with a free-wheel in the transmission box and can also be applied to a crawler tractor The Mulcher is ﬁtted with a free-wheel in the transmission box and can also be applied to a crawler tractor or or in any case with no double clutch, without the danger that the inertia of the rotor prevents stopping the in any case with no double clutch, without the danger that the inertia of the rotor prevents stopping the Mulcher / tractor assembly.
Page 18: Usage Instructions
4.1. Before use Prior to starting up the Mulcher, carry out the following operations; -- Check that all the screws and nuts are fastened, especially those that secure the hammers; USAGE INSTRUCTIONS -- Check that the cardan shaft is inserted correctly between the multiplier and the tractor PTO and also che the operation of the hydraulic pump and the distributor.
Page 19 USAGE INSTRUCTIONS CONT. BE-TMSxxxx 4.2.2. Adjustment of working height Fig. 10 To adjust the working height, raise or lower the support sliders and the idle roller until obtaining the Adjustment of working height desired position. To correctly adjust the working height of the Mulcher, it is necessary: To adjust the working height, raise or lower the support sliders and the idle roller until obtaining the -- To gradually and completely lower the Mulcher, with the tractor o and the emergency brake on, using the desired position.
Page 20 4.2.3. Adjustment of Mulcher working position It is possible to work with the Mulcher both in a lateral and central position according to requirements. Adjustment of Mulcher working position The machine is already equipped with a mechanical lateral movement which can be replaced with a hydraulic It is possible to work with the Mulcher both in a lateral and central position according to requirements.
Page 21 Fig. 12 After use A few guidelines must be complied with when the work is complete, in order to make sure the Mulcher is stable when released from the tractor: • Move to the recovery area of the Mulcher, making sure that the supporting surface is flat and free from obstructing material.
Page 22 Safety devices There are safety devices in the Mulcher to safeguard the operator. WARNING The safety devices must not be tampered or excluded. They should always be kept in perfect working order. The following are installed: • A fixed protection - carter - cardan protection covers both crosses and prevents hands from being introduced into the rotating area of the cardan shaft.
Page 23 -- Before restarting the Mulcher after lubrication and/or maintenance, it is mandatory to wait for the authorization of the mechanical maintenance technician who must verify that: Before restarting the Mulcher after lubrication and/or maintenance, it is mandatory to wait for the •...
Page 24: Maintenance
The hammers with which the Mulcher is equipped are suitable for working on grounds of normal conformation. It is mandatory to check their integrity and the degree of wear every day. When faults or deformation occur in the hammers during work, it is mandatory to replace them immediately. Replacing a single hammer is generally not recommended.
Page 25 5.1.2. Belt maintenance The driving force is transmitted to the hammers (or cutters) holder rotor of the Mulcher by belts with adjustable tension. Periodically, or if the belts malfunction or slip, check the tension of the transmission belts from the appropriate slit and, if necessary, replace them.
Page 26 5.3. Lubricants With reference to Fig. 15, the following lubricants are to be used for the di erent parts of the machine: WARNING -- For the transmission box (1): SHELL SPIRAX S2 A 80W-90 or equivalent responding the It is strictly prohibited to clean the Mulcher with water or other liquid substances. API –...
Page 27: Troubleshooting
TROUBLESHOOTING SEARCH FOR ANOMALIES If the Mulcher malfunctions, search the causes and the solution of the problems in the following table: PROBLEM CAUSE REMEDY Slightly raise the Mulcher from the Mulcher too low Excessive grinding of the product ground, adjusting the height to be cut Forward speed too slow Increase the advancing speed...
Page 28: Exploded View & Parts List
EXPLODED VIEW & PARTS LIST BE-TMSXXXX USER MANUAL...
Page 29 REF PART NO DESCRIPTION REF PART NO DESCRIPTION 3230919 Full Body Forage Harvester TMS 1400 5400112 Cardan Protection Cap Art.36/211 3230685 Full Body Forage Harvester TMS 1550 5213009 Scraper TMS 1400 3230686 Full Body Forage Harvester TMS 1850 5213001 Scraper TMS 1550 3230687 Full Body Forage Harvester TMS 2050 5213002...
Page 30 REF PART NO DESCRIPTION REF PART NO DESCRIPTION Screw TE M 20x133 Special 10.9 TMS 1400 2050182 Right Copper Greasing Kit For Mulcher (Until 2018) 5385041 O-Ring 3.53x107.5 OR4425 Screw TE M 20x133 Special 10.9 TMS 1550 5227711 Oil Seal Cover Ø55 (Until 2018) 5380009 Sealing ring TC 55-100-10...
Page 31 BE-TMSXXXX USER MANUAL...
Page 32 B RA B E R EQ .CO M WGSALES@BRABEREQ.COM PHONE: 604-850-7770 FAX: 604-850-7774 TOLL FREE PHONE: 1-877-588-3311 TOLL FREE FAX: 1-800-665-7334 BE-TMSXXXX USER MANUAL...
