Related Manuals for AGRI EASE BE-TS Series
Summary of Contents for AGRI EASE BE-TS Series
- Page 1 BE-TSxx Rotary Tiller Operations & Parts Manual For Models: • BE-TS120 • BE-TS140 • BE-TS160 Purchase Date Model No. Serial No. Dealer...
-
Page 2: Introduction And Safety
INTRODUCTION & SAFETY BE-TSxx Thank you for purchasing your Tiller. Your Rotary Tiller is designed to be used on 540 RPM tractors. It is important to properly maintain and keep in place all safety guards and shields that came with your tiller. SAFETY Read and understand this manual and all safety signs before operating and maintaining. -
Page 3: Safety Signal Words
SAFETY SIGNAL WORDS BE-TSxx Note the use of the signal words DANGER, WARNING and CAUTION with the safety messages. The appropriate signal word for each has been selected using the following guidelines: DANGER!: Indicates an imminently hazardous situation that, if not avoided, will result in death or serious injury. -
Page 4: Safety Decal Care
SAFETY DECAL CARE BE-TSxx • Keep safety signs clean and legible at all times. • Replace safety signs that are missing or have become illegible. • Replaced parts that displayed a safety sign should also display the current sign. • Safety signs are available from your Local Dealer. HOW TO INSTALL SAFETY SIGNS •... -
Page 5: During Operation
DURING OPERATION BE-TSxx • Children should not be allowed on the product. • Clear the area of small children and bystanders before moving the feeder. • If using a towing unit, securely attach feeder by using a hardened 3/4” pin, a metal retainer and safety chains if required. -
Page 6: Highway And Transport Operations
HIGHWAY AND TRANSPORT OPERATIONS BE-TSxx • Adopt safe driving practices: • Keep the brake pedals latched together at all times. NEVER USE INDEPENDENT BRAKING WITH MACHINE IN TOW AS LOSS OF CONTROL AND/OR UPSET OF UNIT CAN RESULT. • Always drive at a safe speed relative to local conditions and ensure that your speed is low enough for an emergency stop to be safe and secure. -
Page 7: Operation
OPERATION BE-TSxx Before attaching the rotary tiller to the tractor, check the unit to ensure there is oil in the top and side gearbox. See Maintenance Section for lubricant specifications. Before beginning operation, check oil and grease points. Oil Level: Top gear box 1-1/2” from the end of the dip stick. When sitting slightly tilted forward, oil should be at the bottom of the drain plug on the side gearbox cover. - Page 8 OPERATION (CONT.) BE-TSxx Slip clutches have adjustable torque settings. The torque setting varies with the di erent compression of each spring. All the springs should have an equal amount of compression. IMPORTANT: Do not over-tighten the compression nuts as this may impair performance or cause premature wearing of the slip clutch.
-
Page 9: Following Operation
FOLLOWING OPERATION BE-TSxx • Following operation, or when unhitching, stop the tractor or towing vehicle, set the brakes, disengage the PTO and all power drives, shut o the engine and remove the ignition keys. • Store the unit in an area away from human activity. •... -
Page 10: Maintenance
MAINTENANCE BE-TSxx 8 Hours: • Grease the Rotor support (GP grease TXG and YCT only) • Grease PTO shaft cross & bearings (GP grease) • Check Hardware for tightness 16 Hours: • Check oil level in center gearbox (90wt) • Check oil level in side gearbox (140wt) •... -
Page 11: Parts Diagram
PARTS DIAGRAM BE-TSxx... -
Page 12: Parts Breakdown
PARTS BREAKDOWN BE-TSxx REF NO. PART NO. DESCRIPTION REF NO. PART NO. DESCRIPTION Bolt M10x25 Shim GB/T5783-2000 Side Panel Bracket TS58-01-01-00 Frame Weldment 58 TS66-02-09 Input Gear - Side Drive TS66-02-08 Output Gear Shim TS66-01-01-00 Frame Weldment 66 TS72-01-01-00 Frame Weldment 74 TS58-02-10 Drive Shaft 58 TS66-02-01... - Page 13 PARTS BREAKDOWN (CONT.) BE-TSxx REF NO. PART NO. DESCRIPTION REF NO. PART NO. DESCRIPTION GB/T5783-2000 GB/T5783-2000 Bolt - End Cap Right Side Bolt - Bearing Support (Left Side) GB/T5786-2000 M10X1 Grease Fittings Blade Bolt - 12x35 Fine Thread Hex Nut M12 TS66-05-01 Pin - Stand Lock Washer 12mm...
- Page 14 PARTS BREAKDOWN - PTO SHAFT BE-TSxx REF NO. PART NO. DESCRIPTION REF NO. PART NO. DESCRIPTION Complete Female End PTO Shielding DP1075-40 PTO Yoke Series 40 DP1074F-40 Series 20-40 (Tractor End) Complete Female End PTO Shielding DP1075-60 PTO Yoke Series 60 DP1074F-60 Series 60 (Tractor End) Complete Female End PTO Shielding...
