CIGAR OASIS ULTRA 3.0 Quick Start Manual

ASSEMBLY & STARTING YOUR CIGAR OASIS UKTRA 3.0
1) Remove all contents from the box and remove all plastic
wrap.
2) Locate the water cartridge which is pre-filled with distilled
water and remove tape.
3) Put the CIGAR OASIS ULTRA 3.0 together by lining up the
tab on the cartridge with the slot near the ULTRA label on
the unit. Connect the ribbon cable
ULTRA unit A. The flat part of the ribbon cable will slide out
the side of the humidor.
4) Connect the Ribbon Cable
5) Then connect C to the Adapter
Cartridge Refill Instructions
1) Fill a bowl with distilled water only and submerge the
cartridge in it for 4 minutes.
2) Take the cartridge out and let it stand for another minute.
3) Empty all remaining water out of the cartridge so only damp
foam remains. **No water should drip out when the
cartridge is held upside down**.
4) Dry off the cartridge and put the unit back together.
All manuals and user guides at all-guides.com
A to the port on the
B to the Micro USB cable B.
C and plug into an outlet.
USING YOUR CIGAR OASIS ULTRA 3.0
Once the unit is put together and plugged in, it turns on after
a few seconds of powering up and then it will read the
current humidity. The unit is factory preset at 70% humidity.
As soon as the humidity drops below 70% the fan will come
on to add moisture to the humidor.
To raise or lower the humidity settings use the UP or DOWN
arrows.
When the unit needs to be refilled with distilled water, the
Low Water and Alert icons will flash on display.
When the cartridge is refilled and the unit gets to the setpoint
the icons will shut off.
Change Temperature Between Fahrenheit and Celsius
1) Hold the CIRCLE button until the F or C start flashing.
2) Press the UP arrow to select Celsius or Fahrenheit.
3) Hold the CIRCLE button down until F or C stop flashing to
save the changes.
Calibrate Humidity
1) Hold the CIRCLE and UP arrow until the screen displays U.
2) Use the UP and DOWN arrows to raise or lower humidity +-
9%.
3) Hold the CIRCLE and UP arrow to save the changes.
Set UP Wi-Fi
If you would like to have access to your ULTRA 3.0 from your
phone anywhere in the world download our Cigar Oasis
App.
instructions in the app to set up. While setting up you will be
prompted to download a Setup App to connect to your network.
Create an account and follow the
