Everfine EMS61000-2A User Manual

Esd generator
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
EMS61000-2A
ESD GENERATOR
USER'S MANUAL
V 4.02
EVERFINE Corporation (Stock Code: 300306)
ADD ： Bldg.1 #669 Binkang Rd., Binjiang Hi-Tech
Zone, Hangzhou（310053）, China
Tel ：86-571-86698333
Fax ：86-571-86696433
E-mail：Global@everfine.net
Globalservice@everfine.net
http：//www.everfine.net
Copyright © EVERFINE, Copy or spread without authorization is prohibited.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the EMS61000-2A and is the answer not in the manual?

Questions and answers

Related Manuals for Everfine EMS61000-2A

Summary of Contents for Everfine EMS61000-2A

  • Page 1 EMS61000-2A ESD GENERATOR USER’S MANUAL V 4.02 EVERFINE Corporation (Stock Code: 300306) ADD ： Bldg.1 #669 Binkang Rd., Binjiang Hi-Tech Zone, Hangzhou（310053）, China Tel ：86-571-86698333 Fax ：86-571-86696433 E-mail：Global@everfine.net Globalservice@everfine.net http：//www.everfine.net Copyright © EVERFINE, Copy or spread without authorization is prohibited.

  • Page 3: Foreword

    Warm notice to valued customers of EVERFINE "Ensure the quality, insist on continuous improvement and make every customer more satisfied" is the quality policy of EVERFINE. Therefore, the quality of products and services provided by EVERFINE should be better than those have been promised.

  • Page 4: Copyright Statement

    EVERFINE. Any infringement related above can be traced back to the responsible user by the unique product number printed in the manual. If EVERFINE has signed a written agreement with user and the contents in the agreement are in conflict with above terms, the contents in the written agreement have preferential force effect.

  • Page 5: Safety Regulation

    It should be charged within 24 hours if it is turned off as the power shortage, otherwise, the battery would be damaged. If the battery needs to be changed, please contact the retailer or EVERFINE. Vents...
  • Page 6 Never operate the instrument with wet hands or in an environment with high humidity. Transport Take care when moving the instrument, and avoid collision, vibration or placing the instrument upside down. Copyright © EVERFINE, Copy or spread without authorization is prohibited.

  • Page 7: Table Of Contents

    5.7 Altering information and its countermeasures..........23 Chapter 6 Verification....................26 6.1 Verification basis..................... 26 6.2 Verification conditions..................26 6.3 Verification of ESD high voltage output............26 6.4 Verification of ESD gun.................. 27 Chapter7 Set-up in laboratory..................31 Copyright © EVERFINE, Copy or spread without authorization is prohibited.
  • Page 8 EMS61000-2A User’s Manua 7.1 Test set-up in laboratories................31 Chapter 8 Driver installation..................35 8.1 Internet driver installation................35 Copyright © EVERFINE, Copy or spread without authorization is prohibited.

  • Page 9: Chapter 1 Overviews

    EMS61000-2A User’s Manual Chapter 1 Overviews EMS61000-2A ESD Generator is a highly reliable test system specially designed according to the characteristics and requirements of ESD immunity test, with built-in lithium battery and portable design. The maximum ESD voltage is up to 30 kV and...

  • Page 10: Chapter 2 Specifications

    Discharge network are listed in Table 2.1. Table.2.1 Discharge network setting Discharge Discharge Max electrostatic Standard Remark mode network voltage ±30.00kV ISO10605 330Ω/150pF ±30.00kV ISO10605 ESD gun 330Ω/330pF ±30.00kV (optional) 2000Ω/150pF ISO10605/IEC61000-4-2 ±30.00kV 2000Ω/330pF ISO10605 Copyright © EVERFINE, Copy or spread without authorization is prohibited.

  • Page 11: Conventional Specification

    (3) Power supply : 100~240VAC,50Hz/60Hz (4) Battery(build-in): When the instrument is not connected to the charger,its power supply is provided by built-in lithium battery . When instrument connects to AC power supply,the Copyright © EVERFINE, Copy or spread without authorization is prohibited.
  • Page 12 EMS61000-2A User’s Manua instrument is charged by AC and battery will charged automatically. (5) Dimensions: 300mm×200mm×200mm(W×H×D) (6) Weight: About 7.0kg Copyright © EVERFINE, Copy or spread without authorization is prohibited.

  • Page 13: Chapter 3 Panel Instructions

    Indicator is orange：Power OFF and be charged normal Set parameter and show information LCD Screen ESD module connector Connect with ESD module, output the high voltage and control signal output end Copyright © EVERFINE, Copy or spread without authorization is prohibited.

  • Page 14: Rear Panel

    Export test report by connecting to USB disk Communicate with computer by RJ45 RJ45 Input power and need connect to appropriative Power supply connector charger Place the special battery Battery bin Copyright © EVERFINE, Copy or spread without authorization is prohibited.

  • Page 15: Chapter 4 Parameters Setting

    “Reset”：The stop button Display ambient temperature, ⑦ Environment information display section humidity Display charger’s connection ⑧ Charging indicator display section information ⑨ Left power charge display section Display the battery level Copyright © EVERFINE, Copy or spread without authorization is prohibited.
  • Page 16 Setting up general parameters Show information of the instrument ⑥ Help button 1.“Open”tab Fig.4.3 Test program interface Click on the “Open” tag in figure 4.2 and the pop-up window shown as figure 4.3. Copyright © EVERFINE, Copy or spread without authorization is prohibited.
  • Page 17 4.4, then program name can be modified through the qwerty keyboard. Fig.4.4 Testing program rename interface Notes: Click on “Enter” to affirm input; Click on “Esc” to quit input state; Click on “Caps” to switch the capital and small letters. Copyright © EVERFINE, Copy or spread without authorization is prohibited.
  • Page 18 “del”; Click on corresponding title in section ②, enter report edit interface shown in figure 4.6 and edit the report content. Only English and common character are supported. Copyright © EVERFINE, Copy or spread without authorization is prohibited.
  • Page 19 4.7, then relevant functions can be set up as “ON and OFF”. Settings and their functions are specified in the following Table 1. Table4.1 Settings function specification Settings Setting contents Notes Language Chinese/English Setting instrument’s language failed ON/OFF EUT failure detection ON/OFF detection Copyright © EVERFINE, Copy or spread without authorization is prohibited.
  • Page 20 4.8. Communication and language can be set up in this interface. Click on the “waveform” label and it will display standard waveform figure. 4.1.3 Dynamic display interface Fig.4.9 Dynamic display interface Copyright © EVERFINE, Copy or spread without authorization is prohibited.
  • Page 21 Discharge count: Counter works when detecting effective discharge; ⑥ Count 1~9999 when discharge interval is larger than 0.1s 1~100 when discharge interval is less than 0.1s ⑦ RC net Display current discharge RC network Copyright © EVERFINE, Copy or spread without authorization is prohibited.
  • Page 22 Fig.4.12 Progress bar display interface ① Single time Display remaining time of single test; ② Numbers of test Display remaining time of whole test. 4.1.7 Communication interface Fig.4.13 Communication interface Copyright © EVERFINE, Copy or spread without authorization is prohibited.
  • Page 23 Then press the “Reset” button to exit the communication mode and enter into the stand-by state. When it is in the communication state, other buttons do not work. Copyright © EVERFINE, Copy or spread without authorization is prohibited.

  • Page 24: Chapter 5 Operation

    Set test voltage, test number, test interval, trigger mode, etc. Refer to chapter 4 for more details. 5.4 Starting test Press “Run” button to start test. If the instrument is normal, the interface will pop-up as shown in figure 5.1. Copyright © EVERFINE, Copy or spread without authorization is prohibited.

  • Page 25: Test Termination

    5.7 Altering information and its countermeasures the message “Warning: net null” is shown as figure 5.2 after press “Run” button, it means the discharge network was connected error or undependable. Then click on Copyright © EVERFINE, Copy or spread without authorization is prohibited.
  • Page 26 “Rtn” and connect charger. Tab “ ” will be popped-up, then close down the instrument to charge about half an hour. Restart instrument, if the same alert appears, please contact manufacture to change battery. Copyright © EVERFINE, Copy or spread without authorization is prohibited.
  • Page 27 Check the BNC connector and whether the output signal of EUT is 5V . If failure detection is not needed, click on “setting” --> “failure detection” and select “close”. Fig.5.5 EUT failure alert interface Copyright © EVERFINE, Copy or spread without authorization is prohibited.

  • Page 28: Chapter 6 Verification

    High-voltage meter: the voltage range is 0~40kV, the resistance is 100GΩ and the voltage accuracy is ±1%. 6.3.2 Verification items Connection of the instrument and verification of the ESD output voltage should be carried out as Fig.6.1. Copyright © EVERFINE, Copy or spread without authorization is prohibited.

  • Page 29: Verification Of Esd Gun

    Ammeter and edges of the Faraday cage is larger than 0.6m. 6.4.2 Verification items and methods Typical calibration configuration of ESD generator is shown as Fig.6.2. 1.Verification method for the ESD gun. Copyright © EVERFINE, Copy or spread without authorization is prohibited.
  • Page 30 : Rising time of current; At the rated voltage, the ESD generator will discharge for 10 times. Record the peak discharge current and the rising time, and take the averages of the measurement data Copyright © EVERFINE, Copy or spread without authorization is prohibited.
  • Page 31 3.75 ±10% =30ns) =60ns) 2±30% 1±30% 330pF/330Ω 3.75 ±10% =65ns) =130ns) 3.75 +30% 0.275±30% 0.15±50% 150pF/2000Ω =180ns) =360ns) 0.275±30% 0.15±50% 330pF/2000Ω 3.75 +30% =400ns) =800ns) Fig.6.3 Reference wave of 330pF/330Ω,150pF/330Ω,5kV Copyright © EVERFINE, Copy or spread without authorization is prohibited.
  • Page 32 EMS61000-2A User’s Manua Fig.6.4 Reference wave of 330pF/2000Ω,150pF/2000Ω,5kV Copyright © EVERFINE, Copy or spread without authorization is prohibited.

  • Page 33: Chapter7 Set-Up In Laboratory

    470 kΩ resistor located at each end. These resistors shall be capable of withstanding the discharge voltage and shall be well insulated to avoid short circuits to the grounding reference plane. Copyright © EVERFINE, Copy or spread without authorization is prohibited.
  • Page 34 EUT , the overlapped parts should over 0.3m(without needs to be welded). Any mounting feet associated with the EUT shall be remained in place. Fig.7.1 Test set-up for table-top equipment Copyright © EVERFINE, Copy or spread without authorization is prohibited.
  • Page 35 EUT at about 0.1 m distance. This plane should be copper or aluminium sheet with thickness no less than Copyright © EVERFINE, Copy or spread without authorization is prohibited.
  • Page 36 470kΩ resistor located at each end, to prevent a build-up of charge. An example of the set-up for post-installation tests is given in figure 7.3. Fig.7.3 Test set-up for post-installation tests Copyright © EVERFINE, Copy or spread without authorization is prohibited.
  • Page 37 Fig.8.1 Main interface of ZLVircom software Click on “Serial management” and the virtual serial management interface will pop-up shown in figure 8.2, add a virtual serial such as “COM3”. Fig.8.2 Virtual serial management interface Copyright © EVERFINE, Copy or spread without authorization is prohibited.
  • Page 38 Set the serial to serial number same with added serial number such as “COM3”, Set IP address and subnet mask to same IP segment with the computer. After setting up, click on “Modify setting” and “Restart equipment”. Fig.8.4 Equipment edit interface Copyright © EVERFINE, Copy or spread without authorization is prohibited.
  • Page 39 EMS61000-2A User’s Manual After completing setting, open “EmcSuit.exe” to test, more details about the setting regulation of “ ”, please refers to the user manual of “Everfine EMC EmcSuite.exe multi-module test system software”. Copyright © EVERFINE, Copy or spread without authorization is prohibited.
