AeroFlow AF98-2065 Instruction Manual

40 Huntingwood Drive Huntingwood NSW 2148

Phone: (02) 8825 1999 Website:

www.aeroflowperformance.com

INSTRUCTION MANUAL

AEROFLOW PERFORMANCE

ENGINE SUPPORT BAR

WARNING!

BEFORE PROCEEDING WITH INSTRUCTIONS PLEASE READ CAREFULLY AND UNDERSTAND BEFORE ATTEMPTING TO USE THIS

PRODUCT.

INTRODUCTION

Congratulations on your purchase of the Aeroflow Performance Engine Support Bar. Aeroflow Performance products cannot and

will not be responsible for any damage, or other conditions resulting from misapplication of the parts described herein.

However, it is our intention to provide the best possible products for our customer, products that perform properly and satisfy

your expectations. Should you have any questions? Please call technical support at +61 2 8825 1900 and have the product part

number on hand when calling.

The Aeroflow Performance Engine Support Bar allows you to hold your engine and transmission in place while you remove your

sub-frame or engine mounts for repairs without removing the engine from the vehicle. It features dual hook assemblies for

increased load balance when working on heavy engines or when removing the transmission or transaxle. This engine support bar

comes with adjustable extension arms, adjustable height set screws and neoprene support pads which prevents slippage as well

as damage to paint. Each engine support bar is adjustable to accommodate most vehicles on the market and a each is supplied

short length of chain.

Load Rated to 500kg (1102lbs)

Adjustable from 750mm (29-33/64") to 1450mm (57-5/64").

1 |

P a g e

Table of Contents

Do you have a question about the AF98-2065 and is the answer not in the manual?

Page 1 The Aeroflow Performance Engine Support Bar allows you to hold your engine and transmission in place while you remove your sub-frame or engine mounts for repairs without removing the engine from the vehicle. It features dual hook assemblies for increased load balance when working on heavy engines or when removing the transmission or transaxle.
Page 2 DO NOT exceed the maximum capacity of 1102lb (500kg) Consult vehicle owner’s manual for safety precautions, engine weight, and location of support areas on engine. Be sure vehicle is on a solid, level ground such as a paved/concrete driveway/garage floor. Uneven or sloped surfaces create hazardous working conditions and can dangerously impeded the function of the support bar.
Page 3 P a g e...
Page 4 Tools Required: Assembly First insert the standing block (C) making sure to go in sideways through the support beam (E). Secure with a small washer (F) and wing screw (G). Attach the standing bracket (A) and rubber cushion feet (M). Then attach to the standing block(C). Making sure to pass through the support beam (E) from the underside, pass through the support screw (K).
Page 5 Slowly and evenly release the support bar until the engine is holding its own weight. Take off the support chains (L) and remove the support bar assembly, inspect all parts then store away. For more information or technical enquires Contact: Aeroflow Performance on Phone: (02) 8825 1979 Website: www.aeroflowperformance.com...
