- Page 1 User Guide FPT2600-EX1 I/M Handheld Fuel Cap Test System...
- Page 2 No part of this manual may be reproduced or transmitted in any form or by any means, electronic or mechanical, without written permission from Hickok. Hickok assumes no responsibility for use of this equipment by untrained or unauthorized persons. Printed in the United States of America.
-
Page 3: Table Of Contents
Contents Safety Information..........4 Features ............... 6 Fuel Cap Tester ................6 Pass/Fail Standard ................. 8 Storage Case and Fuel Cap Adapters ........8 Connecting & Using the Tester ......10 Step 1—Check the Tester’s Flow Rate Calibration ....10 Step 2—Setup ................12 Step 3—Testing................ -
Page 4: Safety Information
Safety Information Before using this equipment, carefully read, understand and follow instructions and safety messages on equipment and in this guide. The guide cannot anticipate or provide advice and cautions for all situations encountered by technicians. With this in mind, always follow and refer to the manuals provided by the manufacturer or the vehicle or equipment being tested or used for all information and testing procedures whenever diagnosing, repairing or operating such vehicle or equipment. - Page 5 Safety Information Before beginning any tests, make sure the test environment is safe and the vehicle meets these testing conditions: • Test area should be well ventilated. • Vehicle should be in park. • Wheels should be blocked. • Engine should be at normal operating temperature. •...
-
Page 6: Features
Features Fuel Cap Tester Quick Disconnect Coupling Pump Handle FUEL CAP TESTER NO LEAK / TEST BEGINS PASS PASS LEAK (Green LED) (Green LED) PUMP OVER FAIL PRES READY TEST PUT CAP ON BEGINS BATT PUMP STOP PUMPING CAP OFF PRESS TO START OVER PRES / LOW BATT FAIL / READY... - Page 7 Features PRESS TO START (ON/OFF Button)—Pressing this button turns the power on and off. • Turning on the unit also initiates tester auto zero and the start of the test. • The tester automatically turns off if the test is not started within 20 seconds after the unit is turned on.
-
Page 8: Pass/Fail Standard
Features Pass/Fail Standard PASS (Green) Swing Valve Quick Disconnect Fitting FAIL (Red) Storage Case and Fuel Cap Adapters 8 FPT2600-EX1 User Guide... - Page 9 Features Pass Fail Standard—Allows you to verify that the tester is calibrated properly. Storage Case and Fuel Cap Adapters—Color coded for easy identification, the fuel cap adapters allow you to test most vehicle’s fuel caps. • Black Cap Adapter—Standard threaded cap, used for most vehicles. •...
-
Page 10: Connecting & Using The Tester
Connecting & Using the Tester Before You Begin • Please read the instructions carefully before using the tester. Failure to follow the instructions may cause incorrect test results. • Before using the tester for the first time, remove the battery protector pull tab. - Page 11 Connecting & Using the Tester Procedure—Part 1 1. Set the Pass/Fail Standard swing valve to PASS (green). 2. Push the Press To Start button to turn the tester on. The LEDs will light in the following order: • All LEDs will light briefly. •...
-
Page 12: Step 2-Setup
Chapter Step 2—Setup 1. Remove the fuel cap from the vehicle and inspect for the following: • Damage to the fuel cap—if damaged, replace with new cap • Cracked or missing gasket—if damaged or missing, replace with a new gasket. •... -
Page 13: Step 3-Testing
Connecting & Using the Tester Step 3—Testing 1. With the adapter and fuel cap connected to the tester, and with the tester power on (red READY LED on) , begin pumping the handle to build up pressure and to start the test. While pumping the handle, the green PASS LED will turn on. -
Page 14: Warranty
Warranty Subject to the conditions that follow and are noted below, this product is warranted to be free from defects in material and workmanship, under proper use and in accordance with the manufacturer’s written recommendation and specifications, for a period designated below on all products: •... -
Page 15: Contact Information
216/761-9879 E-mail: support@hickok-inc.com repaircenter@hickok-inc.com Service address: Hickok Inc. Automotive Group 1716 Carrollton Avenue Dock E Greenwood, MS 38930 Don’t forget to check out other testers, equipment and parts at our websites. Access our Quick-n-E-Z Parts and Service from any of these sites 24/7 for ordering parts or service. - Page 16 02490-974 Rev C...
