OWNER'S
MANUAL
MODEL NO.
944.369341
HOW TO ORDER
REPAIR PARTS
6.5 HORSEPOWER
21" MULTI-CUT
POWER PROPELLED
ROTARYLAWN MOWER
Each lawn mower has its own model number. Each engine has its own
model number.
The model number for your lawn mower will be found on a decal attached
to the rear of the lawn mower housing.
The model number for your engine will be found on the blower housing of
the engine.
All parts listed herein may be ordered from any Sears Canada, Inc. Service
Centre/Department and most Retail Stores.
WHEN ORDERING REPAIR PARTS, ALWAYS GIVE THE FOLLOWING
INFORMATION:
PRODUCT - LAWN MOWER
MODEL NUMBER - 944.369341
ENGINE MODEL NO. - 143.996522
PART NUMBER
PART DESCRIPTION
Your Sears merchandise has added value when you consider Sears has
service units nationwide staffed with Sears trained technicians...
professional technicians specifically trained to insure that we meet our
pledge to you, we service what we sell.
SEARS HAS ACCESS TO OVER 800,000 PARTS
WHETHER IT'S A SPARK PLUG OR LAWNMOWER BLADE.
SEARS PARTS AND SERVICE CAN SUPPLY YOU WITH
TOP QUALITY REPAIR PARTS FOR ALL YOUR PRODUCTS.
JUST CALL ONE OF THE FOLLOWING NUMBERS TO PLACE YOUR
ORDER. IF CALLING LOCALLY:
Regina - 566-5124
Toronto - 744-4900
Kitchener - 894-7590
ALL OTHER AREAS CALL 1-800-665-4455
26
NEED A PART?
Montreal - 333-5740
Halifax - 454-2444
Ottawa - 738-4440
Vancouver - 420-8211
®

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 944.369341 and is the answer not in the manual?

Questions and answers

Summary of Contents for Craftsman 944.369341

  • Page 1 All parts listed herein may be ordered from any Sears Canada, Inc. Service Centre/Department and most Retail Stores. WHEN ORDERING REPAIR PARTS, ALWAYS GIVE THE FOLLOWING INFORMATION: • PRODUCT - LAWN MOWER • MODEL NUMBER - 944.369341 • ENGINE MODEL NO. - 143.996522 • PART NUMBER • PART DESCRIPTION...
  • Page 2 ® MODEL NUMBER 944.369341 OWNER’S MANUAL • Assembly • Operation • Customer Responsibilities • Service • Adjustments • Repair Parts Caution: Read and Follow all Safety Rules and Instructions Before Operating This Equipment Printed in U.S.A. 170109 07.12.99 Sears Canada, Inc., Toronto, Ontario M5B 2B8...
  • Page 3: Safety Rules

    SAFETY RULES Safe Operation Practices for Walk-Behind Mowers IMPORTANT: THIS CUTTING MACHINE IS CAPABLE OF AMPUTATING HANDS AND FEET AND THROWING OBJECTS. FAILURE TO OBSERVE THE FOLLOWING SAFETY INSTRUCTIONS COULD RESULT IN SERIOUS INJURY OR DEATH. SAFETY STANDARDS REQUIRE OPERATOR PRESENCE CONTROLS TO MINIMIZE THE RISK OF INJURY. YOUR UNIT IS EQUIPPED WITH SUCH CONTROLS.
  • Page 4: Product Specifications

    SPARK PLUG: Champion RJ19LM (GAP: .030") VALVE CLEARANCE: INTAKE: .004 - .008 EXHAUST: .004 - .008 MODEL NUMBER 944.369341 SOLID STATE IGNITION AIR GAP: .0125 IN. SERIAL NUMBER ____________________________________ BLADE BOLT TORQUE: 35-40 FT. LBS. DATE OF PURCHASE __________________________ THE MODEL AND SERIAL NUMBERS WILL BE FOUND...
  • Page 5: Table Of Contents

    Owner’s Manual. Warranty service is available by returning the Craftsman Power Mower to the nearest Sears Service Centre/Department in Canada. This warranty applies only while this product is in use in Canada.
  • Page 6: Assembly

    ASSEMBLY Read these instructions and this manual in its entirety before TO INSTALL ATTACHMENTS you attempt to assemble or operate your new lawn mower. Your lawn mower was shipped ready to be used as a IMPORTANT: THIS LAWN MOWER IS SHIPPED WITHOUT mulcher.
  • Page 7: Operation

    OPERATION KNOW YOUR LAWN MOWER READ THIS OWNER'S MANUAL AND SAFETY RULES BEFORE OPERATING YOUR LAWN MOWER. Compare the illustrations with your lawn mower to familiarize yourself with the location of various controls and adjustments. Save this manual for future reference. These symbols may appear on your lawn mower or in literature supplied with the product.
  • Page 8 OPERATION The operation of any lawn mower can result in foreign objects thrown into the eyes, which can result in severe eye damage. Always wear safety glasses or eye shields while operating your lawn mower or performing any adjustments or repairs. We recommend wide vision safety mask over spectacles or standard safety glasses.
  • Page 9 OPERATION TO CONVERT MOWER Your lawn mower was shipped ready to be used as a mulcher. To convert to bagging or discharging: REAR BAGGING (See Fig. 5A) - • Open rear door and remove mulcher plug. Store mulcher plug in a safe place. •...
  • Page 10 OPERATION MOWING TIPS NOTE: Allow oil to settle down into engine for accurate dipstick reading. • For most cutting conditions and better bagging performance, • Engine holds 20 ozs. of oil. For type and grade of oil the engine speed should be set in the fast position. to use, see "ENGINE"...
  • Page 11: Maintenance Schedule

    CUSTOMER RESPONSIBILTIES MAINTENANCE SCHEDULE FILL IN DATES AS YOU COMPLETE SERVICE DATES REGULAR SERVICE Check for Loose Fasteners Clean/Inspect Grass Catcher (If Equipped) Clean Lawn Mower Clean Under Drive Cover (Power-Propelled Mowers) Check drive belt/pulleys (Power-Propelled Mowers) Check/Sharpen/Replace Blade Lubrication Chart Clean Battery/Recharge (Electric Start Mowers) Check Engine Oil Level...
  • Page 12 CUSTOMER RESPONSIBILITIES LAWN MOWER CRANK- BLADE SHAFT Always observe safety rules when performing any mainte- ADAPTER KEYWAY nance. TIRES • Keep tires free of gasoline, oil, or insect control chemicals BLADE which can harm rubber. • Avoid stumps, stones, deep ruts, sharp objects and other hazards that may cause tire damage.
  • Page 13 CUSTOMER RESPONSIBILITIES DRIVE WHEELS (See Fig. 10) ENGINE Check rear drive wheels each time you mow to be sure they LUBRICATION move freely. The wheels not turning freely means trash, grass cuttings, etc., may be inside the drive wheel and dust Use only high quality detergent oil rated with API service cover area and must be cleaned out to free drive wheels.
  • Page 14 CUSTOMER RESPONSIBILITIES AIR FILTER MUFFLER Your engine will not run properly and may be damaged by Inspect and replace corroded muffler as it could create a fire using a dirty air filter. hazard and/or damage. Replace the air filter every year, more often if you mow in SPARK PLUG very dusty, dirty conditions.
  • Page 15: Service And Adjustments

    SERVICE AND ADJUSTMENTS CAUTION: BEFORE PERFORMING ANY SERVICE OR ADJUSTMENTS: • Release control bar and stop engine. • Make sure the blade and all moving parts have completely stopped. • Disconnect spark plug wire from spark plug and place where it cannot come in contact with plug. ENGINE SPEED LAWN MOWER Your engine speed has been factory set.
  • Page 16: Storage

    STORAGE Immediately prepare your lawn mower for storage at the end ENGINE of the season or if the unit will not be used for 30 days or FUEL SYSTEM more. IMPORTANT: IT IS IMPORTANT TO PREVENT GUM DEPOSITS FROM FORMING IN ESSENTIAL FUEL SYSTEM LAWN MOWER PARTS SUCH AS CARBURETOR, FUEL FILTER, FUEL When lawn mower is to be stored for a period of time, clean...
  • Page 17: Troubleshooting

    TROUBLESHOOTING POINTS PROBLEM CAUSE CORRECTION Will not start Dirty air filter. Clean/replace air filter. Out of fuel. Fill fuel tank. Stale fuel. Drain tank and refill with fresh clean fuel. Water in fuel. Drain fuel tank and carburetor and refill tank with fresh gasoline.
  • Page 18 SERVICE NOTES...
  • Page 19: Repair Parts - Lawn Mower

    REPAIR PARTS ROTARY LAWN MOWER - MODEL NUMBER 944.369341...
  • Page 20 REPAIR PARTS ROTARY LAWN MOWER - MODEL NUMBER 944.369341 PART PART DESCRIPTION DESCRIPTION 166032 Pulley, Fixed 167163 Handle, Upper Dlx Comf. (Including grip) 170045 Bearing Support Assy. 161105X479 Handle, Lower 150406 Bolt, Engine 131036 Bail, Cont. Wire Dlx Comf. Blk...
  • Page 21 REPAIR PARTS ROTARY LAWN MOWER - MODEL NUMBER 944.369341...
  • Page 22 REPAIR PARTS ROTARY LAWN MOWER - MODEL NUMBER 944.369341 PART PART DESCRIPTION DESCRIPTION 166047 Speed Control 57808 Screw Hex Head Tapping 1/4-20 x .75 167259 Bail Control Drive 170011 Drive Pawl 54583 Screw 166450 Pinion, Drive 170050 Drive Cable 52160...
  • Page 23: Repair Parts - Engine

    CRAFTSMAN 4-CYCLE ENGINE MODEL NO. 143.996522...
  • Page 24 CRAFTSMAN 4-CYCLE ENGINE MODEL NO. 143.996522 KEY PART KEY PART NO. NO. DESCRIPTION NO. NO. DESCRIPTION 36478A Cylinder (Incl. 2,7,20 & 125) 169 27234A * Valve Cover Gasket 26727 Dowel Pin 172 32755 Valve Cover 33734 Breather Element 174 30200 Screw, 10-24 x 9/16"...
  • Page 25 CRAFTSMAN 4-CYCLE ENGINE MODEL NO. 143.996522 KEY PART NO. NO. DESCRIPTION — — 632747 Carburetor (Incl. 184 of Engine Parts List) 631615 Throttle Shaft & Lever Assembly 631767 Throttle Return Spring 631184 Dust Seal Washer 631183 Dust Seal (Throttle) 632504...
  • Page 26 CRAFTSMAN 4-CYCLE ENGINE MODEL NO. 143.996522 KEY PART NO. NO. DESCRIPTION — — 590702 Recoil Starter 590599A Spring Pin (Incl. 4) 590600 Washer 590696 Retainer 590601 Washer 590697 Brake Spring 590698 Starter Dog 590699 Dog Spring 590700 Pulley & Rewind Spring Ass’y.
