USER'S MANUAL
UNITEK MIYACHI
No. 990-086
C
O
R
P
O
R
A
T
I
O
N
REV. A
MICROPULL V MANUAL INSERT
STAR NX-1001 115VAC
KX-P1150
These printers may be used on the following product:
Model MP5
Stock No. 6-105-01-01
UNITEK MIYACHI Corp.
1820 S. Myrtle Ave.
Monrovia, CA 91017-7133
(818)303-5676 Fax: (818)358-8048
Printed June 19, 1995
Advertisement
Related Manuals for Unitek Miyachi STAR NX-1001
Summary of Contents for Unitek Miyachi STAR NX-1001
- Page 1 USER’S MANUAL UNITEK MIYACHI No. 990-086 REV. A MICROPULL V MANUAL INSERT STAR NX-1001 115VAC KX-P1150 These printers may be used on the following product: Model MP5 Stock No. 6-105-01-01 UNITEK MIYACHI Corp. 1820 S. Myrtle Ave. Monrovia, CA 91017-7133...
- Page 2 HF2 ADVANCED SERIAL DATACOM INITIAL SETUP PROCEDURE March 15, 1995, REV. A Page 2 - 2 -...
-
Page 3: Initial Setup Procedure
This insert to the MICROPULL V Manual replaces pages 20 through 22 (Section 6.00 through section 6.07.4) when the MP5 is used with Star NX-1001 printer. INITIAL SETUP PROCEDURE BEFORE CHANGING THE POSITION OF THE MP5 ON THE BENCH, ALWAYS REMOVE THE DEVICE HOLDER FROM THE BASEPLATE. -
Page 4: Dip Switch Settings
PRINTER CONNECTION - Use the standard male-to-male RS232 Cable supplied with the MP5. 6.5.1 Connect one end of the cable to the RS232 Serial Port on the rear of the MP5. 6.5.2 Connect the other end of the cable to the Serial Connector of the Serial-Parallel Converter (SPC-8K). Serial-Parallel Converter (SPC-8K) 6.5.3 Set the DIP switches on the Serial-Parallel Converter (SPC-8K) as shown below:... - Page 5 6.5.4 Connect the Parallel Connector of the Serial-Parallel Converter (SPC-8K) to the Interface Connector of the Star NX-1001 printer. PRINTER POWER CABLE CONNECTION - Connect the printer power cable to an outlet of the proper line voltage (usually 115VAC). Switch the Printer Power Switch to “ON.”...
