- Page 1 Ultra 80 SCSI ™ ™ Cable Installation Guide Sun Microsystems, Inc. 901 San Antonio Road Palo Alto, CA 94303 U.S.A. 650-960-1300 Part No. 806-4423-10 March 2000, Revision A Send comments about this document to: docfeedback@sun.com...
- Page 2 Sun, Sun Microsystems, the Sun logo, AnswerBook2, docs.sun.com, Ultra, and Solaris are trademarks, registered trademarks, or service marks of Sun Microsystems, Inc. in the U.S. and other countries. All SPARC trademarks are used under license and are trademarks or registered trademarks of SPARC International, Inc.
-
Page 3: Preface
Preface ™ The Sun Utra 80 SCSI Cable Installation Guide describes how to install the Sun ™ Ultra 80 SCSI cable optional component. Related Documentation Application Title Part Number Service Sun Ultra 80 Service Manual 805-6618 Accessing Sun Documentation Online The docs.sun.com web site enables you to access Sun technical documentation on the Web. - Page 4 Sun is interested in improving its documentation and welcomes your comments and suggestions. You can email your comments to Sun at: docfeedback@sun.com Please include the part number of your document in the subject line of your email. Sun Ultra 80 SCSI Cable Installation Guide • March 2000...
-
Page 5: Table Of Contents
Contents Preface iii Optional SCSI Cable Component 1-1 Optional SCSI Cable Component Kit 1-2 System Hardware Requirements 1-2 SCD Compliance 1-2 How to Proceed 1-3 Powering On/Off and Internal Access 2-1 Powering Off the System/Removing the Access Panel 2-1 Attaching the Antistatic Wrist Strap 2-5 Replacing the Access Panel/Powering On the System 2-6 Removing and Replacing the Peripheral Assembly 3-1 Removing the Peripheral Assembly 3-1... - Page 6 Sun Ultra 80 SCSI Cable Installation Guide • March 2000...
-
Page 7: Optional Scsi Cable Component
C H A P T E R Optional SCSI Cable Component ™ ™ The Sun Ultra 80 system supports up to two SCSI devices, with 50-pin SCSI connectors, in its peripheral assembly (removable media drive bay). This book explains how to install the optional SCSI cable component when a second SCSI removable media drive is added to the system. -
Page 8: Optional Scsi Cable Component Kit
2.1 of the SPARC™ Compliance Definition (SCD) developed by SPARC International, Inc. These systems are binary compatible with all other systems and software that conform to SCD version 2.1. Sun Ultra 80 SCSI Cable Installation Guide • March 2000... -
Page 9: How To Proceed
How to Proceed If you are an experienced technician, system administrator, authorized service provider (ASP), or advanced computer system end user who has experience troubleshooting and replacing hardware, you may want to start with Chapter 4 “Installing the Optional SCSI Cable Component.” Otherwise, first read and perform the procedures in sequence in Chapter 2 “Powering On/Off and Internal Access”, and Chapter 3 “Removing and Replacing the Peripheral Assembly.”... - Page 10 Sun Ultra 80 SCSI Cable Installation Guide • March 2000...
-
Page 11: Powering On/Off And Internal Access
C H A P T E R Powering On/Off and Internal Access This chapter contains procedures to power on and off the system, and instructions on how to access the system for service: Section 2.1 “Powering Off the System/Removing the Access Panel” on page 2-1 Section 2.2 “Attaching the Antistatic Wrist Strap”... - Page 12 5. Turn off the power to the monitor. 6. Disconnect cables to any peripheral equipment. 7. Remove the lock block, if installed ( FIGURE 2-2 Power switch System Power FIGURE 2-1 Sun Ultra 80 SCSI Cable Installation Guide • March 2000...
- Page 13 Lock block Workstation Lock Block Location FIGURE 2-2 8. Remove the access panel as follows ( FIGURE 2-3 Note – Removing the access panel activates the system power interlock circuit. This safety mechanism prevents all DC voltages (except 5 VDC standby power) from reaching any internal components when the access panel is removed.
- Page 14 Access panel Depression (2) Removing/Replacing the Access Panel FIGURE 2-3 Sun Ultra 80 SCSI Cable Installation Guide • March 2000...
-
Page 15: Attaching The Antistatic Wrist Strap
Attaching the Antistatic Wrist Strap Caution – Wear an antistatic wrist strap and use an ESD-protected mat when handling components. When servicing or removing system components, attach an ESD strap to your wrist, then to a metal area on the chassis, and then disconnect the power cord from the system and the wall receptacle. -
Page 16: Replacing The Access Panel/Powering On The System
Ensure that the access panel is installed correctly. 1. Hold the access panel, centering it over the chassis opening. 2. Lower the access panel lightly onto the chassis until the access panel hooks engage the chassis rail. Sun Ultra 80 SCSI Cable Installation Guide • March 2000... - Page 17 3. Tilt the top of the access panel in toward the chassis until it clicks into place. 4. Verify that the access panel clicks into both sides of the chassis top. 5. Replace the lock block ( FIGURE 2-2 6. Place the system into the operating position. 7.
- Page 18 Sun Ultra 80 SCSI Cable Installation Guide • March 2000...
-
Page 19: Removing And Replacing The Peripheral Assembly
C H A P T E R Removing and Replacing the Peripheral Assembly To remove and replace a peripheral assembly drive, it is necessary to remove and replace the peripheral assembly. Note – A peripheral assembly drive can be a CD-ROM drive, a 4-mm tape drive, an 8-mm tape drive, or any offered optional drive component, such as a PCI-connected device. - Page 20 Remove the peripheral assembly from the chassis. 5. Place the peripheral assembly on an antistatic mat. Peripheral assembly Screw (4) Peripheral bezel assembly Removing and Replacing the Peripheral Assembly FIGURE 3-1 Sun Ultra 80 SCSI Cable Installation Guide • March 2000...
-
Page 21: Installing An Optional Component
Installing an Optional Component Note – Ensure that the peripheral power cable and all data cables are properly routed through the clips adjacent to the peripheral assembly. Route the SCSI data cable through the cable management hooks (part of chassis) adjacent to the hard drive cage. -
Page 22: Replacing The Peripheral Assembly
CPU area into the peripheral area. d. Using a No. 2 Phillips screwdriver, tighten the captive screws securing the peripheral assembly to the chassis. 2. Replace the peripheral bezel assembly. Sun Ultra 80 SCSI Cable Installation Guide • March 2000... - Page 23 3. Detach the antistatic wrist strap. 4. Replace the access panel and power-on the system. See Section 2.3 “Replacing the Access Panel/Powering On the System” on page 2-6. Chapter 3 Removing and Replacing the Peripheral Assembly...
- Page 24 Sun Ultra 80 SCSI Cable Installation Guide • March 2000...
-
Page 25: Installing The Optional Scsi Cable Component
C H A P T E R Installing the Optional SCSI Cable Component 1. Remove the peripheral assembly and install the second SCSI device. See Chapter 2 “Powering On/Off and Internal Access and Chapter 3 “Removing and Replacing the Peripheral Assembly”, for safe procedures. 2. - Page 26 Optional SCSI SCSI terminator cable component board SCSI cable middle connector SCSI cable end connector Installing the Optional SCSI Cable Component FIGURE 4-1 Sun Ultra 80 SCSI Cable Installation Guide • March 2000...
- Page 27 Power connector (2) Reinstalling the Power Cables FIGURE 4-2 Chapter 4 Installing the Optional SCSI Cable Component...
- Page 28 Sun Ultra 80 SCSI Cable Installation Guide • March 2000...
