- Page 1 USER MANUAL CM 8SH CI-TC 082256 DVB S/S2 TO COFDM/QAM WITH DUAL CI TRANSMODULATOR ITS Partner O.B.S S.L · Av. Cerdanyola 79-81 Local C 08172 Sant Cugat del Vallés · Barcelona (Spain) Phone: +34935839543 · info@ek.plus · www.ek.plus...
-
Page 2: Table Of Contents
General installation and wiring: ..................................... 5 Installation of a multi-module head-end: ..............................6 “CM Management” PROGRAMMING SOFTWARE: ............................ 7 Main screen: ............................................7 CM 8SH CI-TC module configuration: ................................9 Input card: ............................................. 10 Program pool: ............................................. 11 DVB-C output card: ........................................12 Advanced Configuration: ...................................... -
Page 3: Introduction
• Configuration cloning and report generation. • On-site (FA 524 / CM PR) or remote (FA 524) management Package contents: • 1x CM 8SH CI-TC module (082256) • 1x Power supply cable (082123) • 1x 63.25mm jumper (082148) • 1x Mounting tab (251008) ITS Partner O.B.S S.L ·... -
Page 4: Connections And Interfaces
CM 8SH CI-TC USER MANUAL CONNECTIONS AND INTERFACES: 1. USB input 2. HDMI input 3. Status LED. Status information of the input tuners. 4. Dual CI input 5. Input connectors to each tuner. 6. Status LED. Reports the status of the COFDM/QAM modulated output. -
Page 5: Installation And Wiring
CM 8SH CI-TC USER MANUAL 1.- Ventilation grille. 2.- Power supply connector if using a single module with FA 55 power supply. 3.- Module power supply port and input data bus. (IN) 4.- Port for power supply to the next module and output data bus. -
Page 6: Installation Of A Multi-Module Head-End
CM 8SH CI-TC USER MANUAL 2.- Connect the power supply 524) to the module or 55, power supply can also be connect it to the previous module using the supplied used to power a single module. power cable. 3.- Connect the input signals to the transmodulator inputs. -
Page 7: Cm Management" Programming Software
CM 8SH CI-TC USER MANUAL • It is recommended to install the modules with CIs downstream of the power supply. • It is possible to use the long jumper to deliver the input signal to adjacent modules. • The attenuation at the output of each module can be adjusted to compensate for cable losses at high frequency. - Page 8 CM 8SH CI-TC USER MANUAL For the LAN, select the equipment and for connection press: • ID.: enter the MAC of the corresponding power supply. • KEY: enter the CM Key, if any. If not “0”. • LOCAL IP: the local IP will be entered if connected via LAN from the same network.
-
Page 9: Cm 8Sh Ci-Tc Module Configuration
CM 8SH CI-TC USER MANUAL The main “CM Management” screen enables easy identification of the different modules connected to the power supply, as can be seen in the following screen: Power supply and head-end manager (red). Identification of a module with an input card (green) and an output card (blue). -
Page 10: Input Card
CM 8SH CI-TC USER MANUAL Input card: In this part of the menu the input card will be configured. Selecting A, B, C, D, E, F, G or H in order to choose the input tuner that is to be configured: On: Click on “Check”... -
Page 11: Program Pool
CM 8SH CI-TC USER MANUAL Program pool: In this table all channels, services, which correspond to the selected entries will be listed. From here the services that are wished to be assigned to each MUX output can be selected. Each service is assigned to the input tuner from which it has been tuned. -
Page 12: Dvb-C Output Card
CM 8SH CI-TC USER MANUAL Information window on each MUX output throughput: Four bars are displayed corresponding to each MUX output. The green line indicates the percentage of channel occupied. The number above indicates the total throughput being transmitted. At the end of each bar there are two numbers: the first number indicates the throughput being modulated on that channel and the second the maximum possible throughput for the selected modulation parameters. -
Page 13: Remote Head-End Management
CM 8SH CI-TC USER MANUAL Flow: Adjustment of the data transfer rate to the output: As a general rule, we will set the FTA (Free To Air) modules to 160Mbps. Example flow calculation: 31668Mbps x 4 = 126672 Mbps - The value above would be 160 Mbps. -
Page 14: Faqs
CM 8SH CI-TC USER MANUAL Red: No Internet connection. Orange: Connection to the Internet and server. Green: Connection established against head-end modules. Address and port of the data server which facilitates the remote connection. It is configured by default. DO NOT CHANGE. -
Page 15: Configuration Example
CM 8SH CI-TC USER MANUAL • How can I see the configuration examples? Example 1: Configuration Exa mple Input 1: ON – Tuner A – 22KHz. Disabled. EUTELSAT 5ºO Satellite – Frequency 11554 VERTICAL 29950 11554-9750=1804Mhz. No DISEQ. Input 1 – Standard: DVB S2 6 channels in the COFDM modulated program pool: 2 Encoded services–... - Page 16 CM 8SH CI-TC USER MANUAL Example 2: Input 1: ON – Tuner A – 22KHz. Disabled. Input 1: ON – Tuner B – 22KHz. Disabled. A: EUTELSAT 5ºO Satellite – Frequency 11096 VERTICAL 29950 B: EUTELSAT 5ºO Satellite – Frequency 11554 VERTICAL 29950 DISEQ B.
