Unit 11 Callywhite Business Park, Callywhite Lane, Dronfield, S18 2XP
+44(0)1246 417113
Please read the manual carefully before installing this unit
1. Packing list
Name
Reader
Rubber plug
Self tapping screws
Please ensure that all the above contents are correct. If any are missing please notify us immediately.
2. Specification
Operating Voltage
Output
Card type
Reading Distance
Communication Distance
Idle Current
Operating Temperature
Operating Humidity
Waterproof
Dimensions
C Prox Ltd (inc Quantek)
sales@cproxltd.com
Network Proximity Reader
CP002-EM / CP002-EM-M
User Manual
Quantity Remarks
1
2
Φ6mm×30 mm, used for fixing
Φ4mm×28 mm, used for fixing
2
9-16V DC
Wiegand 26 / 34
EM 125KHz
2-5 cm
Up to 100M
<30mA
-45℃～60℃
10%- 90% RH
Conforms to IP68
110 x 48 x 20 mm
www.quantek.co.uk
Advertisement
Related Manuals for C Prox CP002-EM
Summary of Contents for C Prox CP002-EM
- Page 1 C Prox Ltd (inc Quantek) Unit 11 Callywhite Business Park, Callywhite Lane, Dronfield, S18 2XP +44(0)1246 417113 sales@cproxltd.com www.quantek.co.uk Network Proximity Reader CP002-EM / CP002-EM-M User Manual Please read the manual carefully before installing this unit 1. Packing list Name...
- Page 2 3. Installation • Remove the back cover from the front using a Phillips screw driver. • Use back plate to drill two holes on the wall for the self-tapping fixing screws and one for the cable. • Put the two wall plugs into the fixing holes. •...
