User Manual
GreenPAK Pro
Development Platform
UM-GP-006
Abstract
This user manual provides basic guidelines for the developers to get familiar with the GreenPAK Pro
Development Platform. It gives an overview of the hardware, as well as the functional description of
this platform, and shows the example projects using SLG46880.
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Dialog Semiconductor GreenPAK Pro
Summary of Contents for Dialog Semiconductor GreenPAK Pro
-
Page 1: Abstract
UM-GP-006 Abstract This user manual provides basic guidelines for the developers to get familiar with the GreenPAK Pro Development Platform. It gives an overview of the hardware, as well as the functional description of this platform, and shows the example projects using SLG46880. -
Page 2: Table Of Contents
4.2.5 Generators ......................10 4.2.6 Pins Connectivity ....................12 4.2.7 Preparing GreenPAK Pro Development Board ........... 15 4.2.8 Chip PIN versus Development Board Test Point ..........16 4.2.9 Using 20 Pins Socket Adapter with 32 Pins Socket Connector......17 Example Projects using SLG46880 ................... 19 Project: Counter with Clock Enable .................. -
Page 3: Figures
UM-GP-006 GreenPAK Pro Development Platform Figures Figure 1: GreenPAK Pro Development Board, Top View ..............8 Figure 2: USB Interface ......................... 9 Figure 3: GreenPAK Socket Connector Pinout ..................9 Figure 4: GreenPAK Expansion Connector Pinout ................9 Figure 5: Expansion Connector Control in GreenPAK Designer............10 Figure 6: Choosing Generators ...................... -
Page 4: Terms And Definitions
UM-GP-006 GreenPAK Pro Development Platform Terms and Definitions Analog-to-Digital Converter Digital-to-Analog Converter Electrostatic Discharge Ground General Purpose Integrated Circuit Integrated Development Environment Light Emitting Diode Look Up Table Microcontroller Unit One-Time Programable Over-Voltage Not Connected Random-Access Memory System on a Chip... -
Page 5: Introduction
GreenPAK Pro Development Platform Introduction Thank you for choosing Dialog Semiconductor products. The GreenPAK Pro Development Platform allows you to develop your custom design using GreenPAK mixed signal ICs. You can design your own projects starting from a blank project, or by altering the sample projects provided at https://www.dialog-semiconductor.com/. -
Page 6: Getting Started
UM-GP-006 GreenPAK Pro Development Platform Getting Started Introduction This chapter describes how to install and configure the GreenPAK Pro Development Platform. Section provides the details of hardware operation. Section provides an instructions on how to create a simple project. Install Software GreenPAK Designer software is available free of charge from the Dialog website at https://www.dialog-... -
Page 7: Hardware
30 digital channels and time resolution down to 40 ns point time per channel. For chip power usage analysis GreenPAK Pro Development Board includes a 2 channel power monitor for measuring voltage and current consumption parameters. These power monitors have two current measuring ranges: high current measurement that supports up to 60 mA and low current measurement that supports up to 1 mA. -
Page 8: Functional Description
4.2.1 Power Supply The main power source of the GreenPAK Pro Development Board is an external power supply that is supplied with the Development Board. Use only power supply that comes with the Development Board. The Development Board will not operate correctly without the external power supply. -
Page 9: Socket Connector
This 34-pin connector is in the left bottom portion of the Development Board. The Socket Connector is a standard 0.1" double row female connector. The GreenPAK Pro Development Board should be used with a detachable socket board. Its main purpose is to connect the target GreenPAK chip to the Development Board. -
Page 10: Generators
GreenPAK Pro Development Board as it was set in Emulation mode. After the Emulation button is pressed, the software will automatically perform the following steps: ▪... -
Page 11: Figure 6: Choosing Generators
UM-GP-006 GreenPAK Pro Development Platform Figure 6: Choosing Generators Logic generator is used for generating logic pulses. C generator allows the user to create I C signals based on logic generators. There are two logic generators combined together as SDA and SCL lines. The user can combine predefined I C settings to generate a needed waveform and choose SCL frequency. -
Page 12: Pins Connectivity
The Socket connector has the following type of connections: 1. V 2. GND 3. Data connections The GreenPAK Pro Development Board supports connecting eight types of loads and signal sources. Each source has its own special purpose. For V pins only a signal generator connection is available. - Page 13 UM-GP-006 GreenPAK Pro Development Platform Upper Upper connection to connection to or V high (Note 2) impedance level shifter MCU; through 33 bottom connection to resistor; GND through bottom 33 resistor connection to high impedance MCU input Upper...
-
Page 14: Figure 9: Schematic Connection Of The V
UM-GP-006 GreenPAK Pro Development Platform Figure 9: Schematic Connection of the V Figure 10 shows the schematic connection of the GP data pins. User Manual Revision 1.1 15-Sep-2021 © 2021 Dialog Semiconductor CFR0012 14 of 33... -
Page 15: Preparing Greenpak Pro Development Board
GreenPAK Pro Development Platform Figure 10: Schematic Connection of the Data Pin 4.2.7 Preparing GreenPAK Pro Development Board To start working with GreenPAK Pro Development Board it is necessary to: ▪ Connect external Power Supply; ▪ Connect Development Board to PC via USB cable;... -
Page 16: Chip Pin Versus Development Board Test Point
UM-GP-006 GreenPAK Pro Development Platform Figure 11: GreenPAK Pro Development Board Ready to Work 4.2.8 Chip PIN versus Development Board Test Point Before you start working with a chip, you need to understand the difference between such concepts as PIN (chip pin) and TP (the Development Board test point). -
Page 17: Using 20 Pins Socket Adapter With 32 Pins Socket Connector
UM-GP-006 GreenPAK Pro Development Platform PINs refer to the physical pins that are on the chip package (their marking can be seen in the datasheet). TPs refer to the Socket and Expansion connector pins. TP and PIN numbers may not... -
Page 18: Figure 14: 20 Pins Socket Adapter Connected Into 32 Pins Socket Connector
UM-GP-006 GreenPAK Pro Development Platform Figure 14: 20 Pins Socket Adapter Connected into 32 Pins Socket Connector User Manual Revision 1.1 15-Sep-2021 © 2021 Dialog Semiconductor CFR0012 18 of 33... -
Page 19: Example Projects Using Slg46880
UM-GP-006 GreenPAK Pro Development Platform Example Projects using SLG46880 Project: Counter with Clock Enable Blocks required: ▪ 2 digital inputs ▪ 1 digital output ▪ 2 Look Up Table with two inputs ▪ 1 Counter Figure 15: GreenPAK Designer Components All these components can be found in Components List. -
Page 20: Figure 16: Greenpak Components List
UM-GP-006 GreenPAK Pro Development Platform Figure 16: GreenPAK Components List User Manual Revision 1.1 15-Sep-2021 © 2021 Dialog Semiconductor CFR0012 20 of 33... -
Page 21: Figure 17: Pin1 Mode
UM-GP-006 GreenPAK Pro Development Platform Table 2: GreenPAK Pin Configuration Pin # Pin Name Type Pin Description Supply Voltage Supply Voltage Clock Digital Input Digital Input Enable Digital Input Digital Input 14, 30 Ground Counter Output Push-Pull Output Digital Output... -
Page 22: Figure 18: Look Up Table Properties Configured As An And Gate
UM-GP-006 GreenPAK Pro Development Platform The next component in this design is Look Up Table. First Look Up Table (LUT0) is used to generate logic “1” only when there are high logic levels on both inputs (AND gate). Select AND gate from “Standard gates”... -
Page 23: Figure 19: Look Up Table Properties Configured As A Nor Gate
UM-GP-006 GreenPAK Pro Development Platform Figure 19: Look Up Table Properties Configured as a NOR Gate Figure 20 shows counter properties. User Manual Revision 1.1 15-Sep-2021 © 2021 Dialog Semiconductor CFR0012 23 of 33... -
Page 24: Figure 20: Counter Properties
UM-GP-006 GreenPAK Pro Development Platform Figure 20: Counter Properties The Final step is to connect each of the selected components. Use Wire tool to perform this action. To connect two pins select “Set Wire” and then click on the first and the second pins of the module or modules that you want to connect. -
Page 25: Figure 21: Ready Project In Greenpak Designer
Figure 21 displays ready project with configured blocks and wire connections. Use the GreenPAK Pro Development Board to test this project. Prepare the Development Board to work, see Section 4.2.7, and press “Emulator” button. Wait until the initialization process of GreenPAK Pro Development Board is in progress. -
Page 26: Figure 23: Generator Settings Window
UM-GP-006 GreenPAK Pro Development Platform Figure 23: Generator Settings Window It is necessary to connect logical generator to the PIN3, and to the PIN 2 button. To do so click on “Add” menu from Additional emulation toolbar and from the drop-down menu select needed tool, see Figure Figure 24: “Add”... -
Page 27: Figure 26: Signal Labels And Control Panels
UM-GP-006 GreenPAK Pro Development Platform After all settings have done, signal label near pin will change in accordance with the selected tool. When mouse move on signal label, it shows available tools in pop-up control panel, see Figure Figure 26: Signal Labels and Control Panels The purpose of the logic generator is to provide clock pulses for the Counter block. -
Page 28: Figure 28: Emulator Controls Window
UM-GP-006 GreenPAK Pro Development Platform After all settings are done, click button “Emulation” from Emulation Controls window to start emulation process. signal generators) press button “Start All”, see To start all logic and signal generators (expect V Figure Figure 28: Emulator Controls Window Functionality Waveform Channel 1 (yellow/top) –... -
Page 29: Figure 30: Waveform, No Triggered On Button Released
UM-GP-006 GreenPAK Pro Development Platform Figure 30: Waveform, no Triggered on Button Released Channel 1 (yellow/top) – Logic generator Channel 2 (light blue/2nd line) – Button, 1 - enable Counter; 0 - disable Counter Channel 3 (magenta/3rd line) – Counter output... -
Page 30: Conclusion
GreenPAK Pro Development Platform Conclusion This GreenPAK Pro Development Platform is a truly versatile tool. It allows the designer to create a custom project within minutes, without using additional devices (except oscilloscope). For more information please visit our website https://www.dialog-semiconductor.com/. -
Page 31: Appendix A Electrical Specification
UM-GP-006 GreenPAK Pro Development Platform Appendix A Electrical Specification Mode Parameter Units Test Point Capacitance Input Leakage Current General Max Current through Protection Diode to V Voltage Range Power Supply Max Current ±30 Voltage Output Total Error Number of Channels... -
Page 32: Revision History
UM-GP-006 GreenPAK Pro Development Platform Revision History Revision Date Description Added section Generators 15-Sep-2021 Updated according to Dialog’s Writing Guideline User Manual Revision 1.1 15-Sep-2021 © 2021 Dialog Semiconductor CFR0012 32 of 33... - Page 33 Dialog Semiconductor product (or associated software) can reasonably be expected to result in personal injury, death or severe property or environmental damage.
