Summary of Contents for Outlaw LFM-2
- Page 1 LFM Series Low Frequency Modules LFM-1 Compact and LFM-2 Owner’s Manual Version 1.0...
- Page 2 If water or any metal object, such as a paper clip, coin or a staple, accidentally falls inside the unit, disconnect it from the AC power source immediately, and contact Outlaw Audio for further instructions.
-
Page 3: Table Of Contents
11 The Outlaw Audio 0-Day Satisfaction Guarantee 11 Outlaw Audio Limited Warranty The contents of this manual are Copyright © 2007 by Outlaw Audio, LLC, and may not be duplicated or reproduced by any means, whether physical, electronic or otherwise without prior written consent from Outlaw Audio. -
Page 4: Before You Begin
These spikes provide the ground clearance that is required for optimal performance and safety. Failure to use the feet provided will result in damage not covered under the Outlaw Audio Warranty. For your convenience we have provided “dimpled discs“ that may be used when the LFM is placed on surfaces other than carpet, such as wood, tile, certain rugs and linoleum surfaces to prevent damage to the floor or floor covering. -
Page 5: Subwoofers, Bass And Overall System Performance
Fuse Housing Contains a 20mm 2.5A slow blow fuse (LFM-1 Compact), or 20mm 1.6A slow blow fuse (LFM-2) that protects the subwoofer. In the event that it must be replaced, be certain that a fuse with the same rating is used. - Page 6 Owner’s Manual Wiring Diagrams Diagram 1: Connecting to a System with a Subwoofer Preamp Output Outlaw Audio...
-
Page 7: Connecting To A System With No Preamp Outputs
. Connect one end of the subwoofer cable to the subwoofer or LFE output on the receiver or processor. 4. Locate the connection labeled SUB IN on the rear panel of the subwoofer and connect the other end of the subwoofer cable to that jack. 5. Plug the LFM’s power cord into the input on the LFM Series Subwoofer and connect the plug to an un-switched AC outlet. CAUTION: Due to the power requirements of the LFM, it must not be connected to the accessory outlets on a receiver or processor. If a power-strip or surge protector is used, make certain that it is rated to accommodate your LFM’s power requirements. -
Page 8: Setting The Lfm Controls
Y-adapter that is of equal or better quality than the subwoofer cables you intend to use. (We recommend the Outlaw Audio PCA Y-Adapter.) To use the Y-adapter, insert the single male end of the cable to the subwoofer output of your receiver or processor. -
Page 9: Care And Maintenance
If the fuse is blown, replace the fuse with a 20 mm 2.5A slow blow fuse (LFM-1 Compact) or 20mm 1.6A slow blow fuse (LFM-2). If the fuse blows again, the output transistors are probably damaged. Email or call technical support for further assistance. -
Page 10: Model Lfm-1 Compact Specifications
0 to 180 Degrees 112dB (subject to placement and room gain) Dimensions (HxWxD) 16.75” x 13.0” x 19.0” Weight 55 lbs Outlaw Audio Model LFM- Specifications Driver Type Down Firing, 8" Long-throw Woofer Ports Single Amplifier Power Rating 150WRMS; 800W peak Frequency Response 25Hz -180Hz ±... -
Page 11: The Outlaw Audio 0-Day Satisfaction Guarantee
Outlaw Audio shall not be liable for, in any way responsible for, any inci- dental or consequential damages of any kind. Some states do not allow...
