Kidde Fire Systems Argonite Design, Installation & Maintenance Instruction page 43

Assembly Part
Valve Size
1/2 in. 38-509848-001
3/4 in. 38-509848-002
1 in. 38-509848-003
1¼ in. 38-509848-004
1½ in. 38-509848-005
2 in. 38-509848-006
Note: The Selector Valve Assembly part numbers listed only include the Valve, Actuator and Reset Handle.
Part Number
38-509848-001
38-509848-002
38-509848-003
38-509848-004
38-509848-005
38-509848-006
38-509837-001
38-509813-001
38-509814-001
38-509858-001
July 2004
Number
A B
5.53 2.77
6.24 3.12
6.24 3.12
8.24 4.14
9.74 4.87
10.57 5.28
1/2" Valve, Actuator and Reset Handle Only
3/4" Valve, Actuator and Reset Handle Only
1" Valve, Actuator, and Reset Handle Only
1¼" Valve, Actuator and Reset Handle Only
1½" Valve, Actuator and Reset Handle Only
2" Valve, Actuator and Reset Handle Only
Solenoid, 24 Vdc, 3-Way, Weatherproof
Nipple Connector 1/8" x 1/4" NPT (1/2" to 1½" Valves)
Nipple Connector 1/4" x 1/4" NPT (2" Valves Only)
Closing Instructions Nameplate
®
Dimensions
C D E F
2.14 6.97 1.55 2.73
2.46 7.29 1.92 3.50
2.46 7.52 1.92 3.60
2.80 8.65 2.10 3.93
3.05 9.35 2.47 4.55
3.29 10.02 2.66 4.94
Description
6-11
Nipple Connector
G H J
2.77 1.14 0.50 38-509813-001
3.27 1.42 0.88 38-509813-001
3.27 1.42 0.88 38-509813-001
3.72 1.67 1.00 38-509813-001
4.18 1.95 1.25 38-509813-001
4.84 2.20 1.50 38-509814-001
38-KFSARG-000
