- Page 1 RS-232 Level Shift Board # 15357 Operation Manual...
- Page 2 Front Views RS232 IN Connect to a PC/laptop or any RS-232 command system with a D-Sub 9-pin male null cable to send RS-232 commands to the control device. USB 5V Connect the USB cable (included in the package) to a PC/laptop...
- Page 3 POWER This LED will illuminate when the device is connected to an active power supply. Rear Views RS232 OUT Connect to the RS-232 equipped device to be controlled with a D-Sub 9pin female null cable. RS-232 Protocols INPUT OUTPUT Definition Definition ◄...
- Page 4 Connection Diagram...
- Page 5 Specifications Baud Rate 110 bps~921, 600 bps Input Port D-Sub 9-pin (Female) Output Port D-Sub 9-pin (Male) ESD Protection Human body model: ±8kV (air-gap discharge) ±4kV (contact discharge) Power Supply USB bus power or USB to DC power supply Dimensions 71mm (W)×81.5mm (D)×23mm(H) Weight 110g...
