- Page 1 HDMI Switch Selector 8 in 1 out - ID# 707 Operation Manual...
- Page 2 Introduction HDMI Switch Selector is a high performance HDMI switcher with remote control. It allows your various HDMI sources to share one HDTV display. Simply press a button to select your desired HDMI source to be displayed on the HDTV. Features 1 .
- Page 3 HDMI inputs: Connect your various HDMI sources to each of the HDMI input of the unit using HDMI cables. Power: Plug the supplied 5VDC power supply into the unit. RS232: 9-pin D-sub female connector for connecting to your other control console for remote control.
-
Page 4: Specifications
RS-232 command * The command is combined with a characters and digits. *This combination command code has to be separated by ASCII character SPACE *The command will be executed after ASCII character "CR" input * After ASCII character "CR" is entered, if the command is legal the unit will reply "OK" message * If the command is illegal, The unit will reply "NG"...
