Heat-N-Glo SL-550TR-CE-C Installer's Manual
  1. Manuals
  2. Brands
  3. Heat-N-Glo Manuals
  4. Fireplace Accessories
  5. SL-550TR-CE-C
  6. Installer's manual
Heat-N-Glo SL-550TR-CE-C Installer's Manual

Heat-N-Glo SL-550TR-CE-C Installer's Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Model:
SL-550TR-CE-C
WARNING:
IF THE INFORMATION IN THESE
INSTRUCTIONS IS NOT
FOLLOWED EXACTLY, A FIRE OR
EXPLOSION MAY RESULT
CAUSING PROPERTY DAMAGE,
PERSONAL INJURY, OR DEATH.
-
Do not store or use petrol or other flam-
mable vapors and liquids in the vicinity of
this or any other appliance.
-
What to do if you smell gas
• Do not try to light any appliance.
• Do not touch any electrical switch.
• Do not use any phone in your building.
• Immediately call your gas supplier from
a neighbor's phone. Follow the gas
supplier's instructions
• If you cannot reach your gas supplier,
call the fire department.
-
Installation and service must be performed
by a qualified installer or competent
person.
Printed in U.S.A.
Copyright 2002,
Heat-N-Glo, a division of Hearth Technologies Inc.
20802 Kensington Blvd., Lakeville, MN 55044
This product is covered by one or more of the following patents: (United States) 4,112,913; 4,408,594; 4,422,426; 4,424,792; 4,520,791; 4,793,322;
4,852,548; 4,875,464; 5,000,162; 5,016,609; 5,076,254 5,191,877; 5,218,953; 5,328,356; 5,429,495; 5,452,708; 5,542,407; 5,613,487; (Australia)
543790; 586383; (Canada) 1,123,296; 1,297,746; 2,195,264; (Mexico) 97-0457; (New Zealand) 200265; or other U.S. and foreign patents pending.
Installers Guide
READ THIS MANUAL BEFORE INSTALLING OR
OPERATING THIS APPLIANCE. THIS INSTALLERS
GUIDE MUST BE LEFT WITH APPLIANCE FOR
FUTURE REFERENCE.
WARNING: IMPROPER INSTALLATION,
ADJUSTMENT, ALTERATION, SERVICE
OR MAINTENANCE CAN CAUSE INJURY
OR PROPERTY DAMAGE. REFER TO
THIS MANUAL. FOR ASSISTANCE OR
ADDITIONAL INFORMATION CONSULT A
QUALIFIED INSTALLER OR
COMPETENT PERSON.
These instructions are only valid if the
following country symbol is on the appliance.
If this symbol is not present on the appliance,
it is necessary to refer to the technical
instructions which will provide the necessary
information concerning the modification of the
appliace to the conditions of use for the
country.
These instructions are valid for the following
countries: GB, IE
Please contact your Heat-N-Glo dealer with any
questions or concerns. For the number of your nearest
Heat-N-Glo dealer, please call 1-888-427-3973.
0087
1
529-985C 9/02

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SL-550TR-CE-C and is the answer not in the manual?

Questions and answers

Related Manuals for Heat-N-Glo SL-550TR-CE-C

Summary of Contents for Heat-N-Glo SL-550TR-CE-C

  • Page 1 GB, IE Printed in U.S.A. Copyright 2002, Please contact your Heat-N-Glo dealer with any Heat-N-Glo, a division of Hearth Technologies Inc. questions or concerns. For the number of your nearest 20802 Kensington Blvd., Lakeville, MN 55044 Heat-N-Glo dealer, please call 1-888-427-3973.
