Heat-N-Glo Pier-TRC-CE Installer's Manual

Heat-N-Glo Pier-TRC-CE Installer's Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Models:
Pier-TRC-CE
ST-TRC-CE
L-Corner-TRC-CE
R-Corner-TRC-CE
WARNING:
IF THE INFORMATION IN THESE
INSTRUCTIONS IS NOT
FOLLOWED EXACTLY, A FIRE OR
EXPLOSION MAY RESULT
CAUSING PROPERTY DAMAGE,
PERSONAL INJURY, OR DEATH.
-
Do not store or use petrol or other flam-
mable vapors and liquids in the vicinity of
this or any other appliance.
-
What to do if you smell gas
• Do not try to light any appliance.
• Do not touch any electrical switch.
• Do not use any phone in your building.
• Immediately call your gas supplier from
a neighbor's phone. Follow the gas
supplier's instructions
• If you cannot reach your gas supplier,
call the fire department.
-
Installation and service must be performed
by a qualified installer or competent
person.
Printed in U.S.A. Copyright 2002,
Heat-N-Glo, a division of Hearth Technologies Inc.
20802 Kensington Blvd., Lakeville, MN 55044
This product is covered by one or more of the following patents: (United States) 4,112,913; 4,408,594; 4,422,426; 4,424,792; 4,520,791; 4,793,322;
4,852,548; 4,875,464; 5,000,162; 5,016,609; 5,076,254 5,191,877; 5,218,953; 5,328,356; 5,429,495; 5,452,708; 5,542,407; 5,613,487; (Australia)
543790; 586383; (Canada) 1,123,296; 1,297,746; 2,195,264; (Mexico) 97-0457; (New Zealand) 200265; or other U.S. and foreign patents pending.
READ THIS MANUAL BEFORE INSTALLING OR
OPERATING THIS APPLIANCE. THIS INSTALLERS
GUIDE MUST BE LEFT WITH APPLIANCE FOR
FUTURE REFERENCE.
WARNING: IMPROPER INSTALLATION,
ADJUSTMENT, ALTERATION, SERVICE
OR MAINTENANCE CAN CAUSE INJURY
OR PROPERTY DAMAGE. REFER TO
THIS MANUAL. FOR ASSISTANCE OR
ADDITIONAL INFORMATION CONSULT
A QUALIFIED INSTALLER OR
COMPETENT PERSON.
These instructions are only valid if the
following country symbol is on the appliance.
If this symbol is not present on the appliance,
it is necessary to refer to the technical
instructions which will provide the necessary
information concerning the modification of the
appliance to the conditions of use for the
country.
These instructions are valid for the following
countries: GB, IE
Please contact your Heat-N-Glo dealer with any
questions or concerns. For the number of your nearest
Heat-N-Glo dealer, please call 952-985-6000.
1
Installers Guide
682-900 2/02

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Pier-TRC-CE and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Heat-N-Glo Pier-TRC-CE

Summary of Contents for Heat-N-Glo Pier-TRC-CE

  • Page 1 These instructions are valid for the following person. countries: GB, IE Printed in U.S.A. Copyright 2002, Please contact your Heat-N-Glo dealer with any Heat-N-Glo, a division of Hearth Technologies Inc. questions or concerns. For the number of your nearest 20802 Kensington Blvd., Lakeville, MN 55044 Heat-N-Glo dealer, please call 952-985-6000.

  • Page 2: Safety And Warning Information

    SAFETY AND WARNING INFORMATION READ and UNDERSTAND all instructions carefully This gas stove and flue assembly MUST be vented before starting the installation. FAILURE TO directly to the outside and MUST NEVER be FOLLOW these installation instructions may result attached to a chimney serving a separate solid fuel in a possible fire hazard and will void the warranty.

  • Page 3: Table Of Contents

    Appliance Certification ..............12 Installation Codes ................. 12 High Altitude Installations .............. 12 Section 2: Getting Started ............13 Introducing the Heat-N-Glo Gas Fireplaces ......... 13 Pre-installation Preparation ............13 Section 3: Installing the Fireplace ........... 17 Step 1 Locating the Fireplace ..........17 Step 2 Framing the Fireplace...........

  • Page 4: Service Parts Lists

    Service Parts PIER-TRC-CE Exploded Parts Diagram Log Assembly * Part number list on following page.
  • Page 5 PIER-TRC-CE (NG, LP) Exploded Parts Diagram IMPORTANT: THIS IS DATED INFORMATION. The most current information is located on your dealers VIP site. When ordering, supply serial and model numbers to ensure correct service parts. ITEM PARTS SERIAL # PART NUMBER...
  • Page 6 Service Parts ST-TRC-CE Exploded Parts Diagram Log Assembly * Part number list on following page.
  • Page 7 ST-TRC-CE (NG, LP) Exploded Parts Diagram IMPORTANT: THIS IS DATED INFORMATION. The most current information is located on your dealers VIP site. When ordering, supply serial and model numbers to ensure correct service parts. ITEM PARTS SERIAL # PART NUMBER ON/OFF Rocker Switch 060-511 Burner Orifice NG...
  • Page 8 Service Parts L-CORNER-TRC-CE Exploded Parts Diagram Log Assembly * Part number list on following page.
  • Page 9 L-CORNER-TRC-CE (NG, LP) Exploded Parts Diagram IMPORTANT: THIS IS DATED INFORMATION. The most current information is located on your dealers VIP site. When ordering, supply serial and model numbers to ensure correct service parts. ITEM PARTS SERIAL # PART NUMBER ON/OFF Rocker Switch 060-511 Burner Orifice NG...
  • Page 10 Service Parts R-CORNER-TRC-CE Exploded Parts Diagram / Vue éclatée des pièces Log Assembly * Part number list on following page.
  • Page 11 R-CORNER-TRC-CE (NG, LP) Exploded Parts Diagram IMPORTANT: THIS IS DATED INFORMATION. The most current information is located on your dealers VIP site. When ordering, supply serial and model numbers to ensure correct service parts. ITEM PARTS SERIAL # PART NUMBER ON/OFF Rocker Switch 060-511 Burner Orifice NG...

  • Page 12: Section 1: Approvals And Codes

    Installation Regulations Appliance Certification Before installation check that local distribution conditions, The Heat-N-Glo fireplace models discussed in this Installers nature of gas and pressure, and adjustment of the appliance Guide have been tested to certification standards and listed are compatible.

  • Page 13: Section 2: Getting Started

    Getting Started Introducing the Heat-N-Glo Gas Fireplaces The Heat-N-Glo Warranty will be voided by, and Heat-N-Glo disclaims any responsibility for, the following actions: Heat-N-Glo direct flue gas fireplaces are designed to oper- • Installation of any damaged fireplace or flue system com- ate with all combustion air siphoned from outside of the ponent.
  • Page 14 102mm 616mm 1035mm LEFT SIDE FRONT RIGHT SIDE TOP STANDOFFS TOP VENT COLLARS REAR COLLARS TOP GRILLE SIDE GLASS DOOR END GLASS DOOR BOTTOM GRILLE GAS CONTROLS & LABELS ELECTRICAL GAS LINE ACCESS ACCESS Figure 1. Diagram of the PIER-TRC-CE...
  • Page 15 1143mm 330mm 616mm 308mm VENT COLLARS 1042mm ELECTRICAL GAS LINE ACCESS ACCESS 937mm 733mm 64mm 64mm 918mm 616mm 102mm 1093mm 102mm LEFT SIDE FRONT RIGHT SIDE TOP VENT COLLARS REAR VENT COLLARS TOP STANDOFFS TOP GRILLE GLASS DOOR BOTTOM GRILLE GAS CONTROLS &...
  • Page 16 1086mm 330mm 642mm 308mm VENT COLLARS 1041mm ELECTRICAL GAS LINE 733mm ACCESS ACCESS 937mm 64mm 64mm 102mm 918mm 102mm 616mm 1034mm LEFT SIDE FRONT RIGHT SIDE TOP VENT COLLARS REAR VENT COLLARS TOP STANDOFFS TOP GRILLE SIDE GLASS DOOR END GLASS DOOR BOTTOM GRILLE...

  • Page 17: Section 3: Installing The Fireplace

    Installing the Fireplace Step 1. Locating the Fireplace Minimum Clearances The diagram below shows space and clearance require- from the Fireplace to Combustible Materials ments for locating a fireplace within a room. Glass Sides or Ends ....... 915 mm Floor ............0 Rear Flue ..........
  • Page 18 The center of the hole is L-CORNER-TRC-CE one inch 26mm above the center of R-CORNER-TRC-CE the horizontal flue pipe. Framing should be constructed of 2 X 4 lumber or heavier. ST-TRC-CE PIER-TRC-CE Model FLUE FLUE REAR PIER-TRC-CE 1099 1023 1054...
  • Page 19 220mm DV-45D 1.2m 908mm 298mm 222mm 146mm DV-09D DV-12D DV-06D NOTE: PIPES OVERLAP 34.93mm AT EACH JOINT. Figure 6. D-Series Direct Flue Component Specifications (127mm inner pipe / 219mm outer pipe)

  • Page 20: Step 3 Installing The Flue System

    Step 3. Installing the Flue System Identifying Flue Components The flue systems installed on this gas fireplace may in- A. Flue System Approvals clude one, two, or three 90° elbow assemblies. The rela- These models are approved to use D-series direct flue pipe tionships of vertical rise to horizontal run in flue configura- components and terminations (see Figures 6 and 7).
  • Page 21 STRAIGHT UP VERTICAL FLUEING MAX. RUN 12.2 m Figure 8. Straight Up Vertical Flueing STRAIGHT OUT HORIZONTAL FLUEING MAX. RUN 610 mm Figure 9. Straight Out Horizontal Flueing...
  • Page 22 FLUEING WITH ONE (1) 90° ELBOW MIN. 305mm MAX. 610mm MIN. 610mm MAX. 1.22m MIN. 914mm MAX. 1.86m MIN. 1.22m MAX. 2.4m V+H = MAX. 11.3m H = MAX. 2.4m Figure 10. Flueing with One 90° Elbow FLUEING WITH ONE (1) 90° ELBOW MIN.
  • Page 23 FLUEING WITH TWO (2) 90° ELBOWS H + H MIN. 305mm MAX. 914mm MIN. 610mm MAX. 1.86m MIN. 914mm MAX. 2.7m MIN. 1.22m MAX. 3.6m MIN. 1.5m MAX. 4.5m MIN. 1.86m MAX. 5.1m MAX. 5.1m V + H + H = MAX.
  • Page 24 FLUEING WITH TWO (2) 90° ELBOWS H + H MIN. 305 mm MAX. 610 mm MAX. 914 mm MIN. 610 mm MAX. 1.22 m MAX. 1.86 m MIN. 914 mm MAX. 1.86 m MAX. 2.7 m MIN. 1.22 m MAX. 2.48 m MAX.
  • Page 25 FLUEING WITH THREE (3) 90° ELBOWS FLUEING WITH THREE (3) 90° ELBOWS H + H MIN. 305 mm MAX. 610 mm MAX. 914 mm MIN. 610 mm MAX. 1.22 m MAX. 1.86 m MIN. 914 mm MAX. 1.86 m MAX. 2.7 m MIN.
  • Page 26 FLUEING WITH THREE (3) 90° ELBOWS MIN. 305mm MAX. 914mm MIN. 610mm MAX. 1.86m MIN. 914mm MAX. 2.7m MIN. 1.22m MAX. 3.6m MAX. 5.1m H + H = MAX. 5.1m V + V + H + H = MAX. 11.3m FLUEING WITH THREE (3) 90°...

  • Page 27: Installing Flue Components

    B. Installing Flue Components 1. Attach the First Flue Component to the Starting Collars After determining which set of starting collars will be used (top or rear), follow flueing instructions accordingly. To attach the first flue component to the starting collars of Flueing Out the Rear Flue the fireplace: Remove the installed rear seal cap from the rear starting...
  • Page 28 2. Continue Adding Flue Components WALL BRACKET • Continue adding flue components, locking each succeed- ing component into place. • Ensure that each succeeding flue component is secure- WALL STUD ly fitted and locked into the preceding component in the flue system.
  • Page 29 For Vertical Runs - One ceiling firestop is REQUIRED at If the area above the ceiling is NOT an attic, position and the hole in each ceiling through which the flue passes. secure the ceiling firestop on the ceiling side of the previously cut and framed hole.

  • Page 30: Flue Termination

    C. Flue Termination For Horizontal Terminations - To attach and secure the termination to the last section of horizontal flue: • Rotate and interlock the ends as described at the begin- ning of the Installing Flue Components section. • The termination kit should pass through the wall firestops from the exterior of the building.
  • Page 31 For Vertical Terminations - To locate the flue and install To seal the roof hole, and to divert rain and snow from the the flue sections: flue system: • Locate and mark the flue centerpoint on the underside of • Attach a flashing to the roof using nails, and use a non- the roof, and drive a nail through the centerpoint.

  • Page 32: Positioning, Leveling, And Securing The Fireplace

    Step 4. Positioning, Leveling, and Step 5. The Gas Control System Securing the Fireplace WARNING: THIS UNIT IS NOT FOR USE WITH The diagram below shows how to properly position, level, SOLID FUEL. and secure the fireplace. Standing Pilot Ignition System This system includes millivolt control valve, standing pilot, thermopile/thermocouple flame sensor, and piezo ignitor.

  • Page 33: Step 5 The Gas Control System

    Step 6. The Gas Supply Line Step 7. Gas Pressure Requirements NOTE: Have the gas supply line installed by a qualified Pressure requirements for Heat-N-Glo gas fireplaces are service technician in accordance with all building shown in the table below.

  • Page 34: Step 8 Wiring The Fireplace

    OPTIONAL WALL SWITCH THERMOSTAT OR REMOTE THERMOCOUPLE TP/TH THERMOPILE ON/OFF REMOTE SWITCH GAS VALVE SWITCH PIGTAIL Figure 32. Standing Pilot Ignition Wiring Diagram Step 8. Wiring the Fireplace Remote Wall Switch NOTE: Electrical wiring must be installed by a compe- tent electrician.

  • Page 35: Step 9 Finishing

    QUIRED TO BE SEALED. ONLY NON-COMBUSTIBLE CEILING MATERIAL (USING 150° C. MINIMUM ADHESIVE, IF NEEDED) CAN BE APPLIED AS FACING TO THE FIRE- PLACE SURROUND. SEE THE DIAGRAM BELOW. NOTE: Sheetrock or other combustible material such 788mm 305mm as wood can be placed on the top edge of the fire- place.

  • Page 36: Step 10 Installing Trim, Logs, And Ember Material

    Placing the Ember Material Step 10. Installing Trim, Logs & Ember Material Installing the Trim The bag labeled Glowing Ember (050-721) is standard glow- Combustible materials may be brought up to the specified ing ember material. clearances on the side and top front edges of the fireplace, To place the ember material: but MUST NEVER overlap onto the front face.

  • Page 37: Step 11 Before Lighting The Fireplace

    Step 12. Lighting the Fireplace Step 11. Before Lighting the Fireplace You’ve reviewed all safety warnings, you’ve checked the Before lighting the fireplace, be sure to do the following: fireplace for gas leaks, you know the flue system is Remove all paperwork from underneath the fireplace. unobstructed, and you’ve checked for faulty components.

  • Page 38: Section 4: Maintaining And Servicing Your Fireplace

    Maintaining and Servicing Your Fireplace Checking Flue System Fireplace Maintenance Frequency: Before initial use and at least annually Although the frequency of your fireplace servicing and main- thereafter, more frequently if possible. tenance will depend on use and the type of installation, you By: Qualified service technician/Home owner.

  • Page 39: Section 5: Troubleshooting

    Troubleshooting With proper installation, operation, and maintenance the gas fireplace will provide years of trouble-free service. If you do experience a problem, this trouble shooting guide will assist a qualified service person in the diagnosis of a problem and the corrective action to be taken.
  • Page 40 Troubleshooting continued Symptom Possible Cause Corrective Action 4. Frequent pilot a. Pilot flame may be too high or Clean and adjust the pilot flame for maximum flame impingement on outage problem. too low, or blowing (high), thermocouple. Follow lighting instructions carefully. causing pilot safety to drop out.

This manual is also suitable for:

St-trc-ceL-corner-trc-ceR-corner-trc-ce
