- Page 1 MANUAL DIAMOND Congratulations on purchasing a rotary machine DIAMOND! Read the instructions carefully before using the machine.
-
Page 2: Specifications
Specifications Lengt 115 mm Weight 92 g Connector Motor power Voltage 3-10 V Rotational 10,000 rpm speed Faulhaber, Motor Germany Designed in the USA 1 year Warranty and maintenance service... - Page 3 Working voltage: 3.5-10 V The device not designed to operate at higher voltages. Short stroke: 2.5 mm DIAMOND device is a short stroke device, therefore, in order to avoid pigment leakage, it is highly recommended to adjust the needle stickout to 1-2 mm.
- Page 4 Complement Device, RCA clipcord, Friction Stabilizing O-Ring...
- Page 5 Motor Faulhaber Swivel holder Cartridge slot RCA slot RCA clip cord Friction Stabilizing O-Ring Warranty card...
-
Page 6: Maintenance Instruction
Maintenance instruction 1. Attach special barrier protection film to the clipper and RCA cable (5) 2. Insert the modular needle (cartridge) into the slot (3). To secure, turn the cartridge clockwise until the module snaps into place. Different manufacturers of modules have various fitting dimensions, which makes them less likely to fit into the holder. - Page 7 3. Adjust the needle stickout. It can be adjusted by rotating the rotary holder (2). The DIAMOND device is a short stroke device, therefore, in order to avoid pigment leakage, it is highly recommended to adjust the stroke to 1-2 mm.
- Page 8 4. Connect device to the power source using the RCA cable (4). Turn on the power supply. Set the voltage on the power supply to 3-7 V, depending on the needle configuration and working technique. Do not exceed the maximum voltage of 10 V.
- Page 9 Do not turn the device over in the process of work. The device is not designed for this and will emit crackling and atypical sounds. Service Keep the device clean. Before and after each use, remove all possible dirt by wiping the machine with a special disinfectant.
- Page 10 Sterilization In order to sterilize the device, unscrew the holder and place it inside of an autoclave with an ultrasonic bath or oven. Do not store the holder in a dry oven at temperatures higher than 100 ° Celsius (73.15 ° Kelvin, 212 ° Fahrenheit): this will lead to the change of colour.
-
Page 11: Warranty
Warranty Device will be covered by a 1-year warranty from the date of purchase. The warranty covers factory faults and does not apply in the following cases: The input voltage exceeded 11 V (the maximum allowable voltage is 10 V). The device was damaged due to aggressive non-alcoholic antiseptics. - Page 12 As none of the methods of permanent make-up involves working from the bottom up, DIAMOND device is not adapted for such manipulations. Please do not turn the device over in the process of work.
