Operation Manual
Multi-CD control High power CD/MP3/WMA player
with FM/AM tuner
DEH-P1Y

Advertisement

Table of Contents
loading

Related Manuals for Pioneer DEH-P1Y

Summary of Contents for Pioneer DEH-P1Y

  • Page 1 Operation Manual Multi-CD control High power CD/MP3/WMA player with FM/AM tuner DEH-P1Y...

  • Page 2: Table Of Contents

    Contents Thank you for buying this Pioneer product. Please read through these operating instructions so you will know how to operate your model properly. After you have finished reading the instructions, keep this man- ual in a safe place for future reference.
  • Page 3 Contents Displaying text information on MP3/WMA/ TV tuner WAV disc 27 Watching the TV tuner 36  When playing back an MP3/WMA Introduction of advanced TV tuner disc 27 operation 37  When playing back a WAV disc 27 Storing broadcast stations 37 Scrolling text information in the display 28 Recalling broadcast stations 37 Selecting tracks from the file name list 28...
  • Page 4 Contents Using nonfading output 46 MP3, WMA and WAV files 57  Adjusting nonfading output level 47  MP3 additional information 58  WMA additional information 58 Using the high pass filter 47  WAV additional information 59 Adjusting source levels 47 Using automatic sound levelizer 48 About folders and MP3/WMA/WAV files 59 Terms 60...

  • Page 5: Before You Start

    Section Before You Start About this manual Features This unit features a number of sophisticated CD playback functions ensuring superior reception and op- Music CD/CD-R/CD-RW playback is possible. eration. All the functions have been designed for the easiest possible use, but many are not MP3 file playback self-explanatory.

  • Page 6: Resetting The Microprocessor

    Section Before You Start The Windows Media" logo printed on the box % Press RESET with a pen tip or other indicates that this unit can play back WMA pointed instrument. data. WMA is short for Windows Media Audio and refers to an audio compression technology that is developed by Microsoft Corporation.

  • Page 7: Removing The Front Panel

    Section Before You Start Removing the front panel About the demo mode Press EJECT to open the front panel. This unit features two demonstration modes. One is the reverse mode, the other is the fea- ture demo mode. ! You cannot cancel a demo mode when the front panel is open.

  • Page 8: Use And Care Of The Remote Control

    Section Before You Start Use and care of the remote Using the remote control control Point the remote control in the direction of the front panel to operate. Installing the battery ! The remote control may not function prop- erly in direct sunlight. Slide the tray out on the back of the remote control and insert the battery with the plus (+) and minus () poles pointing in the proper di-...
  • Page 9 Section Before You Start AUDIO button operation % Press AUDIO to select the desired mode. Press AUDIO repeatedly to switch between the following modes: Fad (balance adjustment)EQ (equalizer curve adjustment)Bass (bass and treble level adjustment)Loud (loudness) Sub-W1 (subwoofer on/off setting)/NonFad (nonfading output on/off setting)Sub-W2 (subwoofer setting)/NonFad (nonfading out- put setting)HPF (high pass filter)SLA...

  • Page 10: WhatS What

    Section Whats What 1 2 3 4 Head unit 7 EJECT button Press to eject a CD from your built-in CD 1 ATT button player. Press to quickly lower the volume level, by about 90%. Press once more to return to the 8 EQ-EX button original volume level.

  • Page 11: Remote Control

    Section Whats What i CLEAR button Press to cancel the input number when NUMBER are used. j NUMBER buttons Press to directly select the desired track, preset tuning or disc. Buttons 16 can oper- ate the preset tuning for the tuner or disc number search for the multi-CD player.

  • Page 12: Basic Operations

    Section Basic Operations Turning the unit on ! External unit refers to a Pioneer product (such as one available in the future) that, although % Press SOURCE to turn the unit on. incompatible as a source, enables control of When you select a source the unit is turned basic functions by this unit.

  • Page 13: Adjusting The Volume

    Section Basic Operations ! There is sometimes a delay between starting up CD playback and the sound being issued. When being read in, Format Read is dis- played. ! If you cannot insert a disc completely or if after you insert a disc the disc does not play, check that the label side of the disc is up.

  • Page 14: Tuner

    Section Tuner Listening to the radio Press BAND to select a band. Press BAND until the desired band is dis- played, FM1, FM2, FM3 for FM or AM. 1 2 3 To perform manual tuning, push Multi-Control left or right. The frequencies move up or down step by step.

  • Page 15: Introduction Of Advanced Tuner Operation

    Section Tuner Introduction of advanced Storing broadcast frequencies tuner operation You can easily store up to six broadcast fre- quencies for later recall. When you find a frequency that you want to store in memory press LIST to switch to the preset channel list mode. Use Multi-Control to select the preset number.

  • Page 16: Storing The Strongest Broadcast Frequencies

    Section Tuner % Push Multi-Control up or down to recall # You can also change the station by pushing radio station frequencies. Multi-Control up or down. Pushing Multi-Control up or down selects the preset tuning number. P1  P6 is displayed as Note the preset tuning number is selected.
  • Page 17 Section Tuner # To turn local seek tuning off, press Multi-Control again. Push Multi-Control left or right to set the sensitivity. There are four levels of sensitivity for FM and two levels for AM: FM: Local 1Local 2Local 3Local 4 AM: Local 1Local 2 The Local 4 setting allows reception of only the strongest stations, while lower settings let...

  • Page 18: Built-In Cd Player

    Section Built-in CD Player Playing a CD To skip back or forward to another track, push Multi-Control left or right. Pushing Multi-Control right skips to the start of the next track. Pushing Multi-Control left once skips to the start of the current track. Pushing again will skip to the previous track.

  • Page 19: Introduction Of Advanced Built-In Cd Player Operation

    Section Built-in CD Player Introduction of advanced ! If you do not operate the function within about 30 seconds, the display is automatically re- built-in CD player operation turned to the playback display. Repeating play Repeat play lets you hear the same track over again.

  • Page 20: Scanning Tracks Of A Cd

    Section Built-in CD Player Scanning tracks of a CD Selecting the search method Scan play lets you hear the first 10 seconds of You can switch the search method between each track on the CD. fast forward/reverse and searching every 10 tracks.
