Panasonic ES-LV81 Service Manual page 6

Model No. : ES-LV81 Parts List
Ref.
Safety Part No.
No.
ES-LV81
1 WESLV90X7158
2 WESLV81K0048
3 WES9171Y
4 WES9170Y
5 WESLV90L1007
6 WESLV90L1087
7 WESLV90L1077
8 WESLV90L1177
9 WESLV90L0327
10 WESLV90L1507
11 WESLV81K3058
12 WESLV90H3067
13 WESLV90K3367
14 WESLV90K3857
15 WESLA92L0487
16 WES8258L0497
17 WES8238H0527
18 WESLV81L2128
19 WES8163L2504
20 WES8176L6007
21 WESLV81K3121
22 WES8176L6057
23 WESLV81K3031
24 WESLV90K7663
25 WESLV90K7358
26 WESLV81K4218
27 WES035K7771
28 WESLA92K3747
29 WES8093H7057
30 WES8196X7918
- WESLV81K8003
- WESLV81K8101
Part Name & Description
PROTECTIVE CAP
OUTER FOIL FRAME
OUTER FOIL
INNER BLADE
LINEAR MOTOR ASSEMBLY
TRIMMER DRIVING BAR
SLIT BLADE DRIVING BAR
FINISHING BLADE DRIVING BAR
WATERPROOF RUBBER
TRIMMER
HOUSING A
HOUSING B
REAR PANEL
TOP REAR PANEL
CONNECTING PLATE
TERMINAL BASE
TERMINAL COVER
MODULE
RECHARGEABLE BATTERY
P TIGHT SCREW
BOTTOM COVER
TAPPING SCREW
BODY BLOCK
CHARGING ADAPTOR
WATER TANK
SELF-CLEANING RECHARGER
DETERGENT CARTRIDGE
SOFT CASE
CLEANING BRUSH
OIL
INDIVIDUAL BOX
OPERATING INSTRUCTIONS
Q'ty Remarks
1
1
1
1ST
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1 (LI-ION TYPE)
8 (M2-12)
1
1 (M2-8)
1
1 (C-2 PLUG)
1
1
1 (2PCS/PK)
1
1
1
1
1
