List of Models and Technical Specifi cations
NOTE
The cross in the grey box shows the purchased Compressor Model.
Meaning of the symbols in the table on this page and on the following pages.
2-cylinder
head
Dimensions in cm
(W x D x H)
NOTE The electrical data are shown on the CE plate affi xed to the compressor
and reproduced on page 1- 04 of this document.
This manual is the property of
Compressor
REF
model
REF
SMALLMIRAGE70
SMALLMIRAGE100
SMALLMIRAGE130
MIRAGE70
MIRAGE70E
MIRAGE100
MIRAGE100E
MIRAGE130
Air
receiver
capacity
Weight in kg
L
cm (W x D x H)
15 30 x 40 x 53
15 30 x 40 x 53
15 30 x 40 x 53
25 40 x 40 x 62
25 40 x 52.2 x 62
25 40 x 40 x 62
25 40 x 52.2 x 62
25 40 x 40 x 62
. No part of it may be reproduced in any form.
0 - 02
Dryer (Blue dot if
present)
Noise level
dB (A)
dB
kg
(A)
25 66
25 66
25 67
30 66
35 66
30 66
35 66
30 67
