  • Page 1 Setting instructions and Setting instructions and wiring diagram wiring diagram WAREMA WMS awning drive/black-out blind drive WAREMA WMS awning drive/black-out blind drive Type WMS-ZM Type WMS-ZM For qualified technicians only For qualified technicians only Valid from 8 December 2015 Valid from 8 December 2015 Document number 2009209 [Rev.

  • Page 2: Table Of Contents

    Table of contents Table of contents Information on safety......................3 Commissioning........................3 Information on the limit positions......................... 3 Aids for commissioning..........................3 Setting the motor limit positions........................4 Trial run................................. 6 Learning a hand-held transmitter into the product............7 Drive description....................... 9 Drive type..............................9 Function of the drive.............................9 Learning/moving to the comfort position................

  • Page 3: Information On Safety

    Read through the product instructions before use. Observe all safety and setting instructions. The basic safety instructions INFO can be viewed under (www.warema.de/Sicherheitshinweise). For WMS Hand-held transmitters up to a certain version (see label Rev.D/M on the back), Mode 1 needs to be performed...

  • Page 4: Setting The Motor Limit Positions

    Commissioning Setting the motor limit positions INFO For commissioning, voltage must be applied to the drive.However, voltage should only be applied to one product at a time. The limit positions are not set. The limit positions can also be set via the WMS Central transmitter (as of version D) or the WMS toolkit PC software (as of version 2.00).
  • Page 5 Commissioning Press the UP button/DOWN button. Move to the lower limit position (see Tab. 1/Page "Klack" Press the control button briefly. The drive clicks or jerks briefly. Press the UP button/DOWN button. Move to the upper limit position. Press the control button briefly. The drive waves.

  • Page 6: Trial Run

    Commissioning Trial run Press the DOWN button briefly. The drive stops in the lower limit position. Press the UP button briefly. The drive stops in the upper limit position. The trial run is completed. The next step is "starting the setting procedure" if the limit positions are not correct, or to connect the drive according to the wiring diagram.

  • Page 7: Learning A Hand-Held Transmitter Into The Product

    Learning a hand-held transmitter into the product Learning a hand-held transmitter into the product WMS Hand-held transmitter basic (art. no. 1002953) INFO Only product types of the same type can be operated with a WMS Hand-held transmitter basic. For learning, voltage should only be applied to one receiver. Press the button to wake up the hand-held transmitter.
  • Page 8 Learning a hand-held transmitter into the product WMS Hand-held transmitter (art. no. 1002767) Press the button to wake up the hand-held trans- mitter. Press the learn button for approx. 5 seconds. lights up green and the transmission LED flashes. Red = new receiver Green = the receiver al- ready belongs to the net- work...

  • Page 9: Drive Description

    Drive description Drive description Responsive obstacle detection If the product encounters an obstacle in the outward Drive type direction, the drive stops the movement and then briefly moves in the opposite direction to move clear of the The drive is designed for 230 V/50 Hz and features an obstacle.

  • Page 10: Learning/Moving To The Comfort Position

    Learning/moving to the comfort position Learning/moving to the comfort position Press the UP button/DOWN button. Move to the desired position. Press the comfort button for approx. 5 s. The transmission LED  lights up. Explanation of the colours: Green = position stored Red = procedure failed Briefly press the comfort button .

  • Page 11: Wiring Diagram

    Degree of protection IP 44 Safety class Short-term operation (S2) 4 min. Limit switch range 64 revolutions Transmission frequency 2.40–2.48 GHz Transmission power < 10 dBm INFO Detailed technical data can be requested from WAREMA. 2009209 [Rev. 4 - en]/2015-12-08 Page 11 | 14...

  • Page 12: Possible Faults

    Possible faults Possible faults Malfunction: drive does not move Cause Note Remedy No voltage is applied. The transmission LED on the hand- Check the fuse. held transmitter lights up green and then red during operation. Connect the test cable and operate the product with the hand-held transmitter.
  • Page 13 Possible faults Malfunction: The drive moves in steps in the outward direction and moves normally in the inward direction. Cause Note Remedy The heartbeat wind safety function is On the WMS Hand-held transmitter, Check the communication between the active. the LED under the wind weather sym- drive and sensors.
  • Page 14 Cause Note Remedy The travel drive and tilting drive are Use the WMS toolkit PC software to not a control package. unify the two drives to a single control package. WAREMA Renkhoff SE Hans-Wilhelm-Renkhoff-Straße 2 97828 Marktheidenfeld Germany www.warema.com info@warema.com...
