SCC-M15.6-xVL-DVR3-x M1.0 Manual
Operations Manual
SCC-M15.6-xVL-DVR3-x M1.0
NOVASUB Surface control case with integrated
camera and light control, DVR3 and 15.6" Touch
daylight screen
Version: 1.0 - Date: 26-11-2020
Advertisement
Table of Contents
Related Manuals for Novasub SCC-M15.6-xVL-DVR3-x M1.0
Summary of Contents for Novasub SCC-M15.6-xVL-DVR3-x M1.0
- Page 1 SCC-M15.6-xVL-DVR3-x M1.0 Manual Operations Manual SCC-M15.6-xVL-DVR3-x M1.0 NOVASUB Surface control case with integrated camera and light control, DVR3 and 15.6” Touch daylight screen Seascape Subsea BV De Hoogjens 22 4254 XW Sleeuwijk Version: 1.0 - Date: 26-11-2020 The Netherlands T. +31-183-307900 info@novasub.com...
-
Page 2: Table Of Contents
SCC-M15.6-xVL-DVR3-x M1.0 Manual Index ABBREVIATIONS / TERMINOLOGY ..............................3 INTRODUCTION ....................................4 DVR3 ........................................4 SPECIFICATIONS ....................................5 MAINTENANCE ....................................6 Maintenance scheme ..................................6 GENERAL ......................................7 Basic Controls ..................................... 8 MONITOR ......................................8 PROCEDURES ..................................... 9 Set up ......................................... 9 Diver comms Connections ................................. -
Page 3: Abbreviations / Terminology
SCC-M15.6-xVL-DVR3-x M1.0 Manual Abbreviations / Terminology Ampere hour Comms Diver Communication Diver Depth Gauge Diver Gas Analyzer DVR3 Digital Video Recorder NovaBus Novasub proprietary data transfer port Volt AC www.novasub.com Version: 1.0 - Date: 26-11-2020 3 of 15... -
Page 4: Introduction
DVR3 The Novasub DVR3 is the 3rd generation video recording software developed by Seascape Subsea. The software is completely redesigned from the ground up to accommodate better ease of use, new features, and better image quality. -
Page 5: Specifications
SCC-M15.6-xVL-DVR3-x M1.0 Manual Specifications System Name SCC-M15.6-xVL-DVR3 Channels 1 or 2 Light Control Regulated 32vdc 0-1,7Ah Camera control Balanced or unbalanced 32vdc (optional 12-32vdc) 15.6” DVR Screen size 1000 nits daylight screen Connectors Umbilical Multipin 2x, With Video, Light & Depth... -
Page 6: Maintenance
Have your system serviced each 2 years by a Novasub Authorized Service Center. This service will include a general operational check, replacement of the battery, and overall upgrade of firmware. The service requires special tools and training. -
Page 7: General
SCC-M15.6-xVL-DVR3-x M1.0 Manual General The system can be seen below. Please note that there can be connections to the side or top of the system as well as on the panel. Data Connections • DVR Screen Light control NovaBus Power •... -
Page 8: Basic Controls
SCC-M15.6-xVL-DVR3-x M1.0 Manual Basic Controls Below you find some of the basic controls that are on almost all panels. Press and hold for 1 second to start up the system. This will start up both the DVR3 and the xDR Press and hold for 1 second to shut down the system. -
Page 9: Procedures
If you also want to record the comms in the DVR3 then you need to connect in addition the “Audio Out” on the communication system to the “Audio in” on the DVR3 using a RCA-RCA cable. For Novasub communication systems this can be separate for each diver .For 3rd party communication systems that only have 1 audio out for all diver you will have... -
Page 10: Dvr3 - Video Software
If your system has a DVR3 it can also be found in the “Help” function. That can be opened with the question mark in the bottom of the screen. This manual can also be found on www.Novasub.com. There you can find your product and the manuals will be on that page under the Downloads Folder: Find this manual here www.novasub.com... -
Page 11: Connectors
SCC-M15.6-xVL-DVR3-x M1.0 Manual Connectors Below you will find all the pin diagrams that can be used. Note that not all are in this system. Power 100-240 vac Type Mating type SCC 01-10c / 11c Diver 1&2, camera,light & comms Type... - Page 12 SCC-M15.6-xVL-DVR3-x M1.0 Manual SCC-01-17 Camera & Light Type Amphenol MS3102A-20-29S Mating type MS3106A-20-29P Function Pin layout GND Light Vcc Light GND Cam Vcc Cam Video + Video - SCC-02-17a Diver 1 &2 Camera,Light & 2 wire comms Type Amphenol MS3102A-20-29S...
- Page 13 SCC-M15.6-xVL-DVR3-x M1.0 Manual 2/4 pin comms Diver 1&2 2 / 4 wire comms Type Banana sockets-4mm Mating type Banana plugs- 4mm Function Pin layout Yellow socket Parallel to comms MIC Yellow socket multipin connector Blue socket Head Parallel to comms Head...
-
Page 14: Help & Support
Further details about a Warranty Statement can be found at the chapter 11 Warranty For technical support contact your local a Novasub Authorized Service Center or Seascape Subsea BV. Seascape Subsea BV is the manufacturer of all Novasub branded products. -
Page 15: Warranty
2. has been repaired using unauthorized spare parts; modified or repaired by unauthorized Service Center; 3. serial number has been removed, altered or made illegible in any way, as determined at the sole discretion of Novasub; 4. has been exposed to chemicals. Novasub does not warrant that the operation of the product will be uninterrupted or error free, or that the product will work with any hardware or software provided by a third party.
