Seascape Subsea BV
De Hoogjens 22
4254 XW Sleeuwijk
The Netherlands
T. +31-183-307900
E.
info@novasub.com
www.novasub.com
www.seascapesubsea.com
Operations Manual
SCC-2DR-DSP Manual
NOVASUB Surface control case with digital two
diver radio and light control.
Version: 1.0 - Date: 26-11-2020
SCC-2DR-DSP Manual
Advertisement
Table of Contents
Related Manuals for Novasub SCC-2DR-DSP
Summary of Contents for Novasub SCC-2DR-DSP
- Page 1 SCC-2DR-DSP Manual Operations Manual SCC-2DR-DSP Manual NOVASUB Surface control case with digital two diver radio and light control. Seascape Subsea BV De Hoogjens 22 Version: 1.0 - Date: 26-11-2020 4254 XW Sleeuwijk The Netherlands T. +31-183-307900 info@novasub.com www.novasub.com www.seascapesubsea.com...
-
Page 2: Table Of Contents
SCC-2DR-DSP Manual Index ABBREVIATIONS / TERMINOLOGY ..............................3 INTRODUCTION ....................................4 xDR ........................................4 SPECIFICATIONS ....................................5 MAINTENANCE ....................................6 Maintenance scheme ..................................6 GENERAL ......................................7 Basic Controls ..................................... 8 PROCEDURES ..................................... 9 Set up ......................................... 9 XDR – DIVER INTERCOM .................................. 10 CONNECTORS .................................... -
Page 3: Abbreviations / Terminology
Abbreviations / Terminology Ampere hour Comms Communication Diver Depth Gauge Diver Gas Analyzer DVR3 Digital Video Recorder Microphone NovaBus Novasub proprietary data transfer port Push To Talk Volt AC Diver intercom radio www.novasub.com Version: 1.0 - Date: 26-11-2020 3 of 16... -
Page 4: Introduction
SCC-2DR-DSP Manual Introduction The Surface Control Case (SCC) is a rugged case. It has a 2 channel digital Diver intercom radio (xDR) and light control. The case has a battery built in that is charged when you are connected to an external power supply. This has smart battery charger and has battery state condition monitoring. -
Page 5: Specifications
SCC-2DR-DSP Manual Specifications System Name SCC-2DRVL-DSP Channels Light Control 2x Optional 32vdc 0-1,7Ah Depth monitoring 2x Optional G4.02 Wireless Connections 2x Optional Connectors Umbilical Multipin 2x, With Comms, Light & Depth Banana 2 Channels, Only Comms 4x Banana for each channel... -
Page 6: Maintenance
Have your system serviced each 2 years by a Novasub Authorized Service Center. This service will include a general operational check, replacement of the battery, and overall upgrade of firmware. The service requires special tools and training. -
Page 7: General
SCC-2DR-DSP Manual General The system can be seen below. Please note that there can be connections to the side or top of the system as well as on the panel. Diver 1 Umbilical connections External power Connection Diver 2 Umbilical connections... -
Page 8: Basic Controls
SCC-2DR-DSP Manual Basic Controls Below you find some of the basic controls that are on almost all panels. Press and hold for 1 second to start up the system. This will start up both the DVR3 and the xDR Press and hold for 1 second to shut down the system. This will shut both the DVR3 and the xDR down. -
Page 9: Procedures
SCC-2DR-DSP Manual Procedures Set up • When a case is used, place it on a flat surface that can support the unit. Select a working area which is secure, stable, convenient, and suitable for use during the period of the dive. -
Page 10: Xdr - Diver Intercom
All information for the controls of this subsystem can be found in the manual: xDR – Diver Intercom Manual This manual can be found on www.Novasub.com. There you can find your product and the manuals will be on that page under the Downloads Folder: Find this manual here If your system has a DVR3 it can also be found in the “Help”... -
Page 11: Connectors
SCC-2DR-DSP Manual Connectors Below you will find all the pin diagrams that can be used. Note that not all are in this system. Power 100-240 vac Type Mating type SCC 01-10c / 11c Diver 1&2, camera,light & comms Type Souriau, UTS 712E10S... - Page 12 SCC-2DR-DSP Manual SCC-01-17 Camera & Light Type Amphenol MS3102A-20-29S Mating type MS3106A-20-29P Function Pin layout GND Light Vcc Light GND Cam Vcc Cam Video + Video - SCC-02-17a Diver 1 &2 Camera,Light & 2 wire comms Type Amphenol MS3102A-20-29S Mating type...
- Page 13 SCC-2DR-DSP Manual SCC 01-018 Mic/Headset Type Lumberg 0271-07 Mating type 0251-07 Function Pin layout 12 vdc Speaker/mic Gnd Mic + Speaker + Below jacks are parallel connected to 0271-07 multipin connector Type Jack 3,5 mm Mating type Jack 3,5 mm...
- Page 14 SCC-2DR-DSP Manual Speaker output Ext. Speaker, amplified Type Banana screw socket Mating type Banana plug Function Pin layout Speaker + Speaker - SCC 01-032 SCC with external 10-36 vdc input Type Hirschmann CA3GS Mating type CA3LD Function Pin layout +VDC DP-DDG-013 Depth sensor &...
-
Page 15: Help & Support
Further details about a Warranty Statement can be found at the chapter 10 Warranty For technical support contact your local a Novasub Authorized Service Center or Seascape Subsea BV. Seascape Subsea BV is the manufacturer of all Novasub branded products. -
Page 16: Warranty
2. has been repaired using unauthorized spare parts; modified or repaired by unauthorized Service Center; 3. serial number has been removed, altered or made illegible in any way, as determined at the sole discretion of Novasub; 4. has been exposed to chemicals. Novasub does not warrant that the operation of the product will be uninterrupted or error free, or that the product will work with any hardware or software provided by a third party.
