DESCRIPTION
ITEM
A
B
C
lock washer
D
Allen Wrench
Step 1：Place the chair on a smooth flat surface.
Step 2：Attach front leg（F）to seat frame using bolt (A), washer (B), lock washer ( C ), Use allen wrench (D)
Step 3：Attach back leg（E）to seat frame using bolt (A), washer (B), lock washer ( C ), Use allen wrench (D)
ASSEMBLY INSTRUCTION
DS-2524-900-1
PARTS and Hardware
ITEM
Bolt
8
E
washer
8
F
8
G
1
DESCRIPTION
back leg
front leg
chair back with
attached seat
E
F
2
2
1
