315-D481-700
A
x1
Chair Back
x1
Chair Seat
x1
Dossier de chaise
x1
Siège de chaise
x1
Respaldo de silla
x1
Asiento de silla
E
x1
Right Arm
x1
Accoudoir droit
x1
Brazo derecho
F
x9 Allen bolt (M6 x 50mm)
x2 Allen bolt (M6 x 80mm)
x9 Vis a tete creuse hexagonale (M6 x 50mm)
x2 Vis a tete creuse hexagonale (M6 x 80mm)
x9 Perno Allen (M6 x 50mm)
x2 Perno Allen (M6 x 80mm)
J
x1 Allen Wrench
x1 Clé Hexagonale
x1 Llave Allen
Hudson Accent Chair / Fauteuil décoratifs/ Silla decorativa
B
x1
Front stretcher
x1
Barreau avant
x1
Travesaño delantero
G
x11 Spring Washer M6
x11 Rondelle à ressort M6
x11 Arandela auto-bloqueante M6
K
x2
Nut
x2
Écrou
x2
Tuercas
C
x1
Left Arm
Accoudoir gauche
x1
Brazo izquierdo
x1
H
x3 Flat Washer M6
x3 Rondelle Plate M6
x3 Arandela Plana M6
L
x8
Wooden Button
Ø14mm
x8
Botón de madera
Ø14mm
x8
Bouton en bois
Ø14mm
D
I
Advertisement
Related Manuals for Accentrics Home Hudson Accent 315-D481-700
Summary of Contents for Accentrics Home Hudson Accent 315-D481-700
- Page 1 315-D481-700 Hudson Accent Chair / Fauteuil décoratifs/ Silla decorativa Chair Back Chair Seat Front stretcher Left Arm Accoudoir gauche Dossier de chaise Siège de chaise Barreau avant Travesaño delantero Brazo izquierdo Respaldo de silla Asiento de silla Right Arm Accoudoir droit Brazo derecho x9 Allen bolt (M6 x 50mm) x2 Allen bolt (M6 x 80mm)
- Page 2 315-D481-700 Hudson Accent Chair / Fauteuil décoratifs/ Silla decorativa Important Note: Part L (Flat-bottomed Wooden Screw Cap Covers) are optional. If installed, they should be placed over exposed screw hole wells, covered with a cloth to protect chair paint/finish during installation, and gently hammered into place with a rubber mallet.
- Page 3 315-D481-700 Hudson Accent Chair / Fauteuil décoratifs/ Silla decorativa x1 R315-D481-700-BACK x1 R315-D481-700-SEAT x1 R315-D481-700-STR Chair Back Chair Seat Front stretcher Dossier de chaise Siège de chaise Barreau avant Respaldo de silla Asiento de silla Travesaño delantero x1 R315-D481-700-ARML x1 R315-D481-700-ARMR x2 R315-D481-700-NUT Right Arm Left Arm...
