SAFETYINSTRUCTIONS 安全指 引 請 務必遵 守 Disconnect power supply before maintenance. 維護保養前先斷電。 This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety.
安裝注意事 項 INSTALLATION INSTRUCTIONS WARNING 警告 The product must be grounded. Do not operate the product other than the rated voltage 必 須 接 地 。 (220 V , 50 Hz). Otherwise, it may cause 禁 止 使 用 額 定 電 壓(220 V ,50 Hz)以 electric shock when there is any trouble or electric leakage.
Page 4
安 裝 注意事項 INSTALLATION INSTRUCTIONS WARNING 警告 The product is installed so that The product must be installed by switches cannot be touched by a professionals or trained personnel person in the bath or shower. with equivalent expertise and skills 產...
安裝要求 INSTALLATION REQUIREMENTS Pleasemakesuretheproductinstalled Do not install onto slanting window. horizontallyandthedeviationangle 請勿 安 裝在傾 斜 的窗體 上 。 withintherangeasbelowfigure. 請確保 整 機水 平 安裝偏 差 角度在 下 圖所示 範圍內 。 Prevent the water condensed in the duct pipe flow back into the body.
安裝要 求 INSTALLATION REQUIREMENTS Do not cover air outlet, maybe it can cause breakdown. 請勿覆 蓋 產品出 風 口,否 則 可能 會 引起機 體 故障。 When you install plastic part, do not exert too much strength to fixing the screw (the recommended screw fixing torque is 0.78 N m), otherwise, the product would be damaged.
部 件 名 稱 和尺寸 PART NAMES AND DIMENSIONS Unit: mm 單位:mm No . Part name No . Part name 序 號 部 件名稱 序號 部件名 稱 Louver assembly Main body 機 體 面板 組 合 Cord cover Filter assembly 過...
安 裝 方法 HOW TO INSTALL Recommended main body installation method 建議 的 機體安 裝 方法 This product can be installed on a window which Unit: mm ≥290 size is shown as right figure. A window frame 單位:mm ≥238 needs to be made according to the window and main body dimensions.
Page 9
安裝方法 HOW TO INSTALL Fix the main body onto the window frame with the Installation direction supplied four 4×25 self- tapping screws. 安裝 方向 使用附件包 所提 供 的4顆 4×25的 自攻 螺 絲,將機體 固定於窗膽 。 4×25 self-tapping screws 自攻螺絲 4×25 WARNING 警...
Page 10
安裝 方 法 HOW TO INSTALL Install an all-pole switch with the contact separation not less than 3 mm and a leakage protection switch (with the leakage current lower than 30 mA)between the fixed wring and the main body of this product. 漏電保護開關(另購) 請於...
Page 11
安 裝 方法 HOW TO INSTALL Put the internal cord cover and the Screws (2 pcs) 固定 螺絲(2顆) cord cover back on, and use the screw removed in Step to fix the cord cover again. 將內接 線 蓋板及 接 線蓋 板 重新蓋 好 ,用步 驟...
Page 12
安裝方 法 HOW TO INSTALL 4.Installing louver assembly 面板組 合 安裝 At the power cord lead-out side (left or right), cut the outlet of the louver assembly by tools according to the groove shape on the back (nipper pliers) of the body assembly. (Take left outlet of power cord for example) 面...
Page 13
安裝方法 HOW TO INSTALL Fix the louver assembly onto the M4×10 main body with the supplied one machine M4×10 machine screws. screws. 使 用 附件包 所 提供的1顆M4×10的機 機械螺 絲 械 螺 絲,將 面 板組合 固 定於 機 體。 M4×10 Install the filter assembly. Filter assembly 裝...
Page 14
安裝 方 法 HOW TO INSTALL How to use the remote control 遙控器使用方法 Incorrect use of the battery may cause heating, rupture, injury or product failure. Be sure to observe the following instructions. 錯 誤 使用電 池 可能會 產 生發熱 、 破裂, 導致受 傷 或產品 故 障,請 務 必遵守 以 下事項 。 WARNING 警告...
安裝 方 法 HOW TO INSTALL Notice 提示事項 1.lf you will not use the remote control for a period of time, take out the batteries. 長 期 不使用 時,請 取 出電池 。 2.Do not replace the batteries when the remote control body is wet. 更換電...
遙控 器 功 能 FUNCTION OF REMOTE CONTROL STANDBY button HEAT button 待機按鈕 取暖按鈕 Heating function In the standby status, 取暖功能 this product still requires power consumption. If VENT button the product will not be 換氣按鈕 in use for a long time, Air change function the all-pole power 換氣功能...
定 時 功能的使用方 法 HOW TO USE TIMER FUNCTION For running time adjusted 調整運轉時間時使用 During running, you can press the button to change the running time. Each time you press the button, the time will change once. 運轉 中 可通 過 調...
風 向 功 能 的使用方法 HOW TO USE AIR DIRECTION FUNCTION For air direction adjusted 調整風向時使用 During running, you can press the button to adjust the air direction. 運 轉 中可通 過 按 鈕, 調 整風向 。 The initial air direction setting of HEAT, DRY HOT and DRY COOL is AUTO mode.
取 暖功能的使 用 方 法 HOW TO USE HEATING FUNCTION Used when you feel cold in a bath 在浴室中感到冷時使用 Before taking a bath, start the heating function to warm the bathroom beforehand. 在 沐浴前 開取暖 功 能,可 提 前把浴 室 加溫。 Press the button to start the heating mode at the HI mode.
換 氣 功 能 的 使用方法 HOW TO USE VENTILATION FUNCTION Used to ventilate the bathroom 浴室換氣時使用 Press the button to start the ventilation mode at the HI mode. It will switch to the LO. mode if you press this button again. 按...
Page 21
Weak acidity (with weak acidity features close to that of hair and skin). 弱酸 性(具有與髮質和 皮 膚接 近 的弱酸 性 特性)。 ® ® Note: nanoe and the nanoe mark are trademarks of Panasonic Corporation. ® ® 注 :nanoe 和nanoe 標 記 為松下 電 器產業 株 式會社 商 標。...
HOW TO USE DRY HOT/COOL FUNCTION 熱/涼 乾燥功 能的 使 用方 法 Used when you need to dry the bathroom or clothes 乾燥浴室或乾衣物時使用 Press the button to start the DRY HOT or DRY COOL mode. 按 或 按 鈕,熱 乾燥或 涼 乾燥模 式 開始運 轉 。 During running, you can press to change the set time.
Page 23
HOW TO USE DRY HOT/COOL FUNCTION 熱/涼 乾燥功 能的 使 用方 法 To use the drying function to dry clothes, you are suggested to install the product as shown below: 使 用 乾燥功 能進行 衣 物烘乾 時 ,建議 按 照下圖 進 行安裝: Unit:mm 單位:mm To make the effect of drying...
Page 24
HOW TO USE DRY HOT/COOL FUNCTION 熱/涼 乾燥功 能的 使 用方 法 Notice 提示事項 When you dry clothes, make sure that the air blows to the clothes. 乾 衣時,請 確 保風能 夠 吹到衣 物 。 Condensation may happen as this is natural phenomenon due to specific weather and bathroom condition.
使用 及 維 護 注 意事項 USE AND MAINTENANCE INSTRUCTIONS WARNING 警告 Do not put the battery in reach To avoid low-temperature scalding, of children and infants. do not directly below the same part of the body with hot wind for a long 禁...
Page 27
使 用 及 維 護注意事項 USE AND MAINTENANCE INSTRUCTIONS WARNING 警告 If the product will not be in use Please observe the following for a long time, please use the with using the batteries. “all-pole power switch”to 電 池 的 使 用 請 遵 守 以 下 內 容 。 disconnect the power supply.
使用及維 護 注 意 事 項 USE AND MAINTENANCE INSTRUCTIONS 2.The applicable ambient temperature of this product is in the range of -10 °C 40 °C, using it out of this range may cause a fault. 本產品 適 用環 境 溫度-10 °C 40 °C,否 則 可能會 引 起故障 。 3.
維 護 方 法 HOW TO MAINTENANCE Remove the filter assembly from the slant upward side of louver assembly. 將過 濾 網組合 從 面板組 合 的斜上 方 取出。 Use a vacuum cleaner to remove dust and dirt from the filter. 用...
Page 32
本產 品機 體 及遙 控器 通過防 濺水試驗, 符合IPX4要求。 Insulation class E E級絕緣 The above specification may be changed without further notice. 上述 參數 如 有變 動, 恕不另 行通知。 Web Site: http://www.panasonic.com Issue date 發行: 10/2021 Panasonic Corporation 2021 P1021-023BWN2420 H...
