- Page 1 REPAIR PARTS MANUAL MODEL NO. A20K46YT/93603900 (96046000300) Lawn Tractor 423812 Rev. 3 12.02.08 BAD Printed in U.S.A.
-
Page 2: Table Of Contents
The model number for your tractor can be found on the fender under the seat. When ordering parts, always give the following information: • Product - “Tractor” • MODEL NUMBER - “A20K46YT/93603900 (96046000300)” • Part Number • Part Description TABLE OF CONTENTS SCHEMATIC ........................ -
Page 3: Schematic
TRACTOR - MODEL NO. A20K46YT/93603900 (96046000300), PRODUCT NO. 960 46 00-03 SCHEMATIC SCH10 BATTERY SOLENOID STARTER FUSE AMMETER BLACK (OPTIONAL) WHITE WHITE ATTACHMENT CLUTCH (CLUTCH OFF) BLACK CLUTCH/BRAKE GRAY (PEDAL UP) REVERSE SWITCH BLACK (NOT IN REVERSE) BLACK BLACK BLACK... -
Page 4: Electrical
TRACTOR - MODEL NO. A20K46YT/93603900 (96046000300), PRODUCT NO. 960 46 00-03 ELECTRICAL T03S With 12V Outlet Option With Service Minder Option... - Page 5 TRACTOR - MODEL NO. A20K46YT/93603900 (96046000300), PRODUCT NO. 960 46 00-03 ELECTRICAL PART DESCRIPTION 163465 Battery 74760412 Bolt Hex Head 1/4-20 x 3/4 186491 Box Battery 176138 Switch Interlock Push-In 183759 Harness Socket Light w/4152J 4152J Bulb Light 400253 Cable Battery 8"...
-
Page 6: Chassis
TRACTOR - MODEL NO. A20K46YT/93603900 (96046000300), PRODUCT NO. 960 46 00-03 CHASSIS chassis-tex_elite-husq_1_r1... - Page 7 TRACTOR - MODEL NO. A20K46YT/93603900 (96046000300), PRODUCT NO. 960 46 00-03 CHASSIS PART DESCRIPTION 401715X428 Dash 425404X422 Hood 188264X599 Lens Grille LH 423180 Grille 188263X599 Lens Grille RH 196125 Plate Engine 17060512 Screw 5/16-18 x 3/4 414878X422 Fender 73680500 Nut Crown Lock 5/16-18...
-
Page 8: Drive
TRACTOR - MODEL NO. A20K46YT/93603900 (96046000300), PRODUCT NO. 960 46 00-03 DRIVE drive-tex_T2_pedal_14... - Page 9 TRACTOR - MODEL NO. A20K46YT/93603900 (96046000300), PRODUCT NO. 960 46 00-03 DRIVE PART PART DESCRIPTION DESCRIPTION - - - - - - Transaxle, Hydro T2-AABC-1X2B- 105709 Spring, Return, Clutch 1GX1(Order Parts from Transaxle 408784 Adapter Transaxle Manufacturer) 413322 Rod Pedal Control...
-
Page 10: Engine
TRACTOR - MODEL NO. A20K46YT/93603900 (96046000300), PRODUCT NO. 960 46 00-03 ENGINE 21 20 SPARK ARRESTER KIT engine-tex_Kohl_11... - Page 11 TRACTOR - MODEL NO. A20K46YT/93603900 (96046000300), PRODUCT NO. 960 46 00-03 ENGINE PART DESCRIPTION - - - - - - Engine Kohl Model No. SV600 188655 Muffler 194319 Keeper Belt Engine 405140 Pulley Engine 400021 Tank Fuel 195951 Cap Asm...
- Page 12 TRACTOR - MODEL NO. A20K46YT/93603900 (96046000300), PRODUCT NO. 960 46 00-03 STEERING ASSEMBLY...
-
Page 13: Steering
TRACTOR - MODEL NO. A20K46YT/93603900 (96046000300), PRODUCT NO. 960 46 00-03 STEERING ASSEMBLY PART DESCRIPTION 414803X428 Wheel, Steering 418168 Axle Asm., Front 403087 Spindle Asm., LH 403088 Spindle Asm., RH 6266H Bearing, Race Thrust Harden 121748X Washer 25/32 x 1-5/8 x 16 Ga. -
Page 14: Mower Deck
TRACTOR - MODEL NO. A20K46YT/93603900 (96046000300), PRODUCT NO. 960 46 00-03 MOWER DECK... - Page 15 TRACTOR - MODEL NO. A20K46YT/93603900 (96046000300), PRODUCT NO. 960 46 00-03 MOWER DECK PART PART DESCRIPTION DESCRIPTION 405049X422 Mower Housing 199478 Arm Brake Mower 405506 Cover Mandrel LH 405139 Linkage Brake 405507 Cover Mandrel RH 198398X428 Handle, Clutch Cable 195186...
-
Page 16: Mower Lift
TRACTOR - MODEL NO. A20K46YT/93603900 (96046000300), PRODUCT NO. 960 46 00-03 MOWER LIFT PART PART DESCRIPTION DESCRIPTION 195223 Shaft Asm., Lift 194208 Pin Cotter 5/16 Bow Tie Lock 195231 Lever Asm., Lift RH 195181 Link Asm. Lift Rear 196492X421 Grip, Lever 17000612 Screw 3/8-16 x .75 Smgml Tap/R.Z... -
Page 17: Seat
TRACTOR - MODEL NO. A20K46YT/93603900 (96046000300), PRODUCT NO. 960 46 00-03 SEAT ASSEMBLY seat-tex_6.5SL_2 PART PART DESCRIPTION DESCRIPTION 423010 Seat 73800500 Nut, Lock 5/16-18 unc 180166 Bracket Pivot Fender 197661 Handle Slide Seat 198200 Spring Latch Seat 140675 Strap, Asm Fender... -
Page 18: Decals
TRACTOR - MODEL NO. A20K46YT/93603900 (96046000300), PRODUCT NO. 960 46 00-03 DECALS PART PART DESCRIPTION DESCRIPTION 424088 Decal, Replacement 422808 Decal, Hood RH 422809 Decal, Hood LH 423830 Decal, Hood E85 Warning 422810 Decal, Steering Wheel 422812 Decal, Side Panel... - Page 19 SERVICE NOTES...
-
Page 20: Warranty
LIMITED WARRANTY The Manufacturer warrants to the original consumer purchaser that this product as manufactured is free from defects in materi- als and work man ship. For a period of two (2) years from date of purchase by the original consumer purchaser, we will repair or replace, at our option, without charge for parts or labor incurred in replacing parts, any part which we find to be defective due to materials or workmanship.
