Simmons CHARLESTON Assembly Instructions

Convertible sofa

Operate your convertible sofa by pushing the backrest forward, this will

release the sofa to the bed position. Lift the backrest up to transition from

bed position to either lounge or sofa position. This sofa has a split back

which will allow you to operate either the left or right side independently.

FINGER GUARD

• U.S. Patent No. 8,875,321

• Provides Users a Permanent Safety Solution

• Eliminates the Risk & Liability of an Accident

• Heavy Duty, Fully Welded, Protective Metal Plate

8-8

ADULT ASSEMBLY REQUIRED

If you are missing any parts or have any questions regarding assembly,

do not return this item to the retailers store. Please call our toll-free, customer

service number and have this assembly manual open to the parts list ready to

provide the model name, number and part name or number.

Customer Service

1-877-864-5752

8:30 AM PST - 4:00 PM PST (Monday-Friday)

Website: www.simmonsconvertibles.com

Missing Parts: parts@dwellhom.com

Warranty Information: www.simmonsconvertibles.com/warranty

WARNING: This product may contain small components,

please ensure they are kept away from small children.

C O N V E R T I B L E S O F A

2018/06

CHARLESTON

Table of Contents

Need help?

Do you have a question about the CHARLESTON and is the answer not in the manual?

Page 1 • Eliminates the Risk & Liability of an Accident • Heavy Duty, Fully Welded, Protective Metal Plate CHARLESTON C O N V E R T I B L E S O F A 2018/06...
Page 2 PARTS Attach Front Legs (D) and Back Legs (E) to Sofa Body (A) using Plastic Disk (G) and hand turning until tight. A. SOFA BODY B. LEFT ARM C. RIGHT ARM D. FRONT LEGS E. BACK LEGS F. CENTER SUPPORT LEGS G.
Page 3 HARDWARE Please do not completely tighten any screws until the entire assembly is complete. Insert Stud (1) into Left Arm (B) and Right Arm (C). Once assembly is complete, please be sure to tighten all hardware. Then, attach Left Arm (B) and Right Arm (C) to Sofa Body (A) using Stud (1), Large Washer (4), Lock Washer (6) and Nut (2).
Page 4 ASSEMBLY INSTRUCTIONS Flip Sofa Body (A) over. Attach Center Support Leg (F) to Sofa Body (A) using Bolt (3), Pull out Hardware and Parts from the zippered compartment. Lock Washer (6) and Small Washer (5). Tighten using provided Allen Key (7).
