VTech CM18445 Quick Start Manual

Cordless accessories for CM18445/CM18245/
CM18045/AM18447/AM18247/AM18047
Cordless headset (VTech IS6100)
You can add DECT 6.0 cordless headsets (purchased separately)
to the console. The cordless headsets are assigned with available
extension numbers starting from 9 in descending order (9 to 1),
subject to the limitation of a total of nine cordless devices.
After registration, you have an option to link the headset with the
console, deskset or cordless handset. Linking the cordless headset
with an extension device allows you to make a call handsfree.
Besides, information about which line the cordless headset is
operating will display on the screen of the linked extension.
Place the headset in the headset charger and note the color of the
If the button flashes in red and blue alternately, the headset is unregistered.
If the button shows a constant red light (charging) or blue light (fully charged),
the headset is registered to another device. Deregister the headset before you
can register it to the console. See the deregistration instructions in the user's
manual of the telephone to which it is currently registered.
Cordless speakerphone (AT&T TL80133)
You can add DECT 6.0 cordless speakerphones (purchased
separately) to the console. The cordless speakerphones are
assigned with available extension numbers starting from 9
in descending order (9 to 1), subject to the limitation of a
total of nine cordless devices.
After registration, you have an option to link the speakerphone
with the console, deskset or cordless handset. Linking the
cordless speakerphone with an extension device allows you to make a call
handsfree. Besides, information about which line the cordless speakerphone is
operating will display on the screen of the linked extension.
Place the speakerphone in the speakerphone charger and note the color of
the CHARGE indicator. If the indicator flashes in red and green alternately,
the speakerphone is unregistered. If the indicator shows a constant red light
(charging) or green light (fully charged), the speakerphone is registered to
another device. Deregister the speakerphone before you can register it to
the console. See the deregistration instructions in the user's manual of the
telephone to which it is currently registered.
Register a cordless headset or speakerphone to your system
1. Place the headset or speakerphone in the charger
and allow it to charge for at least five minutes before
beginning registration. Make sure the headset or
speakerphone is out of the charger before you begin
registration.
On the console, press MENU
2.
3. Scroll to Registration, then press
4. Press
MENU/
5. Place the headset or speakerphone in the charger.
It may take up to 60 seconds to complete the
registration. The console shows HDST/SPK X
registered. (X represents the extension number 9 to
1) and beeps when the registration is successful.
button.
The console shows Link HDST/SPK X to extension?.
6.
If you want to link the headset or speakerphone with
an extension, scroll to Yes. Otherwise, choose
then skip to Step 8. Press
7. Scroll to select a desired extension to be linked with
the headset or speakerphone. Press
confirm.
8. Lift the headset, then press
PHONE on the speakerphone. If you hear a dial tone,
the registration was successful.
If you linked the headset or speakerphone with an
extension, the extension screen displays the extension
number along with the line number it is using.
For VTech IS6100, if there is no dial tone, or the
headset flashes in red and blue alternately, the registration was
not successful. Remove the headset from the headset charger.
Wait for about two minutes, then repeat the registration process
again, starting with step 2.
For AT&T TL80133, if there is no dial tone, or the voice prompt
"Not registered" plays once upon every key press, the registration was not
successful. Remove the speakerphone from the charger. Wait for about two
minutes, then repeat the registration process again, starting with step 2.
After registration, you can stick an extension
number label that comes with the package to
the cordless headset or speakerphone for easy
recognition.
.
/SELECT
SELECT.
MENU/
SELECT again to select Register Ext.
choose No and
SELECT to confirm.
Press
MENU/
SELECT to
MENU/
on the headset; or press
Registration:
>Register Ext
Deregistration
Link HDST/SPK X
to extension?
>Yes
No
Link HDST/SPK X:
>Console 0
Deskset 1
Handset 2
light on the
IS6100 TL80133
