- Page 1 INTERSEPTOR PRO INTERSEPTOR PRO INTERSEPTOR PRO Quick Installation Guide Quick Installation Guide Quick Installation Guide www.jacarta.com support@jacarta.com +44 (0) 1672 511125 QIG Version: v1.10 ___________________________________________________________...
- Page 2 Thank you for purchasing the Jacarta interSeptor Pro-XP Environmental Monitoring System and sensors. This installation guide provides instructions for installing the interSeptor Pro-XP on your network. For all other aspects of product use, please see the full User Manual that can be downloaded from: www.jacarta.com/support/resources...
- Page 3 Before shipment, the unit must be completely switched off and unplugged and all connections must be removed. • Before connecting the interSeptor Pro-XP to the power supply, ensure that the rating of the power source is consistent with the rating of the power adapter of the interSeptor Pro-XP.
- Page 4 Password: admin 5. Select the General Settings menu option and then select Network Settings. From here, you can change and save the IP address of the interSeptor Pro-XP as required for your network. Remove the cross-over cable and connect the interSeptor Pro-XP to your network switch/router.
- Page 5 On the Web UI, Port 1= EMD 1, and so on. 9. An optional Jacarta Alarm Siren/Beacon can be connected to the ports on the interSeptor Pro-XP that are marked DO using the terminal block that is attached to the end of the Alarm Beacon cable.
- Page 6 RJ45 sockets on the sensor and the other end into one of the 4 “EMD” ports on the rear panel of the interSeptor Pro-XP. The first dip switch of a Temperature/Humidity sensor connected directly to any of the 4 EMD ports on the Pro-XP should be in the ‘On’...
- Page 7 The relevant Alarm (1 or 2) should be configured as ‘Normal Open’ in the browser via the EMD set-up screens [Device Management/Device Configuration]. When smoke is detected, an audible alarm will sound and the interSeptor Pro-XP will be activated and the sensor’s alarm state will change from ‘Normal’ to ‘Alarm’.
- Page 8 Appendix I Dip Switch Settings for Daisy-Chaining interSeptor Pro-XP Temperature/Humidity Sensors Should you wish to daisy-chain/cascade your Temperature/Humidity Sensors (up to a maximum of 8 sensors per chain), please refer to the following table for the appropriate dip switch settings.
