    Back Page FORWARD This manual provides the user with basic details for the installation and operation of the Oceanaire OWC2412QC spot cooler. It is recommended to read and fully understand the instructions outlined within this manual, before operating the OWC2412QC unit.
  • Page 3: General Information

    GENERAL INFORMATION The OceanAire OWC2412QC is a portable water-cooled air conditioner designed for permanent or temporary spot cooling applications. The entire air conditioning unit has been built in an attractive sheet metal cabinet, equipped with heavy-duty casters for mobility. All OWC2412QC models come with a 10-foot power cord for electrical connection and added mobility in service.
  • Page 4: Product Data And Specifications

    SPECIFICATIONS OWC2412QC COOLING CAPACITY 24,000 btu/hr VOLTAGE 208-230 V, 60Hz, 1PH AMPS WATTS 2100 IN RUSH AMPS PLUG TYPE 6-20P, LCDI 11.4 COMPRESSOR ROTARY COMPRESSOR HP COMPRESSOR LRA EVAP CFM EVAP MOTOR HP 1/83 COND GPM at EWT, 60⁰F COND GPM at EWT, 85⁰F QUIC CONNECT WATER LINE CONNECTIONS WATER IN 3/8”...
  • Page 5: Standard Features

    STANDARD FEATURES CABINET The OWC2412QC cabinet is constructed of 18 gauge steel with a gray and blue polyester powder coated finish that will compliment any decor. The entire cabinet is insulated with sound-absorbing insulation for cool, quiet comfort. All units come equipped with swivel casters for portability and convenient set-up.
  • Page 6: Applications, Electrical Configuration

    APPLICATIONS SPOT COOLER The OWC2412QC can be used in an open environment to cool specific objects or "spots". Spot Cooling is a convenient and economical way to provide air conditioning where cooling the entire space is not viable. Cool air is discharged from the units grille and is directed where it is needed.
  • Page 7: Unit Interior

    OWC2412QC INTERIOR Motor Thermostat Blower Wheel Evaporator Coil Compressor High Pressure Switch Reset Button Condensate Pump Water Water Drai Electrical Cord Strain-Relief Condensate Pump Cubby for the Hose Kit Access Door...
  • Page 8: Installation Instructions

    BEFORE INSTALLING Check the unit for any damage. All Oceanaire products are thoroughly inspected at the factory and carefully packaged. If any damage is evident, contact Oceanaire IMMEDIATELY.
  • Page 9 OWC2412QC ACCESSORIES DISCHARGE AIR NOZZLE KIT ASSEMBLY An optional discharge nozzle kit is used to direct the conditioned air to a specific target area. By concentrating the airflow, the nozzles increase the air velocity towards production lines to cool personnel and/or equipment.
  • Page 10 OWC2412QC ACCESSORIES DISCHARGE DUCT ADAPTER A discharge duct adapter is available for applications where ducting the cool air is required. The adapter can be easily in- stalled on the unit without fasteners, and be installed for either vertical or horizontal ducting. The standard discharge grille is removed and the DDA is placed in the grille opening.
  • Page 11: Hose Kits

    HK-QC SERIES HOSE KIT All Oceanaire hose kits are designed for use with Oceanaire Portable Water-cooled Air conditioners, to accommodate almost any installation requirement. The hose kit allows for the unit to be connected to a water source while providing a certain level of portability and ease of installation.
  • Page 12: Hose Kit Installation Instructions

    HK-QC INSTALLATION INSTRUCTIONS Connect Hose Kit to unit by aligning the QC Coupling with the QC Fitting on the unit. Connect the hose kit according to hose and unit labels: BLACK to WATER IN, RED to WATER OUT and YELLOW to DRAIN. HOLD the coupling behind the sleeve allowing the sleeve to move freely and PRESS firmly, until the sleeve retracts and clicks.
  • Page 13: Optional Hose Adapter Kit

    HA-SMQC HOSE ADAPTER KIT The HA-SMQC Hose Adapter Kit allows for the installation of a QC water cooled unit where the Standard QC Hose Kit cannot accommodate the installation. The kit provides a means of connecting hoses to a QC-Model unit when the water source and drain are located in separate areas, or where longer hose runs are desired.
  • Page 14: Thermostat/Controller Operation

    Doing that, you over- POWER BUTTON OCEANAIRE DELUXE ELECTRONIC CONTROLLER When power is connected, the controller will display “888” momentarily, and then disappear. Press the POWER button, then scroll drown to the TEMP SELECT button until the SET POINT is displayed.
  • Page 15 CONTROLLER PROGRAMMING MENU 1) Make sure the unit has power . 2) Press the power button “OFF”. “S-U-D-S” 3) Press the following buttons in sequence elect— p arrow — own arrow — elect) 4) The display will begin flashing P1 and a number. If there is no display, repeat the sequence, making sure the unit has power, but is turned OFF.
  • Page 16 CODE SETTINGS OWC2412QC P1 = 70, P2 = 50 NOTICE Program Parameters are NOT controller default values. They are Oceanaire Factory Settings DISPLAY FAULTS LAC……………………. Low AC line power AAA or - - - ……… Failed Air Sensor (unit will not run) CON…………………….
  • Page 17: Water Valve Adjustment

    WATER VALVE ADJUSTMENT Each OCEANAIRE WATER-COOLED unit is equipped with an automatic water regulating valve to control the condenser water flow rate. The water valve will open when the unit is in the cooling mode and adjust the gallon per minute flow rate based on the entering water temperature (EWT).
  • Page 18: Replacement Parts Procedure

    OWC2412QC REPLACEMENT PARTS PROCEDURE IT IS RECOMMENDED THAT ALL OCEANAIRE UNITS BE SERVICED BY A LICENSED TECHNICIAN WARNING —TO AVOID INJURY, DISCONNECT UNIT POWER PRIOR TO SERVICING A. FAN MOTOR 1. Remove rear panel and cabinet left-side panel (when looking at the front of the unit).
  • Page 19: Troubleshooting Guide

    TROUBLESHOOTING GUIDE The following steps and procedures are recommended for correcting the problems indicated. In the event that the problem can not be corrected, service may be required. SERVICE SHOULD BE PERFORMED BY A QUALIFIED AIR CONDITIONING SERVICE TECHNICIAN PROBLEM: UNIT DOES NOT POWER UP CAUSE: Power interruption REMEDY: Check LCDI and reset.
  • Page 20: Preventive Maintenance

    GENERAL Oceanaire products are NOT approved for outdoor use. Therefore, off-season storage should be indoor, protected from weather conditions. When necessary maintenance steps outlined above are followed, the air conditioner will provide long and reliable service.
  • Page 21: Piping Schematic

    PIPING SCHEMATIC...
  • Page 22: Wiring Diagram

    WIRING SCHEMATIC FOR OWC2412QC...
  • Page 23: Warranty

    LIMITED WARRANTY The Manufacturer (Oceanaire, Inc.) warrants to the original owner that the Product will be free from defects in material or workmanship for a period not to exceed one (1) year from date of installation. If upon examination by the Manufacturer, the Product is...
  • Page 24 SERIAL NUMBER: _____________________________ Date Purchased: ______________________________ Purchased from: _______________________________ Date Installed: _________________________________ For Technical Support or service parts, Keep Cool Team contact our at 847-583-0311 In order to receive the benefits of our warranty, please register on-line at www.oceanaire-inc.com EISM-OWC2412QC 01012022...
