- Page 1 INSTALLATION MANUAL HT20470 Processor Unit kongsberg.com/simrad...
- Page 3 Additional end-user documents related to the sonar system can be found on our website. This includes publications that are translated to other languages. Selected publications are also provided on IETM (Interactive Electronic Technical Manual) formats. • https://www.kongsberg.com/fisherysonar 492671/C March 2022 © Kongsberg Maritime AS...
- Page 4 Kongsberg Maritime disclaims any responsibility for damage or injury caused by improper installation, use or maintenance of the equipment. Disclaimer Kongsberg Maritime AS endeavours to ensure that all information in this document is correct and fairly stated, but does not accept liability for any errors or omissions. Support information If you require maintenance or repair, contact your local dealer.
-
Page 5: Table Of Contents
Installation Manual Table of contents ABOUT THIS MANUAL ..............5 INTRODUCTION................7 Processor Unit......................... 7 Order information ........................8 Support information ........................ 8 INSTALLATION ................11 Installing the HT20470 Processor Unit..................11 Installing the power supply....................14 CABLE LAYOUT AND INTERCONNECTIONS......... 16 Read this first ........................ - Page 6 Simrad HT20470 492671/C...
-
Page 7: About This Manual
The shipowner and shipyard doing the installation are responsible for obtaining and paying for such approval. Kongsberg Maritime AS will accept no responsibility for any damage or injury to the product, vessel or personnel caused by equipment that has been incorrectly installed or maintained, or by drawings, instructions or procedures that have not been prepared by us. - Page 8 Microsoft Corporation in the United States and other countries. ® ® ® Simrad , SIMRAD and the Simrad logo are either registered trademarks, or trademarks of Kongsberg Maritime AS in Norway and other countries. 492671/C...
-
Page 9: Introduction
The HT20470 Processor Unit is available in two versions. The DC version operates on +24 VDC while the AC version operates on 100 to 240 VAC. Power supply: • : Mean Well Manufacturer • https://www.meanwell.com Manufacturer’s website: • : SDR-240-24 Type designation • : 488156 Kongsberg Maritime part number 492671/C... -
Page 10: Order Information
A list of all our offices and dealers is available on our website. You can also contact our main support office in Norway. Norway (main office) • : Kongsberg Maritime AS / Simrad Company name • : Strandpromenaden 50, N3190 Horten, Norway Address •... - Page 11 Telefax • www.kongsberg.com/simrad Website • simrad.france@simrad.com Email address • : Kongsberg Underwater Technology LLC (KUTL) / Simrad Fisheries Company name • : 19210 33rd Ave W, Suite A, Lynnwood, WA 98036, USA Address • : +1 425 712 1136 Telephone •...
- Page 12 Simrad HT20470 Installation Manual • www.kongsberg.com/simrad Website • simrad.asia@simrad.com Email address Korea • : Kongsberg Maritime Korea Ltd Company name • : #1101 Harbor Tower, 113-1, Nampodong 6-Ga, Jung-Gu, Busan 600-046, Korea Address • : +82 51 242 9933 Telephone •...
-
Page 13: Installation
If you need to install the unit in a 19" rack you must purchase and use the dedicated mounting kit. • Kongsberg Maritime part number: 473676 Mounting brackets for desktop installation are included with the delivery. Relevant mounting hardware (bolts, nuts and washers) are included. - Page 14 Simrad HT20470 Installation Manual Photo: Remove the two plastic blocks located behind each side of the front panel. Fasten the two mounting brackets to the space made available. Note The Processor Unit does not contain any fans. It will be very warm, even during normal operation. This is by design.
- Page 15 Installation Make sure that the space allows you to open the computer for unobstructed access to its internal parts. Note Make sure that you can access both the rear and front side of the computer after it has been installed. Install the Processor Unit.
-
Page 16: Installing The Power Supply
These are commercial items that can be purchased locally. Power supply: • : Mean Well Manufacturer • https://www.meanwell.com Manufacturer’s website: • Type designation: SDR-240-24 • Kongsberg Maritime part number: 488156 Procedure Find a suitable location for the power supply. 492671/C... - Page 17 Installation Prepare the location and the necessary tools. Observe the installation requirements. Make sure that enough space is made available for maintenance purposes. Make sure that the installation method allows for the physical vibration, movements and forces normally experienced on a vessel. Make sure that the chosen location meets the installation requirements.
-
Page 18: Cable Layout And Interconnections
Power supply connectors, page 27 Read this first Detailed information about cable specifications, termination and connectors is provided. Unless otherwise specified, all cables are supplied by Kongsberg Maritime as a part of the delivery. Detailed information about relevant cable specifications, termination and connectors is provided. - Page 19 Only skilled and authorized personnel can install the sonar cables. Kongsberg Maritime accepts no responsibility for damage to the system, or reduced operational performance, when this is caused by improper wiring. Before you install or maintain the system cables, make sure that the AC mains circuit breaker for the system is disconnected.
-
Page 20: Topside Cable Plan
Simrad HT20470 Installation Manual Topside cable plan The topside/bridge cables include those used to connect the Processor Unit and the display to each other, as well as cables for AC mains power and external devices. The connection between the Processor Unit and the operating panel is also shown. -
Page 21: List Of Topside Cables
Cable layout and interconnections List of topside cables Each topside cable used by the sonar system is listed. Cable Type From Minimum requirements / Comments AC Power cable Uninterruptible Vessel AC power 2 x 1.5 mm + 1.5 mm Ground power supply (UPS) AC Power cable... -
Page 22: Comments
Simrad HT20470 Installation Manual Comments Some of the cables used by the sonar system require additional explanations and recommendations. Cable numbers Cable numbers that are not used are spares for optional equipment and/or future expansions. Project cables The sonar system is often a part of a project delivery. For such deliveries, specific project cable drawings are established to show all the main cables, and how the various products are connected. - Page 23 Cable layout and interconnections C9 Video cable This is a commercial cable. The display cable is often physically attached to the display, and terminated in the “computer end” with a male connector. If the cable is not attached, it is normally provided with the display. Keep the display cable as short as possible.
-
Page 24: Processor Unit Rear Panel Description: Ht20470 (Dc Version)
Simrad HT20470 Installation Manual Processor Unit rear panel description: HT20470 (DC Version) The rear panel of the Processor Unit holds the power socket and multiple interface ports. Ground Graphics adapter (Mini DisplayPorts) Graphics adapter (Not used) Serial ports (COM1-4) Ethernet connector (LAN2) - Page 25 Cable layout and interconnections LAN4 Transceiver Use this socket for Ethernet communication with the relevant sonar system unit in the sonar room. It is very important that a high-quality Ethernet cable is used. You must use CAT-5E STP (Shielded Twisted Pair) quality or better. Using cables with lower bandwidth capacity will reduce performance.
-
Page 26: Powered Audio Output
Simrad HT20470 Installation Manual Powered audio output The Processor Unit offers a powered audio output. One or two loudspeakers can be connected to the output. The output is rated to 2 W for each channel. You need a 9-pin male D-Subminiature connector. This is a commercial item that can be purchased locally. -
Page 27: Moxa Cp114El-I Serial Line Adapter
Cable layout and interconnections Moxa CP114EL-I Serial line adapter The Processor Unit is equipped with a Moxa CP114EL-I serial adapter board. The serial adapter offers four serial ports. The serial lines are provided as a large D-Subminiature connector on the rear side of the computer. The Moxa CP114EL-I serial adapter supports RS-232, RS-422 and RS-485 (both 2 and 4-wire). - Page 28 Simrad HT20470 Installation Manual specifications for the actual "shunt capacitance". A common figure is 47.5 pF/m, which gives a maximum cable length of about 50 meters. Even though a standard exist for RS-232 pin configuration, certain manufacturer may still choose their own connector pins for the various signals used. In order to make the RS-232 connection to your peripheral device work properly, you must always consult the relevant instructions provided by the device manufacturer.
-
Page 29: Power Supply Connectors
The power supply offers a 24 VDC output. Connections are made using two terminal boards. • : Mean Well Manufacturer • https://www.meanwell.com Manufacturer’s website: • Type designation: SDR-240-24 • Kongsberg Maritime part number: 488156 Connections TB1 Input (88-264 VAC) TB2 Output (DC voltage) Voltage Voltage Ground Relay contacts... -
Page 30: Setting To Work
Simrad HT20470 Installation Manual Setting to work Topics Visual inspection of the Processor Unit, page 29 Installing the operating software, page 30 Obtaining and installing a software license for additional functionality, page 32 Setting up the sonar system, page 33... -
Page 31: Visual Inspection Of The Processor Unit
Setting to work Visual inspection of the Processor Unit A visual inspection of the Processor Unit is required to verify that the unit has not been physically damaged during the installation. Prerequisites The sonar system hardware units are installed as specified in this manual. The sonar system is turned off. -
Page 32: Installing The Operating Software
Simrad HT20470 Installation Manual Use a standard multimeter to check that the resistance between the unit and the ship's ground is approximately 0 (zero) Ω. Make sure that cable installation has been completed. Make sure that all cables leading to and from the unit have been properly mounted and secured. - Page 33 Setting to work ® Neither tools nor instruments are required. This procedure is made for the Microsoft Windows ® 10 operating system. It is assumed that you are familiar with this operating system. Note The software release note may contain additional details related to the software installation. Procedure On the personal computer: Download the new software version.
-
Page 34: Obtaining And Installing A Software License For Additional Functionality
Simrad HT20470 Installation Manual Obtaining and installing a software license for additional functionality The sonar system does not need any software licenses to operate. However, specific software license codes "unlocks" additional functionality. Context The software license is a 32 character hexadecimal string based on the hardware identifier ). -
Page 35: Setting Up The Sonar System
Setting to work Once the software license string(s) have been returned to you (most likely by e-mail), you can install the licenses into the software. Open the page. Software License Select , and type the license string into the dialog box. Type License String If you do not have a computer keyboard connected to your sonar system, select the button to open an on-screen keyboard. -
Page 36: Technical Specifications
HT20470 Processor Unit. They also provide information related to power requirements, physical properties and environmental conditions. Note At Kongsberg Maritime, we are continuously working to improve the quality and performance of our products. The technical specifications may be changed without prior notice. -
Page 37: Ht20470 Processor Unit Weight And Outline Dimensions
VDC while the AC version operates on 100 to 240 VAC. A power supply is required if a DC powered unit needs to work from an AC supply. The technical specifications are those valid for the computer that is provided by Kongsberg Maritime as a part of the sonar system. For additional details, refer to the technical specifications provided by the manufacturer. -
Page 38: Ht20470 Processor Unit Environmental Requirements
: The manufacturer has not provided this information. Ingress protection (IP) code The technical specifications are those valid for the computer that is provided by Kongsberg Maritime as a part of the sonar system. For additional details, refer to the technical specifications provided by the manufacturer. - Page 39 Technical specifications The technical specifications are those valid for the computer that is provided by Kongsberg Maritime as a part of the sonar system. For additional details, refer to the technical specifications provided by the manufacturer. Note This information was copied from the manufacturer’s documentation. To ensure that your information is correct, always consult the manufacturer’s own documents.
-
Page 40: Drawing File
Simrad HT20470 Installation Manual Drawing file Topics About the drawings in the drawing file, page 39 494024 Processor Unit outline dimensions (HT20470/DC), page 40 494025 Processor Unit outline dimensions (HT20470/AC), page 43 Power supply dimensions, page 46 492671/C... -
Page 41: About The Drawings In The Drawing File
The original installation drawings are available in PDF and/or AutoCad's DWG format. The original drawing can be downloaded from our website. • https://www.kongsberg.com/fisherysonar Some drawings and documents are not available from our website. These can be downloaded from the Simrad Dealer Club. -
Page 42: 494024 Processor Unit Outline Dimensions (Ht20470/Dc)
Simrad HT20470 Installation Manual 494024 Processor Unit outline dimensions (HT20470/DC) Download the source drawing from our website: kongsberg.com/fisherysonar 492671/C... - Page 43 Drawing file 492671/C...
- Page 44 Simrad HT20470 Installation Manual 492671/C...
-
Page 45: 494025 Processor Unit Outline Dimensions (Ht20470/Ac)
Drawing file 494025 Processor Unit outline dimensions (HT20470/AC) Download the source drawing from our website: kongsberg.com/fisherysonar 492671/C... - Page 46 Simrad HT20470 Installation Manual 492671/C...
- Page 47 Drawing file 492671/C...
-
Page 48: Power Supply Dimensions
Simrad HT20470 Installation Manual Power supply dimensions For additional details, refer to the technical specifications provided by the manufacturer. 492671/C... - Page 50 ©2022 Kongsberg Maritime...
