A. General
The KAA0608A is a cable assembly used for testing KNG-P/KNG-Ps series radios. This cable is
compatible with Cobham/Aeroflex 3920 only. If using HP8920, please use KAA0608.
B. The Kit
Cable Assy
1
7001-31084-200_Ver. 11-17 | BK Technologies
KAA0608A
User Guide
RF Coax Cable – 1ea.
Double Banana
Plug Adapter -1 ea.
BNC Male Binding Post - 2 ea.
Advertisement
Table of Contents
Related Manuals for BK TECHNOLOGIES KAA0608A
Summary of Contents for BK TECHNOLOGIES KAA0608A
- Page 1 KAA0608A User Guide A. General The KAA0608A is a cable assembly used for testing KNG-P/KNG-Ps series radios. This cable is compatible with Cobham/Aeroflex 3920 only. If using HP8920, please use KAA0608. B. The Kit RF Coax Cable – 1ea. Double Banana Plug Adapter -1 ea.
- Page 2 5. Highlight the field just below IP Address box. 6. Press “Select” then a menu will show up as shown in Figure 4. Figure 4 7. Choose the type of test for the radio under test. 8. Press “Select”. 7001-31084-200_Ver. 11-17 | BK Technologies...
- Page 3 3. Connect the two “Banana to BNC” binding post to Audio In 1 and 2 as shown in Figure 6. Figure 6 4. Connect “Double Banana to BNC” to “Audio In” binding posts on the Aeroflex 3920 as shown in Figure 7. Figure 7 7001-31084-200_Ver. 11-17 | BK Technologies...
- Page 4 2.2. Press the button corresponding to “START” to begin the alignment. 3. Individual Testing. 3.1. If individual testing is desired, then highlight “RESET ALL” then highlight the individual test items to run. 3.2. Press “START”. 7001-31084-200_Ver. 11-17 | BK Technologies...
- Page 5 Technical Service Support - Customer Service BK Technologies 7100 Technology Drive Melbourne, FL 23904 (800) 422-6281 www.BKTechnologies.com 7001-31084-200_Ver. 11-17 | BK Technologies...
