Youngman MiniMax User Manual

Mobile Aluminium Tower
USER GUIDE
Introduction
This Assembly Guide is designed to provide you with step
bystep instructions to ensure that your system is erected
with themaximum of ease and safety. Before assembly,
please read thesafety notes. Operatives must be qualified
or competent toerect the tower. If the scaffold is passed
on to another personthey should also receive these
instructions. Consult the PASMA Guide for full information
on the use of Mobile Towers.
Checklist
Inspect components prior to erection
Inspect tower prior to use
Tower upright
Castors locked and legs correctly adjusted
Braces & platform level
Stabilisers fitted as specified
MiniMax
Platforms located & windlocks on
Handrails in place
Toeboards located
Refer to this checklist before using each time.
Safe Use
Check that all components are on site and that they are
functioning correctly – (refer to check list and quantities).
Check that the ground is level and capable of
supporting the weight of the strucure.
During erection it is recommended that a temporary
guardrail brace be employed.
The safe working load is 220 kgs per platform uniformly
distributed, 500kg per tower structure.
This must not be exceeded.
The tower should always be climbed from the inside.
Do not use boxes or step ladders on the platform to
gain additional height.
Lifting of Equipment
Components should be firmly secured by a reliable
lifting material (eg rope), employing a reliable knot to
ensure safe fastening and always lift within the tower.
