NAD t765 Specification Sheet

NAD t765 Specification Sheet

A/v surround sound receiver
Hide thumbs Also See for t765:

Advertisement

Quick Links

Features
7 x 80W Simultaneous Full Disclosure Power
7 x 100W Minimum Continuous Power (FTC)
PowerDrive™ amplifier technology
Holmgren™ Toroidal Power Supply
Modular construction for simple upgrade and service
Audyssey Auto Setup and Calibration of all speaker settings using
supplied microphone
Data Port for use with optional NAD IPD 1 Dock for iPod
Dolby Digital, Dolby Digital EX, ProLogic II, ProLogic IIx, DTS,
DTS ES, DTS 24/96, DTS NEO:6, EARS and Stereo Enhanced
Surround Modes
5 A/V Custom Presets store unique listening modes, DSP
options, tone, speaker and display settings
Direct speaker level adjustment for surround, center and sub
NAD Soft Clipping™
Burr-Brown 24 bit 96kHz A/D converter
Burr-Brown 24 bit 192kHz Stereo D/A converters (x5)
Texas Instruments Aureus™ 7.1 DSP (32 bit dual core floating
point design)
3 1080p HDMI Video Inputs switch to 1 Output, freely assignable
Cross Conversion of all analog video formats
7 Analog Stereo Audio Inputs (1 front panel)
Media Player MP front panel input
6 Analog Video Inputs, all S-Video and Composite (1 front panel),
3 Component Video
Details
The NAD T765 is heir to many generations of award winning NAD designs. This exceptional pedigree is evident
in both the look and the feel of the T765, and it is unmistakable the moment you listen. It is NAD's insistence on
creating products with remarkable sound quality at sensible prices that has made NAD the first choice among
the most knowledgeable listeners from around the world. NAD's "Music First" philosophy dictates that we
endow our Surround Sound products with the same warm involving sound quality that makes music listening so
rewarding with our stereo components. This stands in stark contrast to our competitors who view Surround
Sound components primarily from a "content" point of view, with sound quality far down the list of priorities. Yet
the T765 is second to none in terms of flexibility and up-to-the-minute digital technology.
Full Disclosure Power Ratings
Inflated power specifications have been used to "sell" receivers as long as there have been receivers to sell.
But not at NAD. Instead, we encourage our customers take a clear-eyed look at the real issues.
Receivers don't make music and filmsound by driving laboratory test-loads, they do it by driving loudspeakers.
And loudspeakers, whether labeled 8Ω or 4Ω in "nominal impedance," are far more challenging. A speaker
T 765 A/V Surround Sound Receiver
7 Digital Audio Inputs, 3 Coax and 4 Optical (1 front panel)
3 Analog Stereo Audio Outputs, 2 assignable as Tape Out, or
as Zone 3 and Zone 4 Outputs with independent source and
volume control
Back Surround Amplifier Channels can be reassigned for
Zone 2 or front Bi-Amp
3 Video Monitor Outputs, Component, S-Video and Composite
®
formats
3 Analog Video Outputs, 2 Tape (Composite and S-Video) and 1
Zone (Composite)
2 Digital Outputs, 1 Coaxial, 1 TOSLINK
7.1 Analog Input (for DVD Audio/SACD/ETC.)
Speaker A + B switching (Speakers B stereo only)
Zone 2 A/V Line Level Output with independent source and
volume selection
ZR-4 Second Zone Remote included with discrete codes for
independent zone
IR Input
3 x IR Outputs
RS-232 port interface for advanced control systems
3 x 12V Output Triggers, 1 x 12V input
Preamp Outputs for all 7.2 channels (2 Subwoofers)
RDS FM/AM Tuner with 30 direct access presets
XM Ready – XM subscription and optional XM module required
HTR-3 Illuminated Learning Remote Control

Advertisement

loading
Need help?

Need help?

Do you have a question about the t765 and is the answer not in the manual?

Questions and answers

Summary of Contents for NAD t765

  • Page 1 The NAD T765 is heir to many generations of award winning NAD designs. This exceptional pedigree is evident in both the look and the feel of the T765, and it is unmistakable the moment you listen. It is NAD’s insistence on creating products with remarkable sound quality at sensible prices that has made NAD the first choice among the most knowledgeable listeners from around the world.
  • Page 2 With the T765, NAD has made it easy to add more speakers for listening to music in an additional room or “zone”. A second pair of speakers can simply be added to the front channel amplifiers and switched on or off from the remote control or front panel switch.
  • Page 3 T765 does not become obsolete anytime soon. Preamp outputs allow the addition of more powerful amplifier channels. The T765 includes a data port specifically designed to control an iPod with the addition of NAD’s optional IPD-1 Dock. This allows the iPod’s meta-data to be displayed on the OSD and be controlled...
  • Page 4 50dB Stereo: NAD Electronics International reserves the right to change specifications or features without notice. NAD is a registered trademark of NAD Electronics International. All rights reserved. No part of this publication may be reproduced, stored, or transmitted in any form whatsoever without the written permission of NAD Electronics International.
